- Page 1 Maxi Mix Plus Vortex Mixer OPERATION MANUAL AND PARTS LIST Series 1271 Model # Voltage M63215 M63210-33 M63214 LT1271X1 • 11/6/02...
-
Page 2: Table Of Contents
Table of Contents IMPORTANT INFORMATION This manual contains important operating and safety information. You must carefully read and understand the contents of this manual prior to the use of this equipment. Safety Information ..............................3 Alert Signals..............................3 Warnings ..............................3 Introduction................................4 Intended Use ..............................4 General Usage..............................4 Principles of Operation ..........................4 Performance Characteristics and Specifications ....................5... -
Page 3: Safety Information
Safety Information Your Thermolyne Maxi Mix has been designed with func- Alert Signals tion, reliability, and safety in mind. It is your responsibility to install it in conformance with local electrical codes. For safe operation, please pay attention to the alert signals throughout the manual. -
Page 4: Introduction
Introduction Intended Use The Maxi Mix Plus is a general laboratory vortex mixer. It is intended for applications where vortexing of single or multiple tubes is required. The unit consists of 1) a rubber mixing cup, 2) a silicone rubber mixing platform complete with plate & screws 3) a two–position mode switch for touch-on or constant-on operation. -
Page 5: Performance Characteristics And Specifications
Performance Characteristics and Specifications Electrical Specifications M63215 120 Volts, 40 Watts, 60 Hz M63210-33 230 Volts, 40 Watts, 50 Hz M63214 100 Volts, 45 Watts, 50/60 Hz Overall Dimensions Weight M63215 6 lbs., 10 oz 5” 6-1/4” 8” M63210-33 6 lbs., 10 oz 5”... -
Page 6: Declaration Of Conformity
ERFORMANCE HARACTERISTICS AND PECIFICATIONS Declaration of Conformity Barnstead International hereby declares under its sole responsi- bility that this product conforms with the technical requirements of the following standards (230 volt models only): EMC: EN 61000-3-2 Limits for Harmonic Current Emissions... -
Page 7: Operation
Operation Place unit on a stable, flat surface and plug into an appro- priate outlet. Warning To avoid electrical shock, use with a The power switch on the M63215 and the M63214 is a properly grounded electrical outlet of combination ON/OFF and mode switch to enable correct voltage and current handling “TOUCH”... -
Page 8: Troubleshooting
Troubleshooting The Troubleshooting section is intended to aid in defining and correcting possible service problems. When using the chart select the problem category that resembles the malfunction, then proceed to the possible causes category and take necessary corrective action. Problem Possible Causes Corrective Action Mixer does not operate... -
Page 9: Maintenance And Servicing
Maintenance and Servicing To Replace the Mode Switch Warning To avoid electrical shock, always dis- and/or Power Switch connect from power supply before servicing. Refer servicing to qualified Disconnect mixer from power supply. personnel. While holding the rubber mixing cup securely, loosen the screw holding the cup down and remove the cup from the counterweight. -
Page 10: To Replace Motor
AINTENANCE AND ERVICING plunger from defective micro switch. Identify or mark wires disconnected to ensure proper placement and connection when reinstalling. Insert spring and plunger into the shaft of the new microswitch. Position microswitch on mounting studs and secure with two screws. Reconnect the wires as identified or marked in Step 7. -
Page 11: To Replace Damper Springs
AINTENANCE AND ERVICING 12. Reinstall case and secure with four screws. 13. While holding the rubber mixing cup securely, secure mixing cup to counterweight with the hold down screw. 14. Reconnect mixer to power supply. To Replace Damper Springs Disconnect mixer from power supply. While holding the rubber mixing cup securely, loosen the screw holding the cup down and remove the cup from the counterweight. -
Page 12: Replacement Parts List
Replacement Parts Series 1271 Description Part No. Part No. 100-120 volt 230 volt Brass Counterweight Assembly CW1254X1A CW1254X1A Counterweight Spring (2 required) SPX47 SPX47 Motor MTX95 - 120V MTX96 MTX97 - 100V Cord set CR1254X1-120V CR632X3 CR632X1-100V Strain Relief included with cord-120V included with cord SRX10-100V PC Board Switch (under motor) -
Page 13: Ordering Procedures
If the dealer cannot handle your request, then contact our Customer Service Department at 563-556-2241 or 800-553-0039. Prior to returning any materials to Barnstead International, please contact our Customer Service Department for a “Return Goods Authorization” number (RGA). Material... -
Page 14: Exploded View
Exploded View For 100 Volt Units Description Counterweight Assembly Motor Power Switch (230V only) Switch Assembly Mode Switch Foot Damper Springs Rubber Cup Assembly Fuse (120 & 230 Volt Only) -
Page 16: One Year Limited Warranty
SALE, USE OR PERFORMANCE OF ANY PRODUCTS, WHETHER SUCH CLAIM IS BASED ON CON- TRACT, TORT (INCLUDING NEGLIGENCE), ANY THEORY OF STRICT LIABILITY OR REGULATORY ACTION. The name of the authorized Barnstead International dealer nearest you may be obtained by calling 1-800-446- 6060 (563-556-2241) or writing to: 2555 Kerper Boulevard P.O.
