HyQuest Solutions AD375MA User Manual

Hide thumbs Also See for AD375MA:
Table of Contents

Advertisement

Quick Links

Download this manual
AD375MA
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AD375MA and is the answer not in the manual?

Questions and answers

Related Manuals for HyQuest Solutions AD375MA

Summary of Contents for HyQuest Solutions AD375MA

  • Page 1 AD375MA User Manual...

  • Page 2: Table Of Contents

    Obligations of the Operator ........................25 Dismantling / Disposal ..........................25 Appendices Part X 10.1 Appendix A Surge Protection ........................27 10.2 Appendix B SDI-12 to RS232 Interfacing ..................... 28 10.3 Appendix C Changing Pulley Sizes ......................30 © 2022 HyQuest Solutions...

  • Page 3: I Disclaimer

    HyQuest Solutions or KISTERS AG. Other product documentation and the information contained in it, names used may or may not be the trademarks of even if HyQuest Solutions has been advised of the their respective owners. possibility of such damages.

  • Page 4: Scope Of Delivery

    Scope of Delivery § AD375MA Shaft Encoder Unit w/axle and its knurled bolt w/set screw § Allen key suitable for set screw § Manufacturing Compliance Certificate © 2022 HyQuest Solutions © 2022 HyQuest Solutions...

  • Page 5: Safety Instructions

    Before starting to work, you have to check the functioning and integrity of the system. § Check for visible defects on the AD375MA, this may or may not include any or all of the following mounting facilities, connectors and connections, mechanical parts, internal or external communication devices, power supplies or power supply lines, etc.

  • Page 6: Part I Introduction

    The AD375MA is a rugged, microprocessor-based, power-efficient shaft encoder for reliable and accurate water level measurement. The built-in digital technology determines the absolute water level from the reference level and the relative rotational movements at level increase or decrease.

  • Page 7: Part Ii Installation

    Attach the float line to the float and lower it to the water. Pass the float line over the pulley making sure that the cable beads (or tape perforations) engage the respective recessed (or spines) on the pulley. Attach the counterweight and lower it into position. © 2022 HyQuest Solutions...
  • Page 8 1 to 2 months. So with Lithium Backup set to “Yes”, the lithium battery will allow the water level to be tracked in the unlikely event that the external 12V power is not present.) © 2022 HyQuest Solutions...
  • Page 9 Installation © 2022 HyQuest Solutions...
  • Page 10 Installation Shaft Encoder Typical Bore Hole Set Up Using Guide Pulleys. © 2022 HyQuest Solutions...
  • Page 11 Installation © 2022 HyQuest Solutions...
  • Page 12 Installation © 2022 HyQuest Solutions...

  • Page 13: Part Iii Configuration

    (eg. Say ML420 interval is 15mins and warmup is 1 sec then TXI=015/01) (The AD375MA 4-20mA current is ready 200mS after loop power is applied) Note: Setting the 4-20mA range to the smallest possible will give the best resolution on a 4-20mA interface!

  • Page 14: Operation

    Screwless Terminals The plug in terminal block shown is a screwless terminal that keeps a constant tension on the wire that is inserted. (The mating socket on the front panel of the AD375MA is sealed with a waterproofing gasket.) External Power Even though the Shaft Encoder's have an internal lithium battery, the unit should only be operated if +12VDC (9.0V to...

  • Page 15: 4-20Ma Interface

    Operation 4-20mA Interface The 4-20mA interface in the AD375MA is optically isolated from the 0V and +12VDC on the right hand end of the connector. The 4-20mA circuitry must be powered by the loop. To conserve power, the data logger switches power to the 4-20mA circuit only when it wants to make a measurement.

  • Page 16: Sdi-12 Compliant Commands

    (Please note the letter ‘a’ in the commands below refer to the SDI-12 address 0, 1, 2,….9) Name Command Response Break Continuous spacing for at least 12 None milliseconds Acknowledge Active a<CR><LF> Send Identification allccccccccmmmmmmvvvxxx...xx<CR> <LF> © 2022 HyQuest Solutions...
  • Page 17 Set parameter for command 'n'. Quadrature Shaft Encoder will reply with a0001<CR><LF> The aDO! command must be issued to get the actual data. Set/Get Current Value aX0! Get the river level. © 2022 HyQuest Solutions...
  • Page 18 (When set to YES and no external 12V is present – the internal lithium battery will continue to power the sensor to measure water level. The lithium battery can only power the sensor for 1 to 2 months !) © 2022 HyQuest Solutions...
  • Page 19 (This also saves the calibration) aX97+03! Increment the 20mA Calibration by 3 step (This should be done while accurately measuring the current on the 4-20mA loop) (If the calibration is changed, always finish by sending aX97+00! to save it) © 2022 HyQuest Solutions...

