BCM Advanced Research MX6412J User's Quick Start Card

10th gen intel elkhart lake celeron processor j6412 onboard
Hide thumbs Also See for MX6412J:

Advertisement

Quick Links

10th Gen Intel Elkhart Lake Celeron processor J6412 onboard
User's Quick Start Card
• Inspect the Package:
One
MX6412J Motherboard
One
SATA Signal Cable
One
SATA Power Cable
One
I/O Shield (high profile)
One
I/O Shield (low profile)
• Responsibility:
This manual is provided "As-Is" with no warranties of any kind, it will neither expressed or implied,
including, but not limited to the implied warranties or conditions of this product's fitness for any
particular purpose. In no event shall we be liable for any loss of profits, loss of business, loss of data,
interruption of business, or indirect, special, incidental, or consequential damages of any kind, even
the possibility of such damages arising from any defect or error in this manual or product. We reserve
the right to modify and update the user manual without prior notice.
WARNING: CMOS Battery Damage
Replace your system's CMOS RAM battery only with the identical CR-2032 3V Lithium-Ion coin cell
(or equivalent) battery type to avoid risk of personal injury or physical damage to your equipment.
Always dispose of used batteries according to the manufacturer's instructions, or as required by the
local ordinance (where applicable). The damage due to not following this warning will void your
motherboard's manufacturer warranty.
Perchlorate Material- Special Handling May Apply.
See
http://www.dtsc.ca.gov/hazardouswaste/perchlorate/
ATTENTION: Incorrect BIOS Setup
If you do not know how to handle BIOS setup or how to set it up properly, it is strongly advisable that
you do not modify any of the settings than otherwise instructed in the User's Quick Start Card. Even
a seemingly small incorrect adjustment or modification in the BIOS setup can render your system
unstable or unusable. The incorrect BIOS setup is not covered by your motherboard's manufacturer
warranty.
• Additional Information:
Additional information on setting this board up can be found in the User's Manual in the provided CD-
ROM. The Online User's Manual and FAQ/Knowledge Base can be found on our website by visiting
our website: http://www.bcmcom.com. If your question is not answered in our FAQ/Knowledge
Base, visit our forums and post your messages or submit a new FAQ through FAQ Submittal form for
us to add your question in our FAQ with our answer.
MX6412J
Mini ITX Motherboard
Version 0.01
http://www.bcmcom.com

Advertisement

loading

Summary of Contents for BCM Advanced Research MX6412J

  • Page 1 10th Gen Intel Elkhart Lake Celeron processor J6412 onboard Mini ITX Motherboard User’s Quick Start Card http://www.bcmcom.com Version 0.01 • Inspect the Package: MX6412J Motherboard SATA Signal Cable SATA Power Cable I/O Shield (high profile) I/O Shield (low profile) • Responsibility: This manual is provided “As-Is”...
  • Page 2 WARNING: Electrostatic Sensitive Device (ESD) Static electricity can easily damage your motherboard and will void your motherboard warranty. Keep the motherboard and other system components in their anti-static packaging until you are ready to install them. Touch a grounded surface before you remove any system component from its protective anti-static packaging.
  • Page 3: Motherboard Layout

    Motherboard Layout: • Board Layout: HDR: Front Audio JUMP: COM4 PWR SET HDR: I2C Buzzer HDR: INT_SPK1 Socket / IC: BIOS HDR: Battery HDR: eSPI HDR: Front USB2x2 HDR: SPI HDR: Front USB2x2 HDR: SYS FAN HDR: Clear CMOS HDR: I2S HDR: P80 SET HDR: Front I/O...
  • Page 4 HDR: Board ID Socket: M2 Key E HDR: GPIO Socket: DIMM2 Socket: M2 Key-M Socket: DIMM1 CONN: USB3.0 Jumper: LCD_PWR HDR: COM1 Jumper: PNL PWR HDR: COM2 HDR: BACK Light PWR JUMP: COM1 PWR SET T34 CONN: LVDS JUMP: COM2 PWR SET T35 HDR: CPU FAN HDR: COM3 CONN: SATA0...
  • Page 5 • Back Panel:...
  • Page 6: Pin Signal

    Jumpers, Connectors, & Headers: T1: Front Audio T2: I2C Function Pin Pin Function V_I2C_3P3V I2C_RST_N_3P3V 3P3V_I2C2_SCL 1P8V_I2C5_SCL 3P3V_I2C2_SDA 1P8V_I2C5_SDA I2C_INT_N_3P3V T3: Internal Speaker Signal – DVT/PVT Signal – R01 Audio SPK R- Audio SPK R- Audio SPK R+ Audio SPK R+ Audio SPK L+ Audio SPK L- Audio SPK L1...
  • Page 7 T7: CMOS Pin Signal Name SRTC_RTEST_N 1-2: Normal 2-3: Clear CMOS T10: GPIO Function Function GPIO01 GPIO02 GPIO03 GPIO04 GPIO05 GPIO06 GPIO07 GPIO08 T13,T14: COM1, COM2 Signal Signal 1 COM3_P1_40mils DCD (Data Carrier Detect) 2 NRX3 RXD# (Receive Data) 3 NTX3 TXD# (Transmit Data) 4 NDTR3 DTR (Data Terminal Ready) 5 GND...
  • Page 8 T15,T16,T18,T20: COM Port Power Set Jumper T23: eSPI J_eSPI1 P80H_eSPI_IO0 3VSB P80H_eSPI_IO1 P80H_eSPI_CLKIN P80H_eSPI_IO2 P80H_eSPI_RST0_N R 0 B # 5 3 P80H_eSPI_IO3 SIO_eSPI_CS_N P80H_eSPI_ALT1_N GP_B04_P80_eSPI_ALT1_N R3832 VCC3 R3833 2.0mm 5Pin*2 T24: SPI Function Function 3VSB_SPI SPI_CS0_R_N SPI0_CLK_FLSH SPI0_IO1_MISO SPI0_IO0_MOSI SPI0_IO3_HOLD_N SPI0_IO2_WP_N T25: System FAN Pin1 = GND Pin2 = 12V...
  • Page 9 T26: I2S Function V_I2S_PW HDR_I2S_TXD HDR_I2S_SCLK HDR_I2S_SFRM HDR_I2S_RXD T27: Front Panel T31: LCD Power Jumper...
  • Page 10 T32: Backlight Power Jumper T33: Backlight Connector Pin Signal Description 1 PNL_BL_12V BKLT PWR 12V 2 GND Ground 3 PNL_BKLT_PWR_EN Backlight enable 4 PNL_BKLT_CTRL_PWM Backlight control 5 BKLT PWR 5V BKLT PWR 5V T34: LVDS Connector...
  • Page 11 T35: CPU FAN Pin1 = GND Pin2 = 12V Pin3 = CPU_FAN_TACH Pin4 = CPU_FAN_CTRL T38: 4P DC Power In VIN_12V_24V PW_ATX4P_1 2P*2...
