Gigalink PYROMATE Programming Instructions

PROGRAMMING INSTRUCTIONS

Units will not work if transmitter is within 10 feet of receiver!!!

Antenna must be elevated for maximum performance

ATTENTION!!

YOUR UNIT REQUIRES NO PROGRAMMING IT HAS BEEN

DONE AT THE FACTORY.

STANDARD PROGRAMMING

This is used to program all channels from a multi channel receiver to a multi channel transmitter.

Standard programming can be achieved by the following steps below.

Step 1: Turn on the receiver power.

Step 2: Momentarily short the two CC pins on the receiver board. (This sets all channels to a

random code.

Step 3: Connect the Multi Channel transmitter to the Multi channel receiver by inserting the

Programming cable into the transmitter and receiver 2.5 mm socket (this will activate the

programming mode and is indicated by the red light (LED), on the transmitter that must remain on.

Step 4: Activate any two channels simultaneously on the multi channel transmitter for one second;

the led should blink a few times to confirm code programming and then switch off

This mode is used to program multiple receivers to the same channels. And must be performed with

the Low Power Programmer using long cable provided!

Step 1:

Perform standard programming to Low power transmitter to teach unit channel of 1

but do not short cc pins or you will reset the codes.

Step 2:

Open Transmitter (Low Power) and receiver, Turn power on, Place an alligator clip across

CC pins in receiver and leave shorted, Plug long coding cable between receiver and Low Power

forward programming transmitter, get full distance of cable away from receiver and shield the

transmitter from receiver, make sure that red led on transmitter is not lit, Push button 1 for 2

seconds, Remove the Jumper (alligator clip), remove the coding cable Repeat on as many receivers

as needed.

unit
