POUNDEX
Unpack the box and place the contents on a flat, level surface. Verify that you have all the
parts and hardware, including the necessary bolts and washers. READ ALL INSTRUCTIONS
AND WARNINGS BEFORE USING THIS PRODUCT. IF THERE IS ANY QUESTION
ABOUT A CONDITION BEING SAFE OR UNSAFE, DO NOT USE THIS PRODUCT!
Parts List
A
B
C
D
E
L
Step 1: Align female brackets at the back rest (C) to the male brackets at the
seat base (A), (B). Insert the back rest (C) to the seat base and push it to the
end. Make sure the brackets is scured in position.
R
ASSEMBLY INSTRUCTION
ITEM NO: F6891; F6892; F6893
LAF SEAT BASE
1PC
RAF SEAT BASE
1PC
C1 LAF BACK 1PC
C2 RAF BACK 1PC
METAL LEG
4PCS
ADJUSTABLE
METAL LEG
2 PCS
PILLOWS
2 PCS
C1
F
G
H
I
J
K
C2
B
A
5/16" x 25 mm
4PCS
5/16" x 75 mm
2PCS
5/16" x 12 mm
2PCS
5/16" x Ø22 mm
16PCS
1PC
5/16" x 20 mm
8PCS
Advertisement
Table of Contents
Related Manuals for Poundex F6891
Summary of Contents for Poundex F6891
- Page 1 POUNDEX ASSEMBLY INSTRUCTION ITEM NO: F6891; F6892; F6893 Unpack the box and place the contents on a flat, level surface. Verify that you have all the parts and hardware, including the necessary bolts and washers. READ ALL INSTRUCTIONS AND WARNINGS BEFORE USING THIS PRODUCT. IF THERE IS ANY QUESTION...
- Page 2 Step 2: Secure the two individual seat fame (A&B) together. Using bolt (G.I) nut (H) and allen wrench (J) Step 3: Attach the adjustable metal leg (E) and place it on the underside of the seat base (A+B). Align the holes in the metal legs (E) with the holes in the seat base (A+B).
