Summary of Contents for Artone U&I-03

Page 1 Connevans S S o o l l u u t t i i o o n n s s t t o o i i m m p p r r o o v v e e t t h h e e q q u u a a l l i i t t y y o o f f l l i i f f e e This product may be purchased from Connevans Limited secure online store at www.DeafEquipment.co.uk DeafEquipment.co.uk...
Page 2 .artonecs.
Page 3 (The instructions for this found under title: Function Statement.) No t e: In order to use the Artone Bluetooth LoopSet, please make sure that your hearing aid (or inductive receiver) is set to t-coil function. “T” or “MT” - please refer to the hearing aid manual.
Page 4: Table Of Contents
Artone Bluetooth LoopSet User manual Content Introduction Unit description Charging Charging notes Turn On/Off 5 Pairing Bluetooth loopset Disconnecting Function Statement Product Care Accessibility Specification LED status indicator Operation Statement 12-13 Warning Warranty...
Page 5: Introduction
The whole process is totally wireless and hands free. Current version of the Artone BT LoopSet supports the following profiles 2.0 +EDR: handsfree and headset with prior Bluetooth technology V1.0 & V1.2.
Page 6: Unit Description
Unit Detailed description...
Page 7: Charging
Charging Bluetooth LoopSet Connect the USB connection cord to the AC adapter socket. Connect the second end of the connection cord to the Bluetooth LoopSet. Plug the AC adapter to the wall AC socket (mains outlet). When Charging, LED glows red color. The LED will turn off automatically once the battery is full.
Page 8: Charging Notes
Battery and Charging Note When battery is running out of power the LoopSet beeps and the red LED flashes every 2 seconds. Note: if charging the Bluetooth LoopSet when it is on, the unit will automatically turn off. The BT LoopSet can be turned on again for usage while charging.
Page 9: Turn On/Off
Turn ON/OFF Bluetooth LoopSet To turn the BT LoopSet on, please press the multifunctional Button (MFB) for about 3 seconds until the BT LoopSet beeps and the blue LED indicator start flashing continually 4 times and the red LED 2 times. The Blue LED will flash 1 time every 2-5 seconds after being turned on (before pairing).
Page 10 Notes - You need to pair the Bluetooth LoopSet with your mobile phone one time. Now the Artone Bluetooth LoopSet is stored in your memory phone and can be viewed in the phone’s paired Bluetooth devices list. Notice: If the link abnormally disconnects (for example, out of range or phone power off), the loopset tries to reestablish the link.
Page 11: Disconnecting
Disconnecting the Bluetooth LoopSet To disconnect the paired BT LoopSet from your phone (for example to connect another Bluetooth device), turn the LoopSet off or disconnect the loopset from the Bluetooth menu of your phone. You do not need to delete the paired BT LoopSet from your phone in order to disconnect it.
Page 12 Answering a call: In case of incoming call, press the MFB button to answer the call (if your phone is set to automatic answer the LoopSet will answer the call after one ring). Ending a call: Press the MFB button to end the call. Making a Call: If your phone supports redialing function, please press the volume “+”...
Page 13: Product Care
* Bluetooth is a registered trademark of Bluetooth SIG inc Artone™ Artone Communication Solutions™ Artone Bluetooth LoopSet™ and design of the LoopSet and the know-how used are the intellectual property of “Artone Communication Solutions” and can not be used by any other entity without written permission from Artone Communication Solution management.
Page 14: Specification
Specification Artone Bluetooth LoopSet Manufacturer Artone Communication Solutions Main Chip BlueCore4 – Audio ROM Bluetooth version V2.0 + EDR Frequency 2.4Ghz~ 2.4835GHz ISM Band Input Power 45mW RF Out Power 0dBm Data transfer rate 2Mbps ~ 3Mbps BT LoopSet key...
Page 15: Led Status Indicator
Status Note Flashing continued 4 times and LED flashing 2 Turning on mode times . Flashing 1 time for every Stand by mode before 2 seconds pairing Blue Flashing one time for Stand By after every 10 seconds successful pairing Flashing continued 4 Data transferring times for every 8 seconds...
Page 16: Operation Statement
Operation Statement Operation Methods Status The blue LED flashes 4 times Long Press MFB Turning on and red LED key for 2 seconds flashes 2 times and hear a beep Red LED flashes Long press MFB Turning off 4 times and hear a key for 5 seconds beep With the BT...
Page 17 Operation Statement Operation Methods Status Increasing the Press Volume “+” The BT LoopSet volume beeps and both and blue LED flash one time each – total 15 volume levels available Decreasing the Press Volume “-“ The BT LoopSet volume beeps and both and blue LED flash one time each –...
Page 18: Warning
* parts of the Artone Bluetooth LoopSet may be magnetic, please do not place near the BT LoopSet near credit card or magnetic storage media as the information may be erased.
