Summary of Contents for Lippert 1520 Series

Page 1 Challenger Door 1520 Series OWNER'S MANUAL...
Page 2 TABLE OF CONTENTS Introduction Safety Operation Using the Flex Wall Switch Using the Remote Key Fob Using the Key Troubleshooting Possible Solutions to Door Not Opening or Closing Remote Control Door and Compressor Relay Replacement Programming Wiring Diagram Introduction The Challenger Door Series 1520 entry door is designed to accommodate wheelchair accessibility and is an easy hands-free option to getting in and out of the recreational vehicle.
Page 3 The "WARNING" symbol above is a sign that a procedure has a safety risk involved and may cause death or serious personal injury if not performed safely and within the parameters set forth in this manual. Failure to follow instructions provided in this manual may result in death, serious personal injury and/or severe product and property damage, including voiding of the component warranty.
Page 4 Do NOT leave the key in the ignition when operating the door. Leaving the key in the ignition while opening or closing the door can cause personal injury and/or product or property damage. Remove the key from the ignition before opening or closing the door. Using the Flex Wall Switch NOTE: Replacement battery for the Flex Wall Switch is one A23 battery.
Page 5 Using the Key Turn the bypass valve to the OPEN position (Fig. 1A). The bypass valve should be located in the same compartment as the air compressor. Make sure people and objects are clear of the door when first opening the door after shutting off the bypass valve as some air may still be in the air hose line.
Page 6 Remote Control Door and Compressor Relay Replacement Programming NOTE: If all other options have been addressed for the door not opening or closing, and the RC relay has been opened and checked that the circuit board is blown, use the procedure below to replace and set the remotes for the new RC relay.
Page 7 Wiring Diagram • All Wiring is 16 GA. Lock Ignition Compressor Closed Green Junction Lock Open Battery Ground Terminal Block Relay Terminal Orange - 85 Strip Red - 30 Positive Brown - 87A White - 86 Remote Control Door and Compressor Supplied Relay...
Page 8 The contents of this manual are proprietary and copyright protected by Lippert Components, Inc. (LCI). LCI prohibits the copying or dissemination of portions of this manual unless prior written consent from an authorized LCI representative has been provided. Any unauthorized use shall void any applicable warranty. ...
