Power smart DB2194CR Instruction Manual page 22

Item Stock# Descreiption
1 303190312A Engine
Hex Flang Washer
2 303020627
M8×25
3 203050381B Side Discharge Plate
Torsion Spring Pin Φ6
4 303090066A
Torsion Spring
5 303130335
Φ2.5*Φ11*58
6 303160833 Discharge Support
7 303020468 Hex Washer M6*10mm
8 203050382A Discharge Frame
9 203050399C Front Cover
10 303010332 Screw ST6.3*20
Front Turn Spring
11 303071058
Assembly
12 303030032 Nut M6
13 303020276 Hex Bolt M6*12
14 303030077 Nut M8
15 203050384 7" Right Wheel
16 303180934 Front Axle Welding
17 303071420 Wheel Clamp 2.5mm
18 303010216 Screw
19 203050385 7" Left Wheel
20 303071356C Deck
21 303110030 Flat Key 4.7*40
22 303180808 Blade connector
23 303071037 Blade
Dish Washer
24 303043023A
Φ10.5*Φ45*2.5
25 303020626 Blade Bolt
QTY Item Stock#
1 26 203050386
3 27 303071059
1 28 303180938A
1 29 203050387
1 30 303030140
1 31 203050401C
2 32 302080050C
1 33 303160807
1 34 303121005
14 35 303020558
1 36 203050519
4 37 303080488C
4 38 303080503C
4 39 303030026
1 40 203020336A
1 41 303020140
4 42 302060035
8 43 303080489A
1 44 303020308
1 45 302080049
1 46 303030025
1 47 303080490
1 48 303160531A
1 49 303030065
1
22
Descreiption QTY
8" Right Wheel
Rear turn spring
assembly
Rear axle welded
8" Left Wheel
Nut 26*21*5
Back Seat
Plastic Barrier
Shaft Pin M6x35
Cotter Pin Ф1.6*20mm
Bolt M6*35
Wire Clip
Lower Left Tube
Lower Right Tube
Nut M8
Knob
T-Screw M8*50mm
Plug
Upper Handle Φ22*1.2
Hex Bolt M6*30mm
Brake Wire
Cover Nut M6
Blade Control Bar φ8
Engine Connection
Hook
Normal Nut M6
1
1
1
1
2
1
1
2
2
2
1
1
1
2
2
2
2
1
1
1
2
1
1
1
