- Page 1 Included Classic Pattern Dimensions: 6’h x 16’w Included Included Crown & Trumpet Pattern Dimensions: Trumpet: 8’h | Crown: 4’h x 32’w Trumpet Pattern Dimensions: 14’h x 7’w EcoSeries ™ ½ HP Floating Fountain Model #ES05 Gen 3 • 5.8A, 120V/60Hz Owner’s Manual...
-
Page 2: Table Of Contents
THANK YOU FOR CHOOSING OWNER’S MANUAL FOR: The Airmax EcoSeries EcoSeries ½ HP Floating Fountain Floating Fountain Model #ES05 Gen 3 Watch & Learn | Watch & Learn | How-To Install Video How-To Install Video airmaxeco.com/EcoSeriesVideo ENGLISH SECTION PAGE System Components Safety System Installation Maintenance &... -
Page 3: Ecoseries ½ Hp Floating Fountain
EcoSeries ½ HP Floating Fountain Model #ES05 Gen 3 • 5.8A, 120V/60Hz Owner’s Manual Airmax EcoSeries Floating Fountain 1. System Components Control Panel • Easy to Install, No Tools Required • Asynchronous Water Cooled Motor, Silicon Carbide (SiC) Shaft Bearing and Ceramic Shaft •... -
Page 4: System Installation
3. Setup & Installation ENGLISH Fig. 1 Mooring Line (Vinyl Coated Galvanized Wire) EcoSeries Floating Fountain Mooring Stake Control Panel Carabiner Underwater Disconnect Recommended Mooring Kit • 2 stakes Fig. 2 • 2 carabiners Power Cord • 2 cable clamps •... -
Page 5: Maintenance & Winter Storage
3. Setup & Installation, cont. ENGLISH g) Installing the Airmax LED Fountain Light Set (sold separately) (Fig. 5) Note i) To attach the light, clip the light into the mounting spot on the float and use the vertical tension screw to secure the light into place. Continue until all lights are attached. Be Once lights are installed and mindful of the different lengths of interconnect cord between lights. -
Page 6: Troubleshooting - Fountain
5. Troubleshooting - Fountain ENGLISH IF FOUNTAIN WON’T RUN IF FOUNTAIN STARTS AND STOPS ISSUE CORRECTION ISSUE CORRECTION GFCI Tripped Reset GFCI Intake plugged Clean intake Power Cord Cut Repair or replace power cord Not enough water in reservoir Bring water level up to at least 24” at fountain IF STREAMS RAISE AND LOWER Intake plugged Clean intake... -
Page 7: Replacement Parts
7. Replacement Parts ENGLISH Fountain Replacement Parts 1. #651310 – Nozzle Nut Spray Pattern 2. #651164 – Classic Pattern (4185) 3. #651703 – Crown & Trumpet Pattern (1037-iB) 4. #651708 – Trumpet Pattern (1009-C) 5. #653100 – Float Mount Half Ring w/ Hardware 6. -
Page 8: Componentes Del Sistema
EcoSeries ½ HP Fuente flotante Modelo #ES05 Gen 3 • 5.8A, 120V/60Hz Manual de instrucciones Airmax EcoSeries flotante 1. Componentes del sistemama Panel de Control • Fácil de instalar, sin necesidad de herramientas • Asíncrono refrigerado por agua del motor, carburo de silicio (SiC) cojinete del eje y eje de cerámica •... -
Page 9: Operación De Temporada
3. Instalación y Configuración ESPAÑOL Fig. 1 Dispositivo de amarre (Vinilo recubierto de alambre galvanizado) EcoSeries Fuente flotante Estaca de amarre Panel de Control mosquetón Desconecte Submarino Kit de amarre recomendado • 2 estacas Fig. 2 • 2 mosquetones Cable de •... -
Page 10: Mantenimiento Y Almacenamiento De Invierno
3. Instalación y Configuración, continuación ESPAÑOL g) Instalación de la Fuente de luz conjunto Airmax LED (se vende por separado) (Fig. 5) Nota i) Para colocar la luz, cortar la luz en el lugar de montaje en la carroza y utilizar el tornillo de tensión vertical para asegurar la luz en su lugar. -
