3:1 High Ratio Oil Pump W. Extn. Kit
OWNER'S MANUAL
WARNING:
Read carefully and understand all
INSTRUCTIONS before operating. Failure to follow the
safety rules and other basic safety precautions may result
in serious personal injury.
Item # 109097

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 109097 and is the answer not in the manual?

Questions and answers

Related Manuals for Northern Industrial Tools 109097

Summary of Contents for Northern Industrial Tools 109097

  • Page 1 3:1 High Ratio Oil Pump W. Extn. Kit OWNER’S MANUAL WARNING: Read carefully and understand all INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item # 109097...

  • Page 2: Intended Use

    Oil pumps can be used to transfer lubrication oil, waste oil and antifreeze liquids. This manual is applicable to the following pump only. Please confirm your pump is included. TECHNICAL SPECIFICATIONS Item No. 109097 Compression Ratio Operating Pressure(bar/psi) 5-8 / 70-115 Max.

  • Page 3: Work Area

    SAVE THESE INSTRUCTIONS WORK AREA Keep work area clean, free of clutter and well lit. Cluttered and dark work areas can cause accidents. Do not use your tool where there is a risk of causing a fire or an explosion; e.g. in the presence of flammable liquids, gasses, or dust.
  • Page 4 power source for this tool. Use proper size and type air pressure line and fittings. The recommended air line for this tool is 1/4”, delivering no more than 115PSI. Recommended air inlet size is 1/4”. Use air hoses rated for safe operation of the tool. Air hoses rated for a maximum of 140PSI or greater must be used with this tool.

  • Page 5: Operation

    TOOL USE and PERSONAL SAFETY When the pump is connected to the compressed air supply: 1. The compressed air must be filtered to avoid dust and moisture into pump 2. The max compressed air pressure must not exceed 0.8Mpa/120PSI (recommended air pressure is 80-95 PSI).
  • Page 6 Wall Installed Part List Code Name Quantity Oil pump Wall bracket Pump adapter Flexible suction hose Suction hose adapter Bung adapter Rigid suction tube Spring circlip Ball Valve seat Filter Proceed As Follows 1. Secure the bracket to the wall using the dowels at about 47” height appropriate for the tank’s dimensions.

  • Page 7: Maintenance

    Proceed as follows 1. Depending on the length of the suction tube the desired extension length. Can be realized by using the modular extension elements (See the examples given above). 2. Example of possible application to pump with drum or rigid suction tube for obtaining personalized lengths according to needs.

  • Page 8: Diagram & Parts List

    Note: The user should perform only routine maintenance operations (such as filters, silencers, cleaning…) with the pump in order not to damage it or compromise its safety. Contact our sales or service center when the pump needs further maintenance. DIAGRAM & PARTS LIST Page 8 of 10...

  • Page 9: Troubleshooting

    Part # Description Quantity Part # Description Quantity Air motor cover Piston connect cover O-ring Suction tube Air motor shell inside Piston shaft Slider Connector Press piece O-ring Screw Spring circlip Small circlip Ball Quick coupling Valve seat Air center cover Filter Silencer Circlip...
  • Page 10 WARNING Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: • lead from lead-based paints, •...
