Summary of Contents for Furngully SPROUT PRO BP-2
- Page 1 BP–2 SPROUT PRO SIDE-BY-SIDE INSTALLATION GUIDE *General Guide | See Master Plan...
- Page 3 48" POWER PARTS LIST ITEM PRODUCT CODE CODE BPROTPB Module Mounting Plate (Short) BPROTPB Power Module Bracket PRODB Double Receptacle Block PROR Receptacles...
- Page 4 1 | ATTACH RECEPTACLE TO MOUNTING PLATE Place receptacle on top of mounting plate. Slide brackets over receptacle and secure with provided screws. Note: Do not over torque screws 2 | ASSEMBLE POWER BEAM Slide inner beam inside of the outer beam and adjust until at least 2 power slots are visible on the inner beam.
- Page 5 3 | CONNECT JUMPER TO RECEPTACLE Before securing to power beam, secure jumper(s) to receptacle. 4 | INSERT POWER INTO BEAM Insert the modules into the slot in the power beam. One end will connect to the inner beam and the other end will connect to the outer beam.
- Page 6 54"-72" POWER PARTS LIST 54"-72" ITEM PRODUCT CODE CODE BPROTPB Module Mounting Plate (Long) BPROTPB Power Module Bracket PRODB Double Receptacle Block PROSB Single Receptacle Block PROBC In-line Connector PROR Receptacles...
- Page 7 1 | ATTACH RECEPTACLE TO MOUNTING PLATE Place receptacle on top of mounting plate. Slide brackets over receptacle and secure with provided screws. Note: Do not over torque screws 2 | ASSEMBLE POWER BEAM Slide inner beam inside of the outer beam and adjust until at least 2 power slots are visible on the inner beam.
- Page 8 3 | CONNECT JUMPER TO RECEPTACLE Before securing to power beam, secure jumper(s) to receptacle. Note: Jumper connects to the single block 4 | INSERT POWER INTO BEAM Insert the modules into the slot in the power beam. One end will connect to the inner beam and the other end will connect to the outer beam.
- Page 9 SPROUT PRO PARTS LIST ITEM PRODUCT CODE CODE BPROF Surface Attachment Bracket Surface Support Bracket Width Adjusting Bracket BPRO24F 24" Feet BPROSRB SR Beam Mounting Bracket BPROTPB Power Beam BPROTPB Data Beam Set Laminate Surfaces Note: Parts list is for a single workstation, additional parts will be needed for additional workstations...
- Page 10 1 | SECURE LEGS TO FRAME Set frame assembly upside down on floor and then place legs inside of frame aligning the second hole of the frame with the front of the foot. Note: Be sure welded brackets are facing back of workstation 2 | CONNECT SURFACE BRACKETS Slide bracket under frame, align pre-drilled holes of surface bracket to Sprout Pro frame and secure with 4 screws each.
- Page 11 3 | SET FRAME ON SURFACE AND SET LENGTH Measure from outer edges of workstation legs to determine proper workstation length. Use the chart below to determine the length of workstation frame. Surface Frame Width Length (#) 48" 47.5" 54" 54"...
- Page 12 5 | SECURE FRAME TO SURFACE Using wood screws, attach frame to surface and tighten screws on adjustable center bracket. Adjustable Bracket 6 | ATTACH POWER BEAM MOUNT Slide the beam mount over the welded bracket on back of leg with 4 screws.
- Page 13 7 | SECURE POWER BEAM TO WORKSTATION Use a 6" extension to secure power beam end to center cutout of SR Beam Mounting Bracket with 4 screws on each end. 8 | SET POWER BEAM WIDTH Using the set screws, interconnect the inner and outer power beam sections for additional stability.
- Page 14 9 | REMOVE DATA PLATE After power beam is secured, remove data plate from the outer beam. 9 | ASSEMBLE DATA TRAY Slide the inner beam into the grooves of the outer bream and place onto the underside of the power beam and adjust width as needed and secure.
- Page 15 10 | REMOVE GLIDE AND INNER BRACKET Twist off glides, then using an allen wrench remove the 2 holding in the glide bracket. Note: Glides must be removed so feet can be added to workstation 11 | (OPTIONAL) SLIDE ON PANEL BRACKETS If you have laminate panels, slide brackets over legs.
- Page 16 12 | SECURE FEET TO LEGS Using 4 screws for each foot, secure to legs with longer side of foot facing the front of the workstation. 13 | SECURE AND CONNECT CONTROL BOX Place control box inside of the center beam and secure with 2 wood screws.
- Page 17 14 | SECURE HANDSET AND CONNECT Connect handset cable to control box. Align front of handset with surface edge and secure with 3 wood screws. 15 | FLIP WORKSTATION AND INITIALIZE Connect cord to power source then press and hold simultaneously for 5 seconds until both leg columns are in lowest position.
- Page 18 16 | ALIGN AND CONNECT WORKSTATIONS Pass jumper through bridge extension then insert the extension into the open slot of power bridge on first workstation. Align second workstation, connect jumper and push workstations together. Both ends of bridge extension should site inside of power bridge.
- Page 20 © 2021 Furngully. All rights reserved.