Page 11: Solución De Problemas - Fuente
5. Solución de problemas - Fuente ESPAÑOL Si la fuente no se ejecutará Si se inicia fuente y paradas Problema Corrección Problema Corrección GFCI Disparado Restablecer GFCI Ingesta enchufado ingesta Clean Cortar el cable eléctrico Reparar o sustituir el cable de alimentación No hay suficiente agua en el depósito Que el nivel llegue agua a por lo menos 24”... -
Page 12: Piezas De Repuesto
7. Piezas de repuesto ESPAÑOL Piezas de recambio Fuente 1. #651310 – Tuerca de boquilla Patrón de pulverización 2. #651164 – Patrón clásico (4185) 3. #651703 – Patrón Crown & Trompeta (1037-iB) 4. #651708 – Patrón Trompeta (1009-C) 5. #653100 – Flotador montar medio anillo 6. -
Page 13: Des Composants Du Système
EcoSeries ½ HP Fontaine Flottante Modèle #ES05 Gen 3 • 5.8A, 120V/60Hz Mode d’emploi Airmax EcoSeries flottant 1. Des composants du système Panneau de Commande • Facile à installer, sans outils • Asynchrone refroidi à l’eau moteur, carbure de silicium (SiC) Arbre roulement et l’arbre en céramique •... -
Page 14: Opération Saisonnière
3. Installation et de configuration FRANÇAIS Fig. 1 Bitte d’amarrage (Enduit de vinyle fil galvanisé) EcoSeries fontaine flottante Jeu d’amarrage Panneau de contrôle Mousqueton Déconnecter sous-marine Kit mouillage recommandée • deux enjeux Fig. 2 • 2 mousquetons • 2 colliers de câble •... -
Page 15: Entretien Et De Remisage D'hiver
3. Configuration et installation, continué FRANÇAIS g) Installation de la fontaine de lumière Set Airmax LED (vendu séparément) (Fig. 5) Remarque i) Pour fixer la lumière, couper la lumière dans la tache de montage sur le flotteur et utiliser la vis de tension verticale pour sécuriser la lumière en place. Continuez jusqu’à ce que Une fois les lumières sont toutes les lumières sont attachés. -
Page 16: Dépannage - Fontaine
5. Dépannage - Fontaine FRANÇAIS Si la fontaine ne fonctionne pas Si fontaine démarrages et arrêts QUESTION CORRECTION QUESTION CORRECTION GFCI déclenché Réinitialiser GFCI Apport branché apport Clean Cordon coupe Réparer ou remplacer le cordon d’alimentation Pas assez d’eau dans le réservoir Apportez de l’eau niveau jusqu’à... -
Page 17: Pièces De Rechange
7. Pièces de rechange FRANÇAIS Remplacement de pièces Fontaine 1. #651310 – Buse écrou Spray Pattern 2. #651164 – Motif Classique (4185) 3. #651703 – Motif Crown & Trompette (1037-iB) 4. #651708 – Motif Trompette (1009-C) 5. #651284 – Flotter monter demi-anneau 6. - Page 18 Notes Call your local Airmax Dealer with questions or to order parts.
-
Page 19: Warranty
Airmax, Inc. Airmax EcoSeries Fountain Limited Warranty Airmax, Inc. warrants to the original purchaser (the end user) of any Airmax EcoSeries Fountain manufactured by Airmax, Inc. that any component which proves to be defective in materials or workmanship, as determined by the factory within 3 years from the original purchased date, will be repaired or replaced at no charge with a new or remanufactured part, and returned freight prepaid. - Page 20 Optional Single Arch Pattern Optional Double Arch and Geyser Pattern Optional Double Arch Pattern For Information on Optional Spray Patterns, Visit Us Online at airmaxeco.com/ecoseries Airmax, Inc. 15425 Chets Way Street Armada, MI 48005 (866) 4-AIRMAX airmaxeco.com #651274 V3...
