- Page 1 INS40 TIGER GARDEN PERGOLA GENERAL ASSEMBLY INSTRUCTIONS...
-
Page 2: Before You Get Started
BEFORE YOU GET STARTED PLEASE READ INSTRUCTIONS CAREFULLY • Check the pack and make sure you have all the parts listed. • When you are ready to start, make sure you have the right tools at hand (not supplied). • Ensure there is plenty of space and a clean dry area for assembly. TIMBER As with all natural materials, timber can be affected during various weather conditions. - Page 3 Please retain instructions for future reference CAUTION: CAUTION: All buildings should be erected It is advisable to wear safety by two competent adults. gloves during building installation. Whilst all products manufactured are made to the highest standards of safety and in the case of children’s products independently tested to EN71 level, we cannot accept responsibility for your safety whilst erecting or using this product.
-
Page 4: Tools Required
BEFORE YOU GET STARTED TOOLS REQUIRED: We recommend using the following tools (not supplied): DRILL RUBBER MALLET SCREWDRIVER + LADDER TAPE MEASURE SHARP KNIFE SPIRIT LEVEL FIXING KIT GUIDE: Screws (70mm Galvanised - QTY 55) IMPORTANT: Customer to supply own fixings for type of ground. - Page 5 Please retain instructions for future reference BUILDING PACK CONTENTS: For full details of what should be included please see the Product Construct Diagram and itemised Cutting List that are supplied with the delivery. They are also available on request in pdf form from our helpful Customer Support team –...
- Page 6 TIGER GARDEN PERGOLA ASSEMBLY GUIDE IMPORTANT: Customer to supply own fixings for type of ground. Posts 92mm square. NOTE - Make sure that customer supplied fixings are in place before building commences - For post layout. (Detail A) 2382 CENTERS...
-
Page 7: Inside View
Please retain instructions for future reference Step 1: INSIDE VIEW (Detail B) • Layout upright posts and side rails (un-notched) as shown. • Pre-drill holes in side rails to reduce risk of wood splitting. • Secure together using 2x 70mm (S70) screws per join. - Page 8 TIGER GARDEN PERGOLA ASSEMBLY GUIDE Step 2: S100 • Slot in outer top rails (notched) as shown. (Detail D) S100 • Pre-drill holes in top rails to reduce risk of wood splitting. (S100) • Secure to side rail using 1x 100mm...
- Page 9 Please retain instructions for future reference Step 3: • Slot together pergola support arms into the corner of framework. • Pre-drill holes to reduce risk of wood splitting. (S70) (Detail E) • Secure to upright post using 2x 70mm screws per join. EXTERNAL VIEW (S70) (Detail F)
- Page 10 TIGER GARDEN PERGOLA ASSEMBLY GUIDE Step 4: S100 • Pre-drill holes in feet to reduce risk of wood splitting. (S70) • Secure feet to upright post using 2x 70mm screws per foot. 2 feet supplied per post. (Detail G) NOTE: Please check type of ground fixings used that the feet can sit flush.
- Page 11 Please retain instructions for future reference...
