IMPORTANT NOTICE RELATED TO PRODUCT PART NUMBERS
For the latest model and part numbers, please refer to "VT8000 and VT7000 Series Room
Controllers Catalog, version 10" (028-6100-08), which can be found on
http://www.viconics.com/.
This document contains information on active and retired products. The latter are no longer
sold by Viconics Technologies or its partners.
For additional information on 7000 Series Room Controllers and a list of replacement part
numbers, please visit http://www.viconics.com/.
Failure to follow these instructions can result in confusion or order delays.
1 |
028-0323-02_LIT-VZ7656R&VZ7656H_W-E01_EN
VZ7656R1000W / VZ7656H1000W
Zigbee™ Wireless RTU / HP Terminal
Equipment Controllers
Installation Guide
F o r C o m m e r c i a l Z o n i n g S y s t e m s
S e p t e m b e r 2 0 1 9 / 0 2 8 - 0 3 2 3 - 0 1
NOTICE
www.viconics.com
2
3
5
6
8
9
10
12
14
20
30
31
September 2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VZ7656R1000W and is the answer not in the manual?

Questions and answers

Summary of Contents for Viconics VZ7656R1000W

  • Page 1: Table Of Contents

    This document contains information on active and retired products. The latter are no longer sold by Viconics Technologies or its partners. For additional information on 7000 Series Room Controllers and a list of replacement part numbers, please visit http://www.viconics.com/.
  • Page 2: Safety Information

    A qualified person is one who has skills and knowledge related to the construction, installation, and operation of electrical equipment and has received safety training to recognize and avoid the hazards involved. 028-0323-02_LIT-VZ7656R&VZ7656H_W-E01_EN www.viconics.com September 2019...
  • Page 3: Before You Begin

    • Avoid touching exposed conductors and components leads with skin or clothing. For additional information about anticipated transmission delays or failures of the link, refer to NEMA ICS 1.1 (latest edition), Safety Guidelines for the Application, Installation and Maintenance of Solid State Control or its equivalent. 028-0323-02_LIT-VZ7656R&VZ7656H_W-E01_EN www.viconics.com September 2019...
  • Page 4 • Do not drop or crush the Room Controller, or allow it to come into contact with liquids. • Do not use a damaged device (such as one with a cracked screen). Failure to comply with these recommendations will result in damage to the unit and void the manufacturer’s warranty. 028-0323-02_LIT-VZ7656R&VZ7656H_W-E01_EN www.viconics.com September 2019...
  • Page 5: Installation

    Insert screws in mounting holes on each side of the base (fig. 2). Gently swing back the circuit board on the base and push on it until the tabs lock it. Strip each wire 1/4 inch from end. 028-0323-02_LIT-VZ7656R&VZ7656H_W-E01_EN www.viconics.com September 2019...
  • Page 6: Theory Of Operation

    HEORY OF PERATION The VZ765 series uses a Viconics proprietary adaptive logic algorithm to control the space temperature. This algorithm controls the heating and or air conditioning system to minimize overshoot while still providing comfort. It provides exceptional accuracy due to its unique PI time proportioning control algorithm, which virtually eliminates temperature offset associated with traditional, differential-based on/off thermostats.
  • Page 7 Locks out heat pump compressor operation when outside air temperature is below this value. Compressor/auxiliary interlock: • Adds flexibility by locking out heat pump operation during auxiliary heating, to prevent high pressure trip when the coil is downstream of the auxiliary heat source. 028-0323-02_LIT-VZ7656R&VZ7656H_W-E01_EN www.viconics.com September 2019...
  • Page 8: Wireless System Overview

