TKH security EVE ONE-PoE Quick Start Manual

EVE ONE-PoE
One-channel H.264 video encoder with PoE
Quick Start Guide
Unpack
Note: Subject to modification. Actual product and accessories may differ in appearance.
Mount with bracket (optional)
© Siqura B.V. 2017
Version 1.1 (162610-1.1)
EVEONEPOE QSG (MW10)
All manuals and user guides at all-guides.com
Find the latest firmware, additional manuals, the
EU Declaration of Conformity, and support for this
product at:
http://www.tkhsecurity.com/support-files
Understand the front panel
1
Power OUTPUT
12.5 Vdc, (+/- 0,5 V)
Max 5 W (0.4 A)
μSDHC 32 GB
Digital I/O
RS-422/485
/
2
Reset button
1
For powering analogue camera, for example. Do NOT use as power input.
2
Press and hold for 10 sec. to reset to factory defaults (incl. network settings)
Assign IP address via DHCP ...
S620 D
Mini
DisplayPort
HDMI
10.x.y.0
Video Management System
IEEE 802.3af PoE
... or use factory-set IP address (optional)
Video/RS-422/485
IP = 10.x.y.z
Cat 5
NTP
DHCP
Mount on DIN rail
Video/RS-422/485
EVE ONE-PoE V1
Cat 5
10.x.y.0
NTP
Video Management System
