YOKOGAWA 735454 Series User Manual

User's
Manual
Thank you for purchasing the 735454 Optical Transceiver Module. This manual focuses on the handling
precautions of the 735454.To ensure correct use, please read this manual thoroughly before operation.
Keep this manual in a safe place.
For information on the optical transceiver module, see also the manual of the AQ1300 and AQ1301 (IM
AQ1300-02EN).
Checking the Package Contents
After receiving the product and opening the package, check the following contents before use.
Optical Transceiver Module
XFP Module SFP Module
735454-SR
735454-LR
735454-ER
Name Model or Component Number
Optical Transceiver 735454-SR
Module
735454-LR
735454-ER
735454-SX
735454-LX
Manuals IM 735454-01EN
IM 735454-92Z1
PIM113-01Z2
To Use the Optical Transceiver Module Safely
This product is designed to be used by a person with specialized knowledge. Be sure to follow the safe-
ty precautions listed below. This manual is part of the product and contains important information. Store
this manual in a safe place close to the instrument so that you can refer to it immediately. Yokogawa Test
& Measurement Corporation assumes no liability for the customer's failure to comply with these require-
ments.
The following symbols are used on this product.
Handle with care. Refer to the attached safety information.
Make sure to comply with the precautions below. Failure to do so could lead to damage to the
instrument, injury, or death.
This optical transceiver module is designed specifically for the AQ1300 and AQ1301. Do not
install this instrument in other devices.
French
Ce module d'émetteur-récepteur optique est spécialement conçu pour les dispositifs AQ1300
et AQ1301. Ne pas installer cet instrument dans d'autres appareils.
Note
The SFP module and XFP module are components of the AQ1300/AQ1301. Use the SFP module and XFP module by installing
them into the AQ1300/AQ1301. If you install them in other devices, the product functions and performance are not guaranteed.
Additionally, using these modules voids your warranty.
Model 735454
Optical Transceiver Module
Manuals
IM 735454-01EN(this manual)
735454-SX IM 735454-92Z1
735454-LX PIM113-01Z2
AVERTISSEMENT
6th Edition: December 2021 (YMI)
All Rights Reserved, Copyright © 2014 Yokogawa Test & Measurement Corporation
Printed in Japan
Notes
10GBASE-SR XFP module 850nm
10GBASE-LR XFP module 1310nm
10GBASE-ER XFP module 1550nm
1000BASE-SX SFP module 850nm
1000BASE-LX SFP module 1310nm
This manual.
A manual for China.
List of worldwide contacts
WARNING
IM 735454-01EN 1/2
6th Edition