  • Page 20: Part V Maintenance

    Maintenance Maintenance The AD375MA (as well as AD37.5MA, AD150MA and AD100MA) Shaft Encoders require no maintenance, however all connected mechanical equipment should be periodically checked for cleanliness and ease of operation. Internal 3.6V Lithium AA batteries should be replaced every 2 years.

  • Page 21: Part Vi Troubleshooting

    Remove the 4x screws from the front cover containing the LCD, and press on the ribbon cable connector to check it is firmly plugged in. © 2022 HyQuest Solutions...
  • Page 22 Check the PCB's for water damage - or transient damage (burning on the PCB) - if this is found, the PCBs may need replacing. § If the error does not go away, return the equipment for repair. © 2022 HyQuest Solutions...

  • Page 23: Part Vii Repair

    In rare cases, a product may not be delivered in accordance with your order. In such cases HyQuest Solutions’ return and repair policy applies. For you as a customer, this means the following: 1. Contact HyQuest Solutions using the Repair Request Form made available online: https://www.hyquestsolutions.com.au/fileadmin/Form/RepairRequestForm.pdf...

  • Page 24: Part Viii Technical Data

    -40 °C to +60 °C (encoder only) § -10 °C to +60 °C (standard LCD; -40 °C OLED version available on request) Humidity: 95 % non-condensing Dimensions (L × W × 245 × 125 × 150 mm Mass 1.5 kg © 2022 HyQuest Solutions...

  • Page 25: Part Ix Obligations Of The Operator And Disposal

    Instead, these old appliances must be collected separately and disposed of via the local collection and return systems. Integrated or provided batteries and accumulators must be separated from the appliances and disposed of at the designated collection point. © 2022 HyQuest Solutions...
  • Page 26 Obligations of the Operator and Disposal EU WEEE Directive As players in the environmental market, KISTERS AG and HyQuest Solutions are committed to supporting efforts to avoid and recycle waste. Please consider: Avoidance before recycling! Recycling before disposal! This symbol indicates that the scrapping of the unit must be carried out in accordance with Directive 2012/19/EU.

  • Page 27: Part X Appendices

    Different suppressors are required, depending on the voltage to be protected. The transient suppressors and the metal cabinets should also be connected to a solid earth at the site. © 2022 HyQuest Solutions...

  • Page 28: Appendix B Sdi-12 To Rs232 Interfacing

    Appendix B SDI-12 to RS232 Interfacing The following schematic is for an SDI-12 to RS232 adapter that can be used for any Hyquest Solutions SDI-12 transducer. The adapter will allow a transducer to be connected to a PC, and will communicate at 1200 baud, 7 bits and even parity.
  • Page 29 Appendices Sample SDI-12 comms session: (commands sent to the AD375MA are in “red” and the AD375MA replies are in “black”) (Parameter X17 is set to 0 when unit is supplied from the factory – BattV measure is OFF) (What address are you ? reply indicating 0)

  • Page 30: Appendix C Changing Pulley Sizes

    0+0001.234 (Contin Measure – same result as an M and D command combination) (Compliance with SDI-12 Spec V1.3 (implementing CRC ) occurs in AD375MA S/W Rev 5.0 and higher) 0MC! 00001 (Measure command with CRC request – reply 1 meas ready in...
  • Page 31 13. Press the SELECT button to stop the units flashing. 14. Press the SCROLL button until you return to the main menu. The model will now be ADxxxxMA where xxxx is the steps per rev. (Eg. A 400mm circumference pulley will be model AD0400MA) © 2022 HyQuest Solutions...
  • Page 32 Contact Data Europe | HyQuest Solutions (KISTERS AG) +49 2408 9385 0 info@hyquestsolutions.eu Australia | HyQuest Solutions Pty Ltd +612 9601 2022 sales@hyquestsolutions.com.au New Zealand | HyQuest Solutions NZ Ltd +64 7 857 0810 sales@hyquestsolutions.co.nz Latin America | HyQuest Solutions (KISTERS LATAM) +57 350 575 4079 sales-latam@hyquestsolutions.com...
  • Page 33 © 2022 HyQuest Solutions 29.06.2022...
