Page 2
Introduction…………………………………………………………………………………………..1 Part 1 General Information ....................2 Part 2 Indoor Units ......................... 5 Part 3 Installation ........................56 Part 4 Control ........................75...
Page 3
(heated water system). ® Fresco commercial AC fan coil is designed and manufactured on the base of advanced technology, and utilize qualified galvanized iron as material. Due to its supper-thin design, it has such advantages: beautiful outlook, space saving, easy installation, etc.
Page 4
General Information FCAC-KTSM-2008-12 Part 1 General Information 1. Model Names of Fan Coil ................3 2. External Appearance ................. 3 3. Nomenclature .................... 4 4. Features ..................... 4 General Information...
Page 5
FCAC-KTSM-2008-12 Model Names of Fan Coil 1. Model Names of Fan Coil Auxiliary Electrical Type Model Power source Heater FFC4B-03H FFC4B-400R Without FFC4B-045H Compact Four-way Cassette Type FFC4B-05H FFC4B-03H With FFC4B-04H FFC4A-06H FFC4A-07H Without FFC4A-08H FFC4A-09H 220-240V~,1Ph, 50Hz FFC4A-1200H Four-way Cassette Type FFC4A-06HA FFC4A-07HA...
Page 6
Air flow capacity Function Code B :Compact 1One way 4Four way Cassette Type Fan Coil Fresco 4. Features Chilled water/Hot water (2 pipes) Low height for easy installation Low noise fan direct driven by single phase, 3 speed permanent split capacitor motor.
Page 7
FCAC-KTSM-2008-12 Indoor Units Part 2 Indoor Units Four-way Cassette Type ..........6 Compact Four-way Cassette Type ........ 27 One-way Cassette Type ..........40 Indoor Units...
FCAC-KTSM-2008-12 Features 1. Features Ultra thin machine body to easy installation and maintenance: 600~750CFM: 230mm, 850~1500CFM: 300mm. Different color panels for choose: White Gray Blue Black Adding digital tube displaying on the display board. LED can display the Error Code to make the malfunction checking easier.
Page 10
Features FCAC-KTSM-2008-12 3 Pre-cut and air outlet stopple make the air blow to other rooms. Vertical water inlet and outlet are in the same line making the installation easier. Electrical heater is optional. A full series of controller give you the most suitable solution according to the different requirement from different customers.
Page 25
FCAC-KTSM-2008-12 Exploded View Part Name Part Name Electric control box head cover I Wire clip Electric control box head cover II Drip tray assembly Electric control box assembly of indoor unit Evaporator fixing hook Electric control box welded assembly Water pump baffle plate Transformer Water drain pump subassembly Capacitor...
Page 27
FCAC-KTSM-2008-12 Exploded View Part Name Part Name Electric control box head cover I Tandem, wire Electric control box head cover II Wire clip Electric control box assembly of indoor unit Drip tray assembly Electric control box welded assembly Evaporator fixing hook Voltage transformer Water pump baffle plate Supporter of electrical heater...
Features FCAC-KTSM-2008-12 1. Features Low operation noise ---Streamline plate ensures quietness ---Creates natural and comfortable environment The adoption of the most advanced 3- Dimensional Screw fan ---Reduces the air resistance passing through ---Smoothes the air flow ---Makes air speed distribution to the heat exchange uniform Improvement for easy installation and maintenance (only available for small four-way cassette) ---Little space is required for installation into a shallow ceiling ---Because of the compactness and weight reduction of the main unit and panel, all models can be...
FCAC-KTSM-2008-12 Troubleshooting FFC4B-03H, FFC4B-400R, FFC4B-045H, FFC4B-05H Part Name Quantity Part Name Quantity Evaporator Wiring box assembly Panel 16.1 Wiring box Room temperature sensor 16.2 Motor capacitor Locker of evaporator 16.3 Transformer Fixer of evaporator 16.4 Main PCB Drain pipe 16.5 Terminal Drain pump 16.6...
Page 42
One-way Cassette Type FCAC-KTSM-2008-12 One-way Cassette Type 1. Feature ................41 2. Specification ............... 42 3. Dimensions................. 43 4. Service Space ..............44 5. Wiring Diagrams ..............45 6. Capacity Tables ..............47 7. Sound Levels ..............51 8. Explored View ..............52 9.
