- Page 1 WATCHING WHERE OTHER CAMERA’S CAN’T RANGER INSTALLATION GUIDE...
- Page 2 INSTALLATION ON A WOOD POST This guide is for installing the camera system on a 4” X 4” wood post. For best results mount post in 18” of concrete 24 hours prior to camera installation. Choose a post height applicable for your security situation. Recommended camera height is 10’...
- Page 3 HOW TO INSTALL STEP 1 STEP 2 Install solar panel mounting bracket on Install camera mounting bracket on side of the side of the wood pole closest to facing pole facing the center of the field of view towards the south. you want to monitor.
- Page 4 HOW TO INSTALL STEP 8 STEP 7 Using 2 provided machine screws, secure Place solar panel on solar panel mounting solar panel to bracket. bracket using the horizontal bar on the back of the panel, make sure holes are aligned with the bracket. STEP 10 STEP 9 Connect the camera’s power cable to the...
- Page 5 HOW TO INSTALL STEP 11 STEP 12 Place remote sensor in desired monitoring Login to view your camera using the Eye location. Range from camera: 250ft (76m) Trax software at eyetrax.net. Detection Range: 40ft (12m) Mounting Height: 3ft (1m) ~ 10ft (3m) STEP 13 Check to see your camera working.
- Page 6 OTHER INSTALL METHODS Universal Mounting Barrel Mounting Bracket System Modular Pole System INSTALLATION GUIDE...
