Summary of Contents for Hihome WZB-FLOW
- Page 1 INSTRUCTIONS Hihome WZB-FLOW INSTRUCTIONS Hihome WZB-FLOW...
- Page 2 Wireless transmission protocol: standard Zigbee protocol Wireless transmission distance: open 30M Protection level: IP54 Installation............04 Maximum water pressure range: 0.03~0.8MPA Display: LED indicator Hihome APP ...............08 Button input: silicone button Low voltage alarm: 2.4V alarm, 2.2V forced shutdown Low temperature alarm:5°C 30mm 83mm...
- Page 3 Main function Voice control function: By connecting with Amazon alexa and Google assistant voice speakers, the voice control watering function can be realized. Manual mode: The watering function can be turned on/off through the buttons on the water Zigbee connection: timer.
- Page 4 Install battery Installation Open the battery slide cover. Remove the battery compartment The battery compartment Battery slide cover Install the battery Install the battery slide cover When installing the batter y cover, please pay attention to the up direction as indicated Battery by the arrow.
- Page 5 BS standard/EU-type NH standard/US-type 1/2''Hose Faucet 3/4''Hose Faucet LED indicator Fitting 1/2'' Fitting 3/4'' 1/2'' Adapter *Pairing and networking indicator: Manual switch button for the red and green lights flash alternately. watering device Seal circle Seal circle *Power on: the red light is on for 1s Short press once: open/close the valve Manual control(without WIFI connect or loss connect): watering 10 min.
- Page 6 Hihome APP-Login Download: Click App store or Android application market to download “Hihome Smart” APP. Hihome APP Registration and Login: Click the “Register” to create account. Enter your account password to log in Register Login Create accout...
- Page 7 Link APP Make sure the red light is blinking fast. Enter your wifi account and password Click “ Confirm ” Click “ Next ” Add gateway: xxxxxx Enter the “HOME” interface of the app,Click the “+” in the upper right corner . Click “Done”, it means the wait a few seconds until the search gateway added successfully.
- Page 8 Add Timer Click “Done”, it means ” to enter the device list. Click “ " the Timer " added successfully. the power button Fortimer: long press for 3 seconds. Tips: During pairing, the water timer indicator light flashes red and green alternately Search device..
- Page 9 Set Timed Watering After clicking the right top button, there is a basic information and operation board with several different options: Device Information,Ta-to-Run and Automation and other basic functions and services for the device. Click here to remove Device Click" "to check histor y "to set program Click"...
- Page 10 Delayed watering 10mins Normal Schedule Cycle & Soak This setting means: ever y Monday, This setting means: ever y Monday, Tuesday Tuesday, Wednesday, Thursday at 10:00-16:00 ever y 40 minutes water 10 minutes. 10:00 start watering 20 minutes. Note: when two programming modes are set at the same time, run in the last set Click”...
- Page 11 Irrigation History Restore factory default settings Statistics Irrigation History 05/08 09:34 Duration mins Click ” ”, view your irrigation histor y. Click"Disconnect and wipe data" Click"Remove Device" and re-pair the network to restore factory default settings.
- Page 12 Voice command： After waking up the speaker, you can say: Amazon Alexa Google Assistant * Alexa, open <device name>. Tips:you need connect to the Google speaker * Alexa, close <device name>. * Ok, Google, start <device name>. * Ok, Google, stop < device name>. * Tips: You can name the device yourself...