    IRELESS YSTEM VERVIEW Viconics VZ72605x00W Zone Controllers are used in conjunction with the VZ7656x1000W roof top controllers. Combined, they are designed for operating typical; single or multistage RTU’s and their associated local zones. For example, a typical job layout system may feature 3 RTU controllers and a total of 31 zones. This would bring to total number of nodes (individual Com addresses) to 34.
  • Page 9 14 - Scom Scom Reference input for DI 1, RS, OS & DS. 15 - OS Outside air temperature sensor input. 16 - DS Discharge air temperature sensor input. 028-0323-02_LIT-VZ7656R&VZ7656H_W-E01_EN www.viconics.com September 2019...
  • Page 10 C (common) Note 5: The transformer of the unit provides power to the t Terminal Equipment Controller and the additional loads that will be wired to the Terminal Equipment Controller. 10 | 028-0323-02_LIT-VZ7656R&VZ7656H_W-E01_EN www.viconics.com September 2019...
  • Page 11 • Outside air temperature sensing with the sensor installed in the fresh air plenum. • Supply air temperature sensing. Fig.10 – Remote Duct Mounted Temperature Sensor 11 | 028-0323-02_LIT-VZ7656R&VZ7656H_W-E01_EN www.viconics.com September 2019...
  • Page 12: Configuring And Status Display Instructions

    Manual scrolling of each menu item is achieved by pressing the Yes (scroll) key repetitively. The last item viewed will be shown on the display for 30 seconds before returning to automatic scrolling. Temperature is automatically updated when scrolling is held. 12 | 028-0323-02_LIT-VZ7656R&VZ7656H_W-E01_EN www.viconics.com September 2019...
  • Page 13 Mode Status Temperature (if detected) Monday Sys Mode Occupied Outdoor Service 12:00 AM xx.x °C or °F DAS Alrm Sys Mode Unoccupied SetClock Auto Filter Sys Mode Override Comm Lost Cool Sys Mode Heat 13 | 028-0323-02_LIT-VZ7656R&VZ7656H_W-E01_EN www.viconics.com September 2019...
  • Page 14: User Interface

    MENU key. The status display automatically resumes after exiting the user-configuring menu. If the user pauses at any given time during configuring, Auto Help text is displayed to help and guide the user through the usage and configuring of the controller. 14 | 028-0323-02_LIT-VZ7656R&VZ7656H_W-E01_EN www.viconics.com September 2019...
  • Page 15 System mode Schedules Clock setting Resume setting setting Override Sys mode Schedule Clock schd Y/N set Y/N set Y/N set Y/N Appears only in unoccupied mode Cancel ovrd Y/N Appears only in override mode 15 | 028-0323-02_LIT-VZ7656R&VZ7656H_W-E01_EN www.viconics.com September 2019...
  • Page 16 Cooling mode cool Cooling operation mode only Sys mode Heating mode heat Heating operation mode only Sys mode Emergency heat mode ( heat pump models only ) emergenc Forced auxiliary heat operation mode only 16 | 028-0323-02_LIT-VZ7656R&VZ7656H_W-E01_EN www.viconics.com September 2019...
  • Page 17 * Configuring consecutive events to the same time will cause the controller to choose the last event as the time at which it will set its schedule. In the above example, the controller will control the unoccupied set point until 7:00 AM Monday. 17 | 028-0323-02_LIT-VZ7656R&VZ7656H_W-E01_EN www.viconics.com September 2019...
  • Page 18 Sets Event # 4 Unoccupied time Unoccup2 Unoccup2 Unoccup2 To set To set To set Will activate unoccupied 00:00 AM 00:00 AM 00:00 AM value value value setpoints Use ▲▼ to set value, Yes key to confirm 18 | 028-0323-02_LIT-VZ7656R&VZ7656H_W-E01_EN www.viconics.com September 2019...
  • Page 19 Y/N set? Y/N Yes down ↓ Yes down ↓ Yes down ↓ Time Use ▲▼ Use ▲▼ 12/24hrs Use ▲▼ 0:00 Monday 12 hrs To set value To set value To set value 19 | 028-0323-02_LIT-VZ7656R&VZ7656H_W-E01_EN www.viconics.com September 2019...
  • Page 20: Installer Configuration Parameter Menu

