Additional Information
Notes on discs
Precautions
If you use the discs explained below, the sticky
residue can cause the CD to stop spinning and
• If your car was parked in direct sunlight
may cause malfunction or ruin your discs.
resulting in a considerable rise in temperature
inside the car, allow the unit to cool off before
Do not use second-hand or rental CDs that have
operating it.
a sticky residue on the surface (for example from
• If no power is being supplied to the unit,
peeled-off stickers or from ink, or glue leaking
check the connections first. If everything is in
from under the stickers).
order, check the fuse.
• If no sound comes from the speakers of a two-
There are paste residue
speaker system, set the fader control to the
Ink is sticky
center position.
•If your car is equipped with a power antenna,
Do not use rental CDs with old labels that are
it will extend automatically while the unit is
beginning to peel off.
operating.
Stickers that are beginning to
If you have any questions or problems
peel away, leaving a sticky
concerning your unit that are not covered in this
residue
manual, please consult your nearest Sony dealer.
Do not use your CDs with labels or stickers
Notes on handling CDs
attached.
A dirty or defective disc may cause sound
Labels are attached
dropouts while playing. To enjoy optimum
sound, handle the disc by its edge. To keep the
disc clean, do not touch the surface.
Notes on moisture condensation
On a rainy day or in a very damp area, moisture
may condense on the lenses inside the CD
player. Should this occur, the unit will not
Do not stick paper or tape on the labeled surface.
operate properly. In this case, remove the disc
and wait for about an hour until the moisture
evaporates.
When you play 8 cm (3 in.) CDs
Use the optional Sony compact disc single
adapter (CSA-8) to protect the CD player from
Do not expose the discs to direct sunlight or heat
damage.
sources such as hot air-ducts, or leave them in a
car parked in direct sunlight where there can be
a considerable rise in temperature inside the car.
Maintenance
Fuse replacement
When replacing the fuse, be sure to use one
matching the amperage rating stated on the
original fuse. If the fuse blows, check the power
connection and replace the fuse. If the fuse
Before playing, clean the discs with an optional
blows again after replacement, there may be an
cleaning cloth. Wipe each disc from the center
internal malfunction. In such a case, consult
out.
your nearest Sony dealer.
Do not use solvents such as benzine, thinner,
commercially available cleaners, or antistatic
spray intended for analog discs.
Fuse (10 A)
Warning
Never use a fuse with an amperage rating
exceeding the one supplied with the unit as this
could damage the unit.
2
Insert a flathead screwdriver between the
Dismounting the unit
bracket and mounting spring. Gently pry
the spring toward the unit while pulling
1
the unit out a little. Repeat on the
Insert the supplied tool between the unit
opposite side and remove the unit.
and the frame, and rotate 90° to release
the hidden mounting spring. Repeat on
the opposite side and remove the frame.
10 mm (
13
/
in.)
32
4 mm (
3
/
in.)
16
90°
Specifications
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC DISTORTION
18 watts per channel minimum continuous average power into
4 ohms, 4 channels driven from 20 Hz to 20 kHz with no more than
1 % total harmonic distortion.
Other specifications
CD player section
General
System
Compact disc digital audio
Outputs
Audio output
system
Power amplifier control
Signal-to-noise ratio
90 dB
Power antenna relay control
Frequency response
10 – 20,000 Hz
Tone controls
Bass ±8 dB at 100 Hz
Wow and flutter
Below measurable limit
Treble ±8 dB at 10 kHz
Laser Diode Properties
Power requirements
12 V DC car battery
Material
GaAs + GaAlAs
(negative ground)
Wavelength
785 ~ 815 nm (Typ.800 nm)
Dimensions
Approx. 178 50 178 mm
Emission Duration
Continuous
(7
1
/
2 7
1
/
8
Laser output power
Less than 0.5 mW*
(w/h/d)
Mounting dimensions
Approx. 182 53
* This output is the value measured at a distance of
1
1
(7
/
4
2
/
8
0.7 mm from the objective lens surface on the
(w/h/d)
Optical Pick-up Block.
Mass
Approx. 1.2 kg (2 lb. 10 oz.)
Supplied accessories
Parts for installation and
Tuner section
connections (1 set)
Optional accessories
Compact disc single adapter
FM
CSA-8
Tuning range
87.5 – 107.9 MHz
Antenna terminal
External antenna connector
Intermediate frequency
10.7 MHz
Design and specifications are subject to change
Usable sensitivity
12 dBf
without notice.
Selectivity
75 dB at 400 kHz
Signal-to-noise ratio
65 dB (stereo),
68 dB (mono)
Harmonic distortion at 1 kHz
0.7 % (stereo),
0.5 % (mono)
Separation
35 dB at 1 kHz
Frequency response
30 – 15,000 Hz
AM
Tuning range
530 – 1,710 kHz
Antenna terminal
External antenna connector
Intermediate frequency
10.7 MHz/450 kHz
Sensitivity
30 µV
Power amplifier section
Outputs
Speaker outputs
(sure seal connectors)
Speaker impedance
4 – 8 ohms
Maximum power output 45 W
4 (at 4 ohms)
Getting Started
Resetting the unit
Before operating the unit for the first time or
after replacing the car battery, you must reset
the unit.
Press the reset button with a pointed object, such
as a ball-point pen.
Reset button
Notes
• Pressing the reset button will erase the clock
setting and some memorized program and
memory functions.
• When you connect the power supply cord to the
unit or reset the unit, wait for about 10 seconds
before you insert a disc. If you insert a disc within
these 10 seconds, the unit will not be reset, and
you will have to press the reset button again.
FM/AM
Compact Disc
Player
in.)
8
Operating Instructions
162 mm
1
6
/
2
in.)
Owner's Record
The model and serial numbers are located on the bottom of the unit.
Record the serial number in the space provided below.
Refer to these numbers whenever you call upon your Sony dealer regarding this
product.
Model No. CDX-1200 Serial No.
For installation and connections, see the supplied installation/connections
manual.
CDX-1200
Sony Corporation
2000
Printed in Japan
Warning
Welcome !
This equipment has been tested and found to
Thank you for purchasing the Sony Compact
comply with the limits for a Class B digital
Disc Player. This unit lets you enjoy a variety of
device, pursuant to Part 15 of the FCC Rules.
features.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment
generates, uses, and can radiate radio frequency
energy and, if not installed and used in
accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to
radio or television reception, which can be
determined by turning the equipment off and
on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the
equipment and receiver.
— Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
— Consult the dealer or an experienced radio/
TV technician for help.
You are cautioned that any changes or
modifications not expressly approved in this
manual could void your authority to operate
this equipment.
CAUTION
The use of optical instruments with this product
will increase eye hazard.
*I-3-043-462-11*
(1)

Advertisement

   Summary of Contents for Sony CDX-1200

  • Page 1

    The model and serial numbers are located on the bottom of the unit. Record the serial number in the space provided below. Refer to these numbers whenever you call upon your Sony dealer regarding this product. Model No. CDX-1200 Serial No.

  • Page 2

    Error displays The following indications will flash for a while. Solution Clean or insert the CD correctly. Press the reset button. because of some problem. If the above-mentioned solutions do not help improve the situation, consult your nearest Sony dealer.
