MODEL E13SGH-E16SGB CENTER PIVOT
OWNER'S MANUAL – ORIGINAL INSTRUCTIONS
CONGRATULATIONS!
You are now the proud owner of the BARRETO stump grinder. The OPERATOR'S MANUAL is
attached to the machine. Please study it and this manual to become familiar with the stump grinder,
its characteristics, and method of operation. Pay particular attention to the safety and operating
instructions to prevent personal injury or equipment damage.
If you have any questions or need any replacement parts in the future, please contact us at your
convenience. Our toll-free phone number, fax and email are listed below.
THANK YOU for your patronage and confidence in BARRETO equipment.
Barreto Manufacturing, Inc.
Innovative Equipment Engineered to Last
66498 Hwy 203, La Grande, OR 97850
(800) 525-7348 (541) 963-7348
FAX (541) 963-6755
E-Mail:
info@barretomfg.com
Web Site:
http://www.barretomfg.com
Machine Identification Record
Machine model number
Machine serial number
Engine manufacturer
Engine model number
Engine serial number
13SGH-16SGB OWNER'S MANUAL
MANUAL PIVOT STUMP GRINDER
________________________
________________________
________________________
________________________
________________________
THE
8/29/18
Page 1 of 11

Advertisement

Table of Contents
loading

Related Manuals for Barreto E13SGH

Summary of Contents for Barreto E13SGH

  • Page 1 OWNER’S MANUAL – ORIGINAL INSTRUCTIONS CONGRATULATIONS! You are now the proud owner of the BARRETO stump grinder. The OPERATOR’S MANUAL is attached to the machine. Please study it and this manual to become familiar with the stump grinder, its characteristics, and method of operation. Pay particular attention to the safety and operating instructions to prevent personal injury or equipment damage.

  • Page 2: Table Of Contents

    STUMP GRINDER INSTRUCTIONS UPON DELIVERY SERVICE INFORMATION HOUR METER STUMP GRINDER INTENDED USE LUBRICATION REQUIREMENTS OPERATOR TRAINING WARRANTY OF BARRETO MANUFACTURING EQUIPMENT MAINTENANCE PREPARATION ROUTINE MAINTENANCE BRIGGS/VANGUARD MAINTENANCE SCHEDULE CUTTER WHEEL TORQUE SPECS ELECTRICAL SCHEMATIC – BRIGGS/VANGUARD ELECTRICAL SCHEMATIC WITH HONDA...

  • Page 3: Stump Grinder Instructions Upon Delivery

    Damage resulting from this will void your engine warranty and not be covered. IMPORTANT - The engine on the Barreto stump grinder may or may not have been serviced prior to shipping. Shipping regulations may prohibit shipping with fuel or oil in the engine. Check levels and add oil and fuel as required before starting engine.

  • Page 4: Hour Meter

    Your DGI® hour meter is pre-set at the DGI® factory to go into Flash Alert mode at 25-hour intervals. Although the engine manufacturer does not require changing engine oil this often, due to heavy-duty use and extreme conditions inherent to tiller use, Barreto Manufacturing strongly recommends frequent oil changes.

  • Page 5: Stump Grinder Intended Use

    STUMP GRINDER INTENDED USE The Barreto Stump Grinder is designed to remove in-ground tree stumps and exposed roots. It should not be used to cut any material other than wood stumps and the surface soil around the stumps or exposed roots.

  • Page 6: Operator Training

    Barreto Manufacturing, Inc. warrants all BARRETO equipment to be free of defects in material and workmanship for a period of one (1) year. All BARRETO fuel components, fuel tank, cap, lines & fittings are warranted for two (2) years. Warranty period begins on date of delivery to the original user.

  • Page 7: Routine Maintenance

    • Fasteners • Safety Decals Barreto recommends using genuine Barreto spare parts to ensure not only quality but also the health and safety of the operator. Clean safety decals often using soap and water. Do not use abrasive cleaners or solvents such as mineral spirits that may damage the decals.

  • Page 8: Briggs/Vanguard Maintenance Schedule

    BRIGGS/VANGUARD MAINTENANCE SCHEDULE Please see your engine owner’s manual for specific procedures and products to use for proper maintenance of your engine, as well as proper disposal of used parts/fluids. 13SGH-16SGB OWNER’S MANUAL 8/29/18 Page 8 of 11...

  • Page 9: Cutter Wheel Torque Specs

    CUTTER WHEEL TORQUE SPECS We recommend that the teeth and holders be inspected after every use to maximize the usable life of these high wear items. • Cutter teeth have three sides and we recommend rotating them frequently to keep the cutting edges sharp.

  • Page 10: Electrical Schematic With Honda

    ELECTRICAL SCHEMATIC- HONDA GX390 STUMP GRINDER TROUBLESHOOTING GUIDE CAUTION!! Always use extreme care when troubleshooting or making adjustments on stump grinder. Stay clear of cutter wheel when engine is running. Stop engine before disassembling any component. Cutter Wheel Problem 1. Slow cutter wheel speed Check and adjust belts tension 2.

  • Page 11: Specifications

    SPECIFICATIONS MODEL NUMBER E16SGB E13SGH DIMENSIONS BRIGGS/VANGUARD HONDA Weight 406 lb. (184.55 kg) 406 lb. (184.55 kg) Height 54.5” (1.39 m) 54.5” (1.39 m) Length 74” (1.89 m) 74” (1.89 m) Width 29” (744 mm) 29” (744 mm) ENGINE Engines...