    PAN ID This parameter (Personal Area Network Identification) is used to link specific controllers to a single specific Personal Area Network Viconics wireless gateway (VWG / Jace-Driver) or a Identification specific VZ76 RTU controller. For every controller Default value = 0...
  • Page 21 Channel 25 ID 205 Channel 25 ID 205 Channel 25 ID 205 Channel 25 ID 205 Notes: Each system with a VZ76 RTU master will use a unique PAN ID and / or Channel settings. 21 | 028-0323-02_LIT-VZ7656R&VZ7656H_W-E01_EN www.viconics.com September 2019...
  • Page 22 Channel 25 ID 200 Notes: Each controller(s) to use same PAN ID and Channel as VWG Jace-Driver • coordinator. VWG / Jace-Driver supports network integration for required GUI / System / • Status objects. 22 | 028-0323-02_LIT-VZ7656R&VZ7656H_W-E01_EN www.viconics.com September 2019...
  • Page 23 This parameter will select the type of operation required for the RTU based on the size of the system. Please refer Sets how the Zones attached to the Viconics Zoning System Guide for recommended to the RTU controller vote to settings.
  • Page 24 2, 3 or 4 °F ( 1.0 to 2.0 °C ) Units 0 = SI for Celsius / Pa pressure scale. Sets the display scale of the 1 = Imp for Fahrenheit / in. WC pressure scale. controller Default value = Imp 24 | 028-0323-02_LIT-VZ7656R&VZ7656H_W-E01_EN www.viconics.com September 2019...
  • Page 25 Default value = 0.0 °F or °C Cal OS Offset that can be added/subtracted to actual displayed Outside air temperature outside air temperature sensor calibration ± 5.0 °F ( ± 2.5 °C ) Default value = 0.0 °F or °C 25 | 028-0323-02_LIT-VZ7656R&VZ7656H_W-E01_EN www.viconics.com September 2019...
  • Page 26 Default value = -40 °F ( - Function will only be enabled if OS (outside air temperature 40 °C ) sensor) is connected. From -40 °F up to 95 °F ( -40 °C up to 35 °C ) 26 | 028-0323-02_LIT-VZ7656R&VZ7656H_W-E01_EN www.viconics.com September 2019...
  • Page 27 If network communication is lost with the zone controllers, the Return air sensor return air sensor will control the RTC to maintain this setpoint. network lost unoccupied 54 to 100°F (12°C to 37.5°C) cooling setpoint (increments: 0.5° or 5°) Default: 82°F 27 | 028-0323-02_LIT-VZ7656R&VZ7656H_W-E01_EN www.viconics.com September 2019...
  • Page 28 Pressure Bypass damper will maintain this supply static pressure set point. Static Pressure setpoint Please refer to the Viconics Zoning System Guide for Default: 0.8”WC recommended settings. 0 to 2 in WC (0 Pa to 500 Pa) (increments: 0.1” WC or 25 Pa)
  • Page 29 Typically applies when the air handler heat pump coil is installed after the auxiliary heat. ( add on systems ) There is a 2 minute delay to restart the heat pump, when the auxiliary heat is shut down. 29 | 028-0323-02_LIT-VZ7656R&VZ7656H_W-E01_EN www.viconics.com September 2019...
  • Page 30: Specifications

    TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION Please check with your local government for instruction on disposal of this product 30 | 028-0323-02_LIT-VZ7656R&VZ7656H_W-E01_EN www.viconics.com September 2019...
  • Page 31: Drawing & Dimensions

    & D RAWING IMENSIONS Viconics Technologies Inc. 7262 Marconi Street Montreal Quebec Canada H2R 2Z5 (514) 313-8885 1 (800) 563-5660 Tel.: Toll free: sales@viconics.com I www.viconics.com 31 | 028-0323-02_LIT-VZ7656R&VZ7656H_W-E01_EN www.viconics.com September 2019...
