Operators Manual
Water Heater Module
Model 2000-0250
# 003-703270
Oct 16/03
DRYAIR INC.
606 Highway Drive,
St. Brieux, SK., Canada, SOK 3V0,
Tel: 306-275-4848
1-888-750-1700
Fax: 306-275-4664
dryair@dryair.ca
DRYAIR INC.
1095 N. Main Street
Bowling Green, Ohio, USA, 43402
Tel: 419-354-8546
1-866-354-8546
Fax: 419-354-9706
dryair@dryair.us

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2000-0250 and is the answer not in the manual?

Questions and answers

Summary of Contents for DryAIR 2000-0250

  • Page 1 Operators Manual Water Heater Module Model 2000-0250 # 003-703270 Oct 16/03 DRYAIR INC. 606 Highway Drive, St. Brieux, SK., Canada, SOK 3V0, Tel: 306-275-4848 1-888-750-1700 Fax: 306-275-4664 dryair@dryair.ca DRYAIR INC. 1095 N. Main Street Bowling Green, Ohio, USA, 43402 Tel: 419-354-8546...
  • Page 2: Table Of Contents

    Water Heater Module ..........................3-1 Powered Heat Transfer ..........................3-1 Passive Heat Transfer ..........................3-2 Accessories ..............................3-2 How the DRYAIR System Works ........................3-3 Setup Positioning and Handling of Water Heater Module..................... 4-1 Required Safety Clearances ..........................4-1 Elevation Concerns ............................4-1 Fuel Setup ................................
  • Page 3: Warranty Policies & Claim Procedures

    Warranty Policies & Claim Procedures DRYAIR Inc. (referred to within as DRYAIR) warranties its new, unused equipment to be free of defects in material and workmanship at the time of delivery to the first retail purchaser. Warranty Policies Basic warranty policy •...
  • Page 4: Warranty Claim Procedure

    All warranty credits must be processed with the DRYAIR Warranty Claim Form. • All warranty parts, unless otherwise specified, are to be returned to DRYAIR along with a completed Warranty Claim Form. Note: Prior to returning warranty parts, please call for an authorization number and shipping instructions from the Warranty Department in Canada.
  • Page 5: Safety Concerns

    Safety Concerns General Safety Guidelines • Make certain that the operator reads and understands all the information in this manual. • All unauthorized people must be kept away from the equipment when in operation. • Maintain instructional and safety decals. Replace damaged decals. •...
  • Page 6: Material Safety Data Sheet

    Material Safety Data Sheet BOSS CHILL PG MSDS Canadian Centre for Occupational Health and Safety Issue: 2001-4 (November, 2001) ***MATERIAL SAFETY DATA*** CHEMICAL PRODUCT & COMPANY IDENTIFICATION PRODUCT NAME:........PROPYLENE GLYCOL INDUSTRIAL PRODUCT CODE: ........70511 EFFECTIVE DATE: ........05/23/03 DATE PRINTED 10/09/03 MSD: 000248 COMPANY IDENTIFICATION: ....
  • Page 7 ACCIDENTAL RELEASE MEASURE (See Section 15 for Regulatory Information) PROTECT PEOPLE: Isolate area. PROTECT THE ENVIRONMENT: Contain liquid to prevent contamination of soil, surface water or ground water. CLEANUP: For small spills, clean up with absorbent material. Collect material in suitable and properly labeled open containers. For large spills, dike and pump into suitable and properly labeled containers.
  • Page 8 13. DISPOSAL CONSIDERATION (See Section 15 for Regulatory Information) DISPOSAL: DO NOT DUMP INTO ANY SEWERS, ON THE GROUND OR INTO ANY BODY OF WATER. All disposal methods must be in compliance with all Federal, State/Provincial and local laws and regulations. Regulations may vary in different locations. Waste characterizations and compliance with applicable laws are the responsibility solely of the waste generator.
  • Page 9: Material Safety Data Sheet

    Material Safety Data Sheet DOWFROST* HEAT TRANSFER FLUID MSDS Canadian Centre for Occupational Health and Safety Issue: 05/09/2002 Received: 09/10/2003 ***MATERIAL SAFETY DATA*** CHEMICAL PRODUCT & COMPANY IDENTIFICATION PRODUCT NAME:........DOWFROST* HEAT TRANSFER FLUID MSDS#: ............1376 EFFECTIVE DATE: ........05/09/2002 COMPANY IDENTIFICATION: ....
  • Page 10 ACCIDENTAL RELEASE MEASURE SMALL SPILLS: Absorb with materials such as: cat litter, sawdust, vermiculite, Zorb-all. Collect in suitable and properly labeled containers. LARGE SPILLS: Dike area to contain spill. Recover spilled material if possible. See Section 13, Disposal Considerations for additional information.
  • Page 11 11. TOXICOLOGICAL INFORMATION ACUTE TOXICITY: Peroral: Rat; female; LD50 = 20300 mg/kg Percutaneous: Based on information for a similar material: Rabbit; LD50 = > 10000 mg/kg DEVELOPMENT TOXICITY: Contains component(s) which did not cause birth defects or any fetal effects in lab animals., The component(s) is/are:, REPRODUCTIVE TOXICITY: Contains component(s) which did not interfere with reproduction in animal studies., Contains component(s) which did not interfere with fertility in animal studies., The component(s) is/are:, Propylene glycol.
  • Page 12 STATE/LOCAL Pennsylvania (Worker and Community Right To Know Act): Pennsylvania Hazardous Substances List and/or Pennsylvania Environmental Hazardous Substance List: The following product components are cited in the Pennsylvania Hazardous Substance List and/or the Pennsylvania Environmental Substance List, and are present at levels which require reporting. COMPONENT CAS# AMOUNT...
  • Page 13: Introduction

