Page 17
テープ走行のしかたを選ぶ MENU ボタンをくり返し押して、表示窓のカーソルを 位置に合わせます。 操作 両面をくり返し再生 両面を 回再生 本体側の面から始めたときは、本体側の面のみを再生します。 停止中にカセットぶたを開けると、走行する面はふた側の面に変わります。 B NR ドルビー MENU ボタンをくり返し押して、表示窓のカーソルを a 位置に合わせます。 の特性に合わせた再生ができます。ドルビー テープの場合には「 ドルビーノイズリダクションはドルビーラボラトリーズライセンシングコーポ レーションからの実施権に基づき製造されています。 DOLBY ドルビー、 及びダブル ングコーポレーションの商標です。 MODE (PB) NR (PB) と a ボタンを押して表示を切り換えます。 MODE の画面表示 Å で録音したテープを聞く ボタンを押して 「 B NR 」...
Page 22
放送局一覧 エリア番号表(エリアコールの放送局一覧) エリア番号: 札幌 バンド プリセット 周波数 放送局名 番号 AM 1 567kHz NHK 747kHz NHK 1287kHz 北海道放送 1440kHz 札幌テレビ放送 80.4MHz FM 82.5MHz FM 85.2MHz NHK FM 88.2MHz NHK FM エリア番号: 仙台 AM 1 891kHz NHK 1089kHz NHK 1260kHz 東北放送 77.1MHz FM 82.5MHz NHK FM エリア番号:...
Page 23
エリア番号: 大阪 バンド プリセット 周波数 放送局名 番号 AM 1 558kHz ラジオ関西 666kHz NHK 828kHz NHK 1008kHz ABC 1143kHz KBS 1179kHz 毎日放送 1314kHz ラジオ大阪 1431kHz 和歌山放送 76.5MHz 関西インターメディア 80.2MHz FM802 82.8MHz NHK FM 85.1MHz FM 大阪 86.5MHz NHK FM 88.1MHz NHK FM 89.4MHz FM 京都...
Page 24
海外でラジオを聞く PRESET +、− ENTER 1 RADIO ON•BAND 2 ENTER ボタンを押して、周波数表示、 「 とプリセット番号表示を点滅させる 3 RADIO ON•BAND 表示を点滅させる。 表示の点滅中に して「 」または「 を押す 自動的に下記の受信範囲に変わります。 使う地域 アメリカ合衆国、 カナダ、中南米諸国 ヨーロッパ、その他 5 RADIO ON•BAND TUNING を選び、 合わせる 海外でも放送局を記憶させることができます ジ 参照 。 日本の周波数に戻すには 上の手順にしたがって操作し、手順 ENTER し、 ボタンを押します。 RADIO ON•BAND ボタンを押してラジオをつける...
Welcome ! Thank you for purchasing the Sony WM-GX655 Radio Cassette- Corder. Some features are: • You can enjoy low bass sounds by the powerful earphone. • You can choose from 2 different emphasizing tones: MB (MEGA BASS) and GRV (GROOVE) to adjust to your favorite sound.
LR6 (WM)) Notes • Do not tear off the film on the rechargeable battery. • Use the Sony NC-6WM rechargeable battery only with the supplied battery charger or with the separately sold battery charger for Sony NC-6WM. • Remove the charger unit from the...
Connecting the Earphones Connect the micro plug firmly to the remote control. Connect the remote control to 2REMOTE. You can put the longer earphone cord behind your neck. To use the supplied clip Position the earphones cord through the guides on the supplied clip as shown.
Page 40
find the beginning FF•AMS of the next track/ once/ succeeding 9 tracks repeatedly (AMS*) during playback find the beginning REW•AMS of the current track/ once/ previous 8 tracks repeatedly (AMS) during playback play the same side REW•AMS from the beginning for two (Rewind Auto seconds or...
Page 41
Select a recording source: To record from the radio Tune in to a station you want to record (see “Listening to the Radio”). When recording FM programmes, make sure the earphones are plugged in as they serve as an aerial. To record with the microphone Connect the supplied...
Listening to the Radio Press RADIO ON•BAND to turn on the radio. Press RADIO ON•BAND repeatedly to select AM or FM. Press TUNING+/– to tune in to the desired station. If you keep pressing TUNING+/– for a few seconds, the Walkman will start tuning to the stations automatically.
Page 43
Tuning in to and Storing Radio Stations Automatically (Auto- Memory Scanning function) Press RADIO ON•BAND to turn on the radio. Press RADIO ON•BAND repeatedly to select AM or FM. Press ENTER until “A” appears in the display. The Walkman starts searching and storing stations.
Area indication and frequency range Area* Frequency range FM (MHz) 87.5–108.0 87.5–108.0 * USA : USA, Canada and Central and South America : European and other countries Using Other Functions Emphasizing Bass Press MENU repeatedly in the playback or stop mode to set the cursor to SOUND in the display.
Page 45
To lock the buttons Slide HOLD to the direction of the arrow. When you press any button “Hold” appears in the display. To unlock, slide HOLD to the opposite direction of the arrow. Using SOUND Press SOUND/AVLS to select the desired mode.
On tapes longer than 90 minutes We do not recommend the use of tapes longer than 90 minutes except for a long continuous recording or playback. They are very thin and tend to be stretched easily. On the remote control Use the supplied remote control only for each unit.
A beep sounds and recording is not possible when REC is slid. • If the tab of the tape is broken off, cover the tab hole with adhesive tape. • If “REV” appears, open the cassette holder then close it so that “FWD”...
Page 48
ソニー株式会社 〒141 東京都品川区北品川6-7-35 お問い合わせはお客様ご相談センターへ ●東京(03)5448-3311●名古屋(052)232-2611●大阪(06)539-5111 Printed in Japan...
