SNOW CAB #1695613
FOR
BROADMOOR, CONQUEST, PRESTIGE
1600, 1700, 1800, 2600, 2700, 2800,
YARD & GARDEN TRACTORS
INSTALLATION INSTRUCTIONS - PARTS LIST
IMPORTANT
READ THIS MANUAL CAREFULLY AND KEEP FOR FUTURE REFERENCE
CAUTION !
REMOVE THE VINYL PANELS FOR TRANSPORT IN AN OPEN TRUCK OR TRAILER
WARNING !
THIS CAB WILL NOT PROTECT OPERATOR FROM INJURIES CAUSED BY ROLLOVER, COLLISION,
OR OTHER ACCIDENTS
1
11745808R
1754894
Rev. -
Advertisement
Summary of Contents for Original Tractor Cabs 1695613
- Page 1 SNOW CAB #1695613 BROADMOOR, CONQUEST, PRESTIGE 1600, 1700, 1800, 2600, 2700, 2800, YARD & GARDEN TRACTORS INSTALLATION INSTRUCTIONS - PARTS LIST IMPORTANT READ THIS MANUAL CAREFULLY AND KEEP FOR FUTURE REFERENCE CAUTION ! REMOVE THE VINYL PANELS FOR TRANSPORT IN AN OPEN TRUCK OR TRAILER...
-
Page 2: Maintenance Instructions
WARNING This cab is designed to provide foul weather protection only. It does not provide protection from noise, exhaust fumes, chemicals or injury from collision, or other accidents. 1. Do not operate machine in confined areas without proper ventilation 2. Thoroughly check area of operation before using machine 3. - Page 3 Carton Contents: Snow Cab #1695613 Key # Part # Qty. Description 11218 Foot, RH 11219 Foot, LH 11220 Rear Cross Bar 11257 Rear Cross Bar Bracket 11235 Front Post, RH 11230 Blade Control Bracket 11236 Front Post, LH 11222 Foot Pocket Guard...
- Page 4 Note: Some early model tractors do not have the boltholes for cab installation. See the drilling instructions in the back of this manual to locate and drill the required holes in these tractors. FIGURE 1 A. Use the carton contents list and Figure 1 to identify all the steel parts.
- Page 5 Step 2; See Figure 2: Install Right Foot (1) A. Pull the buttons in the front end of the step plate mat out and pull the mat back to expose the bolt at reference (A). Remove the bolt. B. Place the right Foot on the step plate and attach it with a 5/16”...
- Page 6 NOTE: On Prestige, 2700, and 2800 tractors the Rear Cross bar assembly is attached to the frame behind the hitch plate. The hitch plate is removed by removing the two bolts on each side of the tractor frame. Step 4; See Figure 4: Install Rear Cross Bar Bracket (4) and Rear Cross Bar (3) A.
- Page 7 Step 6; See Figure 6: Install Right Front Post (5) and a Foot Pocket Guard (8) A. Insert lower end of the right Front Post into the upper end of the right Foot. Insert a 1/4” x 1 1/2” bolt through the hole in the Foot Pocket Guard. B.
- Page 8 NOTE: The latch plate on the rear posts should be facing forward with the notch to the outside. Step 8; See Figure 8: Install Right Rear Post (10), Left Rear Post (11) and Rear Curtain Support (12). Insert the right Rear Post into the right end of the Rear Cross Bar.
- Page 9 Step 10; See Figure 10: Install Rear Curtain (14). A. Place the Rear Curtain onto the rear of the frame. Close the snap flaps at the corners. B. Close the snap flaps around the Rear Posts and the ends of the Rear Cross Bar. C.
- Page 10 Step 12; See Figure 12: Install Plastic Top (17) A. Place the Plastic Top over the Top Frame. Keep the rod sewn into the Rear Curtain laying over the rear of the frame to hold it in place. Do not insert bolts at this time. Figure 12 Step 13;...
- Page 11 Step 14; See Figure 14: Install Windshield (16), Secure Front Panel Vinyl A. Set the Windshield into position on top of the Front Panel Vinyl as it lies over the Front Cross Bar. B. Hold the front of the Plastic Top up and push the Windshield into position on the frame.
- Page 12 Template for drilling cab-mounting holes in early model tractors. Rear Frame dimensions for drilling. (not actual size)
- Page 13 Left front step plate mount. For Replacement Parts and Accessories Contact: Original Tractor Cab Co., Inc. P.O. Box 97 6849 W. Front St. Arlington, IN 46104 Phone 765-663-2214 765-663-2101 Email Sales@originalcab.com Visit us on the web to see our other products. www.originalcab.com Cabs for Lawn Tractors, Garden Tractors, Compact Tractors, Snow Blowers, Utility Vehicles...
- Page 14 LIMITED WARRANTY SNOW REMOVAL EQUIPMENT CABS COVERED BY WARRANTY ORIGINAL TRACTOR CAB CO., INC., (the "Company") warrants to the owner that each new product listed below is merchantable and free of defects in workmanship and material. During the warranty period, the dealer from whom the product was bought, or the Company, will provide, free of charge, parts and the shipping costs of parts necessary to correct any defect in workmanship and material.
