BOX-7355-1 Metal Indoor Enclosure
The BOX-7355-1 enclosure provides a rugged and
secure housing for C-7355 Series Time Clocks. The
BOX-7355-1 is a NEMA 1-rated metal enclosure with
conduit knockouts and a window, which allows full
view of the time and On/Off status of the time clock.
Y Y
Steel Construction
Y Y
NEMA 1 Rated
Y Y
Padlock Hole
© 1995 Johnson Controls, Inc.
Part No. 24-7664-443, Rev. —
Code No. LIT-216133
Features and Benefits
Provides a sturdy housing for mounted time clock
Complies with National Electrical Code for line
voltage wiring
Prevents unauthorized access to mounted time
clock
Master Catalog
Clocks Section
Product/Technical Bulletin
Issue Date
Figure 1: BOX-7355-1 Enclosure
125
C
BOX-7355-1
0795
1
