Philips HR1604/09 User Manual

Register your product and get support at
www.philips.com/welcome
EN User manual
LV
BG
PL
CS
RO Manual de utilizare
ET Kasutusjuhend
RU
HR
SK
HU Felhasználói kézikönyv
SL
KK SR
LT Vartotojo vadovas
UK
7
HR1607,
HR1608
HR1607,
HR1608
HR1605,
HR1607,
HR1608
HR1605,
HR1607,
HR1608
HR1606,
HR1608
HR1606,
HR1608
Specifications are subject to change without notice
© 2012 Koninklijke Philips Electronics N.V.
All rights reserved.
HR1604_1605_1606_1607_1608_EEU_UM_V2.0 3140 035 33402
English
1 Important
Read this user manual carefully before you use the appliance, and save the user manual for future
reference.
Danger
Never immerse the motor unit in water or any other liquid, nor rinse it under the tap.
Only use a moist cloth to clean the motor unit.
Warning
Check if the voltage indicated on the appliance corresponds to the local mains voltage before
you connect the appliance.
Do not use the appliance if the plug, the mains cord or other parts are damaged.
If the mains cord is damaged, you must have it replaced by Philips, a service center authorized
If the appliance is damaged, always have it replaced with one of the original type, otherwise
your guarantee is no longer valid.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
Children should be supervised to make sure that they do not play with the appliance.
Do not allow children to use the blender without supervision.
Do not touch the blades or paddle, especially when the appliance is plugged in. The blades are
very sharp.
If the blades or paddle get stuck, unplug the appliance before you remove the ingredients that
block the blades.
To avoid splashing, always immerse the bar into the ingredients before you switch on the
appliance, especially when you process hot ingredients.
Caution
Switch off the appliance and disconnect it from the mains before you change accessories or
approach parts that move during use and cleaning.
Never use any accessories or parts from other manufacturers or that Philips does not
This appliance is intended for household use only.
Do not exceed the quantities and processing times indicated in Fig.2.
Do not process more than 1 batch without interruption. Let the appliance cool down to
room temperature before you continue processing.
Maximum noise level = 85 dB(A)
2 Recycling
Your product is designed and manufactured with high quality materials and components, which can
be recycled and reused.
When you see the crossed-out wheel bin symbol attached to a product, it means the product is
covered by the European Directive 2002/96/EC:
Never dispose of your product with other household waste. Please inform yourself about the local
rules on the separate collection of electrical and electronic products. The correct disposal of your
old product helps prevent potentially negative consequences on the environment and human health.
3 Electromagnetic fields (EMF)
properly and according to the instructions in this user manual, the appliance is safe to use based on
4 Introduction
Philips offers, register your product at www.philips.com/welcome.
For recipes to use with your hand blender, go to www.philips.com/kitchen.
5 Overview
a Button g Chopper gearbox
b Motor unit h Blade unit
c Bar body i Chopper bowl
d Whisk gearbox j Potato masher coupling unit
e Whisk k Potato masher
f Beaker (Depending on Country) l Mashing paddle
6 Before the first use
Thoroughly clean the parts that will come into contact with food before you use the appliance for
Preparing for use
1 Cool down hot ingredients before chopping or pouring into the beaker (max. temperature
80 °C).
2 Cut large ingredients into pieces of approximately 2 cm before processing them.
3 Assemble the appliance properly before plugging it into the wall socket.
1/3
1
HR1604/09
HR1604
HR1605
HR1606
HR1607
a d
HR1608
b
e
HR1607,
HR1608
c f
4
7 Use the appliance
Handblender
The hand blender is intended for:
mixing soft ingredients, e.g. pancake batter and mayonnaise.
pureeing cooked ingredients, e.g. for making baby food.
Chopper
The chopper is intended for chopping ingredients such as nuts, meat, onions, hard cheese, boiled
eggs, garlic, herbs, dry bread and etc.
Caution
The blades are very sharp! Be very careful when handling the blade unit, especially when removing it from the
chopper bowl, when emptying the chopper bowl, and during cleaning.
Note
If the ingredients stick to the wall of the chopper bowl, stop the chopper, and then loosen the ingredients by
adding liquid or using a spatula.
For the best results when processing beef, use refrigerated beef cubes.
Whisk (HR1607 and HR1608)
The whisk is intended for whipping cream, whisking egg whites, desserts etc.
Tip
When you beat egg whites, use a large bowl for the best result.
When you whip cream, use the beaker to avoid splashing.
Potato masher (HR1606 and HR1608)
The potato masher is especially equipped to make potato puree and to mash cooked peas.
Note
Tip
Never use the potato mashing bar to mash ingredients in a pan over direct heat.
Always remove the pan from the heat and let the ingredients cool down slightly before you mash them.
Do not mash hard or uncooked foods, as this may damage the potato mashing bar.
Do not tap the potato mashing bar on the side of the pan during or after mashing. Use a spatula to remove
excess food.
Cook for approx. 20 minutes, drain the potatoes and put them in a bowl.
Add milk little by little and continue until you have achieved the desired result.
8 Cleaning (Fig.6)
Do not immerse the motor unit, the whisk coupling (HR1607, HR1608), the mini chopper lid
(HR1605, HR1607 and HR1608) or the coupling unit of the potato masher in water.
Always detach the accessories from the motor unit before you clean them.
Caution
Unplug the appliance before you clean it or release any accessory.
You can also remove the rubber rings from the chopper bowls for extra thorough cleaning.
For quick cleaning, pour warm water with some washing-up liquid in the beaker, insert the blender bar or potato
masher and let the appliance operate for approximate 10 seconds.
9 Storage
1
Wind the power cord round the heel of the appliance.
2
Put the blender bar, whisk and blade unit in the beaker.
3
Store the appliance in a dry place away from direct sunlight or other sources of heat.
10 Accessories
You can order a direct-driven mini chopper (under service code number 4203 035 83450) from your
Philips dealer or a Philips service centre as an extra accessory for the HR1604, HR1605, HR1606,
HR1607 and HR1608. Use the quantities and processing times of the mini chopper for this accessory.
11 Guarantee and service
If you need service or information or if you have a problem, please visit the Philips website at
go to your local Philips dealer.
12 Baby food recipe
Ingredients Quantity
Cooked potatoes 50 g
Cooked chicken 50 g
Cooked french beans 50 g
Milk 100 ml
Note
Always let the appliance cool down to room temperature after each batch you process.
2
g
h
i
HR1605,
HR1607,
HR1608
j
k
l
HR1606,
HR1608
5
a g
b h
c i
d j
e k
f l
Speed Time
1
2
ON 60 sec
3
3
(MAX)
100-200 g 30 sec
100-400 ml 60 sec
100-500 ml 60 sec
100-1000 ml 60 sec
100 g 5 x 1 sec
120 g (max) 5 sec
20 g 5 x 1 sec
50-100 g (max) 3 x 5 sec
100 g 2 x 10 sec
250 ml 70-90 sec
4 x 120 sec
750 g 1 min
2x2x2 cm
6
1
2
3
<20 sec.