    The clean, low relative humidity heat delivery minimizes energy costs by eliminating the need to draw in fresh outside air. With the DRYAIR system, you just reheat warm internal air, rather than heating cold external air. Fluid circulation Fluid circulation lines are designed to endure the toughest work site environment.
  • Page 14: Passive Heat Transfer

    Hose reel The DRYAIR hose reel is capable of holding over 6000 ft. of 3/4" I.D. circulation line heat exchangers. The reel can be transported by common carrier, or slings can be used for lifting. The hose reel is forklift accessible from all four sides.
  • Page 15: How The Dryair System Works

    How the DRYAIR System Works The DRYAIR system uses a low-pressure, open fluid loop distribution system with an atmospherically vented fluid reservoir. A hydronic water heater warms the heat transfer fluid. This heated fluid is pumped through a distribution system loop, passing through heat exchangers in remote locations.
  • Page 16: Setup

    The positioning of all the system components on the site will be influenced by a number of factors. Please read all of the “Setup” section before beginning. Be sure to observe all local electrical codes, gas codes and fire regulations when setting up the DRYAIR system. Positioning and Handling of Water Heater Module •...
  • Page 17: Fuel Setup

    Fuel Setup Natural Gas • The installation of natural gas lines to the DRYAIR water heater module must be performed by a licensed gas tradesperson, and must conform to all local natural gas codes for water heater appliance installations. •...
  • Page 18: Heat Transfer Fluid (Htf)

    Heat Transfer Fluid (HTF) CAUTION! At no time should you use automobile antifreeze in your DRYAIR system. The use of automobile antifreeze will void your DRYAIR warranty. • The heat transfer fluid (HTF) level should show no more than 1/4 on the gauge (cold fluid) at start-up. As the HTF warms to operating temperature, fluid expansion will raise the level to 1/2 or 3/4 on the gauge (depending on the total volume of fluid in the circulation system).
  • Page 19: Operation

    Make sure the gas supply is closed off and control panel toggle switchws are in the “OFF” position. • Supply power to the system. Fluid Circulation System Start-up The DRYAIR water heater cabinets, portable heat exchangers and circulation line are shipped pre- filled with heat transfer fluid. Purging Air from the “HTF” Circulation System •...
  • Page 20 • Toggle the pump switch (4-1) to the “On” (up) position and run the pump. This will release the air from the system. 4 - pump switch, water heater • Monitor the “heat transfer fluid level gauge” (5-1) and switch and breaker reset make sure that the heat transfer fluid level stays between 1/4 to 3/4 full at all times during this process.
  • Page 21: Water Heater Initial Firing

    Water Heater Initial Firing Bleed gas line • With door panels removed from the front of cabinet and the heating unit, loosen the gas line union (item 1) and open exterior gas line valve (item 2) only enough to purge air from gas line. CAUTION: Propane gas is heavier than air.
  • Page 22 Raising “HTF” Fluid to Set Temperature First, make sure that none of the portable heat exchanger fans are in operation. The portable heat exchanger fans must be turned on in succession. Cold Structure • Plug in the first portable heat exchanger fan and verify that the fan is running.
  • Page 23: Troubleshooting

    Troubleshooting • There are 2 red light(s) on the control panel, propane system (1 solid, 1 flashing); natural gas system (1 solid), which will indicate a condition that has caused the unit to shut down. • There are 6 green lights on the control panel, which indicate the status of a sequence of functions while the unit is running. •...
  • Page 24: Maintenance

    Maintenance The DRYAIR system is designed to be a low maintenance system. All system equipment is assembled using extensively tested and certified components. Following these maintenance procedures will ensure the maximum benefit and minimal downtime for the system. The daily maintenance schedule is designed to be a quick system check and ensures a low risk of operating interruptions.
  • Page 25: Seasonal Checklist

    Circulation Pump • The pump requires no special maintenance other than that specified in the manufacturer’s pump manual provided as part of the literature package with each DRYAIR system. Hoses • Periodically check all hoses for damage due to aging, elevated temperatures, over-torqued hose clamps, abrasion and weathering.
  • Page 26 “Y” Strainer “Y”strainer flush • The “Y” strainer (1-1) requires regular maintenance every time system is set up or 1000 hours of operation. • Remove the end plug from the end of the strainer outlet valve (1-2). • Position a 5-gallon container at the outlet valve. •...
