Ashton MT400 User Manual

SAFETY NOTICES

Please read the instructions below to ensure that you use the product correctly.
Overall
1. Never use alcohol or other chemicals to clean the unit.
2. Handle carefully. Impact may cause damage to the unit.
Battery use
1. Confirm the correct polarity when putting in a new battery.
2. Take out the battery if you are not going to use the unit for an extended period of time.
3. If the unit is operating unusually, please take out the battery and replace after ten seconds.
4. Replace the battery if the LCD display becomes weak.
5. Please dispose of the used battery appropriately.

TUNER DESCRIPTION

FRONT:
1 1
2 2
3 3
4 4
5 5
1. Tuner On Button
2. Pitch (UP)
3. Pitch (DOWN)
4. Mode Button
5. Sound Button
6. Metronome On/
Pause Button
Using The Tuner
Tuning whilst watching the meter (Meter mode).
1. Connect your instrument cable or contact MIC to the tuner's INPUT jack. If you want to use
the internal MIC, do not plug anything into the INPUT jack. The internal MIC cannot be used
when a plug is connected to the INPUT jack.
2. Press TUNER ON button (1). You will enter the meter mode, and the tuning meter will
appear in the display. The upper part of the display will indicate "TUNER" and the most recently
specified calibration (reference pitch) is shown at the left.
3. If you want to change the calibration setting, press PITCH buttons (2) or (3). This setting is
stored when the power is off. Press PITCH buttons (2) or (3) and the calibration setting will
increase or decrease in 1 Hz increments. If you hold down the button, the calibration setting will
change continuously.
4. If you want to change the tuning mode, press MODE button (4). You can then choose a tuning
mode from the selection (Chromatic, Guitar, Bass, Violin or Ukulele). Any instrument can be tuned.
USER MANUAL
11
12
7. Tempo (UP)
8. Tempo (DOWN)
9. Beat Button
10. Value Button
11. Sound Button
12. Metronome On Switch
6
LED:
A
7
8
C
9
10
H G F
LED DISPLAY:
A: A4 (410-490 Hz)
B: Tempo ( 30-280 bpm)
C: Meter Display
D: Beat
E: Value
F: String Number
G: Note
H: Model Display
B
D
E