FCAC-KTSM-2008-12 Feature 1. Feature 235 mm-thick body features discreet, slim design and offers a wide variety of discharge methods and mounting such as in corners or in suspended ceilings, etc. (1) Smoother air flow with less turbulence --- Owing to the multiple-blade fan rotor and the air guide design, the airflow is getting smoother and more comfortable (2) One direction air flow --- Quick cooling...
Page 55
FCAC-KTSM-2008-12 Explored View Part Name Quantity Part Name Quantity Panel 15.1 Wiring box Swing motor 15.2 Transformer Base 15.3 Main PCB Right side plate 15.4 Wiring terminal Evaporator assembly 15.5 6-hole terminal Tube temperature sensor Left side plate Indoor temperature sensor Right cover of evaporator Evaporator Supporter of water level switch...
FCAC-KTSM-2008-12 Troubleshooting Part Name Quantity Part Name Quantity Panel 15.2 Transformer Swing motor 15.3 Main PCB Base 15.4 Wiring terminal Right side plate 15.5 6-hole terminal Evaporator assembly 15.6 Control PCB of electrical heater Tube temperature sensor Left side plate Indoor temperature sensor Right cover of evaporator Evaporator...
Page 58
Installation FCAC-KTSM-2008-12 Part 3 Installation The Installation of FFC1A ..........57 The Installation of FFC4A/FFC4B ......... 65 Installation...
Page 59
FCAC-KTSM-2008-12 The Installation of FFC1A The Installation of FFC1A 1. Installation Attention ............58 2. Install the Main Body ............59 3. Install the Panel ..............61 4. Install Drain Pipe ..............62 5. Wring ................... 64 The Installation of FFC1A...
Installation Attention FCAC-KTSM-2008-12 1. Installation Attention Installation place There is enough room for installation and maintenance. The ceiling is horizontal, and its structure can endure the weight of the indoor unit. The air outlet and the air inlet are not impeded, and the influence of external air is the least. The air flow can reach throughout the room.
FCAC-KTSM-2008-12 Install the Main Body 2. Install the Main Body Please refer to the following figure for the hanging screw bolts. Please install with Ø10 hanging screw bolts. The handling to the ceiling varies from the constructions, consult the construction person for the specific condition.
Page 62
Install the Main Body FCAC-KTSM-2008-12 Install the hanging bolt into U groove of the hanging tool. Overhang the indoor unit and ensure it is level using a level gauge. The Installation of FFC1A...
FCAC-KTSM-2008-12 Install the Panel 3. Install the Panel Note: The panel and the ceiling, the panel and the unit body should be connected closely, or air leakage, water leakage and condensate dew will be caused. Please refer to the panel installation manual to install the panel. Please confirm if the installation places of unit body and panel are proper.
Install Drain Pipe FCAC-KTSM-2008-12 4. Install Drain Pipe When connecting the pipe, please use the sealing material and pipe glove. Caution: The drain pipe of indoor unit must be heat insulated, or it will condense dew, as well as the connections of the indoor unit.
Page 65
FCAC-KTSM-2008-12 Install Drain Pipe Drainage test Check whether the drainpipe is unhindered New built house should have this test done before paving the ceiling. Stow 600-800cc water with pot or hose from outlet slowly. Turn on the power, and operate the air conditioner under the "COOLING" mode. The drainage test is doing during checking the drain pump motor running sound.
Wring FCAC-KTSM-2008-12 5. Wring Caution: The air conditioner should use separate power supply with rated voltage; the voltage of power supply must be within90%~110% of rated value. The wiring work should be done by qualified persons according to circuit drawing. A disconnection device having an air gap contact separation in all active conductors should incorporated in the fixed wiring according to the National wiring regulation.
Page 67
FCAC-KTSM-2008-12 The Installation of FFC4A/FFC4B The Installation of FFC4A/FFC4B 1. Before Installation .............. 66 2. Installation space ............... 66 3. Installation procedures for fresh air intake duct connection ..............66 4. Install the Main Body ............67 5. Install the Panel ..............70 6.
Before Installation FCAC-KTSM-2008-12 Before Installation Please check whether the accessories are of full scope. If there are some fittings free from use, please restore them carefully. 2. Installation space (refer to fig.1,fig.2,fig.3 and table 1 for specification.) The indoor unit should be installed in a location that meets the following requirements: There is enough room for installation and maintenance.
