Southwest DuraBind Manual

[]
1. Install handle from right side and attach handle onto master shatt.
Then insert knob set and tighten the handle.
2. Install the sub-handle from lett side and attach sub-handle onto
sub-shatt.
'27
r.
Measure the thickness of papers to be bound and determine
punching depth by using binding gauge.
�

Select correct diameter of binding comb to use.

DEPTH 2
DEPTH l
BINDING GAUGE & DIAMETER GUIDE
1. Ad l ·ust side guide.
2. Pu I set pin out to cancer this die if you find edge of document
partially covers one of white rectangles on the alignment scale.
3. Adjust knob for binding depth to 1.2.3. or

1. Insert paper into punch throat.

2. Pull handle down to punch. Return handle to upright
and pull paper out.
3. Continue this step until all papers are punched.
DEPTH 3
3/4"
11/16"
22mm
20mm
5/8"
Place ring with opening side up behind metal finger.
[fil
1. The Binder Stop is on th_ e left hand side turn it down forward
to the extrem end.
2. Push the sub-handle forward until the proper opening of
binding is reached.
Hold it there.
3. Turn the Binder Stop back until it locks.
Fix it there.
1-1/8"
1"
28mm
7/8" 25mm
Insert papers vertically and make sure all fingers are line up
[I]
with punched holes la� down papers horizontally.
Continue this step until all papers are bound.
Return sub-handle to upright. Remove book from metal fingers.
[ID
And you have a professionally bounded document.
DEPTH 4
1-3/4"
1-1/2"
45mm
38mm
1-1/4"
32mm
2"
50mm