FCAC-KTSM-2008-12 Install the Main Body Install the Main Body A. The existing ceiling (to be horizontal) Cut a quadrangular hole of 880×880mm in the ceiling according to the shape of the installation paper board. The center of the hole should be at the same position of that of the air conditioner body. Determine the lengths and outlets of the connecting pipe, drain pipe and cables.
Page 70
Install the Main Body FCAC-KTSM-2008-12 The Installation of FFC4A/FFC4B...
Page 71
FCAC-KTSM-2008-12 Install the Main Body The Installation of FFC4A/FFC4B...
Install the Panel FCAC-KTSM-2008-12 5. Install the Panel Caution: Never put the panel face down on floor or against the wall, or on bulgy objects. Never crash or strike it. (1) Remove the air inlet grill. Slide two grid switches toward the middle at the same time, and then pull them up. (Refer to fig. 9) Draw the grid up to an angle of about 45o, and remove it.
Page 73
FCAC-KTSM-2008-12 Install the Panel The Installation of FFC4A/FFC4B...
Connect the Drain Pipe FCAC-KTSM-2008-12 6. Connect the Drain Pipe Install the drainpipe of the indoor unit You can use a polyethylene tube as the drainpipe (out-dia. 37~39mm, in-dia. 32mm). It could be bought at local market or from your dealer. ...
Page 75
FCAC-KTSM-2008-12 Connect the Drain Pipe 1. Drainage test Check whether the drainpipe is unhindered New built house should have this test done before paving the ceiling. Remove the test cover, and stow water of about 2000ml to the water receiver through the stow tube. (Refer to Chart 19) Turn on the power, and operate the air conditioner under the "COOLING"...
Wiring FCAC-KTSM-2008-12 7. Wiring Caution: The air conditioner should use separate power supply with rated voltage. The external power supply to the air conditioner should have ground wiring, which is linked to the ground wiring of the indoor and outdoor unit. The wiring work should be done by qualified persons according to circuit drawing.
Page 77
FCAC-KTSM-2008-12 Control Part 4 Control Wireless remote controller R51/E ......... 76 Wireless remote controller R05/BGE ........78 Control...
Page 78
Wireless remote controller R51/E FCAC-KTSM-2008-12 Wireless remote controller R51/E Suitable for One-way Cassette type, Compact Four-way Cassette type and Wall-mounted type: Remote Controller Specifications Model R51/E Rated Voltage 3.0V Lowest Voltage of CPU Emitting Signal 2.0V Reaching Distance 8m (when using 3.0 voltage, it can get 11m) Environment Temperature Range Introduction of Function Buttons on the Remote Controller 1.
Page 79
FCAC-KTSM-2008-12 Wireless remote controller R51/E SWING Button: Push this switch button to change the louver angle. RESET Button: When the RESET button is pushed, all of the current settings are cancelled and the control will return to the initial settings. 5.
Page 80
Wireless remote controller R05/BGE FCAC-KTSM-2008-12 Wireless remote controller R05/BGE Suitable for Four-way Cassette type: Visual photo Note: The outline figure on cover is for reference only, which may differ from what you purchased. Make sure to read chapter PRECAUTIONS before you operate the air conditioner. The content is available for model R05/BG.
Page 81
FCAC-KTSM-2008-12 Wireless remote controller R05/BGE Please remove the batteries before long period unused, otherwise the remote controller may be damaged. If pressing the button reset the remote controller, which indicates low battery, please replace the batteries. If no receiving sound is heard from indoor unit or on remote controller does not flash, please replace the batteries.
Page 82
Wireless remote controller R05/BGE FCAC-KTSM-2008-12 Indicators and functions Temp: Display the set temperature. Adjust temperature via and No display in this area if the unit is on FAN mode. Transmitting display: The icon will flash once when the signal is sent by remote controller. ON/FF: Icon is displayed when the remote controller is turned on, or vice versa.
Page 83
FCAC-KTSM-2008-12 Wireless remote controller R05/BGE Timer operation TIME ON and TIME OFF are used to turn on and turn off the unit at the set time respectively. TIME ON operation Press TIME ON, icon SET, HOUR and ON are lightened. Press TIME ON again and adjust the time.
