For Documentation and Online Support: https://www.resideo.com/us/en/pro/resources
General Information
CELLANT3DBPK supports 30 global cellular frequency bands for 4G LTE, 3G WCDMA and CDMA. It should be
used on installations where the antenna must be mounted at some distance from the communicator. The antenna
is rated for outdoor installations but can also be mounted in attics, plenums and other indoor spaces.
Signal Strength
For reliable service, the communication module should only be installed in locations where there is satisfactory
signal strength. The signal strength value is measured in dBm.
For the VISTA and Safewatch Pro Series controls the signal strength can be viewed on the 7720P Programming
Tool, by using the shift <E> command. The signal strength (green) LED lights steady to indicate satisfactory signal
strength.
For the L3000, L5000, L5210, L7000, QC3ADT, ADT5AIO, ADT7AIO, the signal strength value can be viewed
through ADT 3rd Party Services. Go to https://3ps.adt.com.
For the ADT5AIO, ADT7AIO, ADT2X16AIO and ADTHYBWL the signal strength value can be viewed through ADT
3rd Party Services Party Services and the Alarm.com Mobile Tech Tool. Go to https://3ps.adt.com and
https://alarmadmin.alarm.com/mobile.
dBm is displayed as a negative value. A value closer to 0 represents a stronger signal. (i.e.,
Signal strength of -60 dBm is stronger than that of -100 dBm.)
The CELLANT3DBPK Kit includes the following items:
CELL-EXTCX
MMCX-M to SMA-F Cable (p/n 600-00494V1)
SMA-M to SMA-F Coaxial Adapter (p/n R300-11296)
Cable tie (2) (p/n P3171)
CELL-EXT
u.FL to SMA Cable (p/n 600-00278)
Antenna Cable Removal Tool (p/n 700-03513)
WA7626-CA
SMA to N Cable
Antenna
LTE 50ohm, 100w (p/n 900-03021 with N7197 Bracket OR p/n 900-03137 with 700-05655
Bracket)
Additionally, an RF extension cable is required.
7626-50HC
50ft RF Extension Cable
7626-25HC
25ft RF Extension Cable
7626-5
5ft RF Extension Cable
For the correct cable applicability for your installation refer to the table below:
LTE
ADT-LTE
CELL-EXTCX (600-00494V1)
LTE-L57-V
CELL-EXT (600-00278)
LTE-L57-A
LTEL5V-ADT
LTE-L3A
CELL-EXT (600-00278)
LTEL3A-ADT
LTE-XV
CELL-EXT (600-00278)
LTE-XA
LTE-XC
LTEXV-ADT
LTE-IV
CELL-EXT (600-00278)
LTE-IA
LTE-IC
CELLANT3DBPK Remote Weatherproof Antenna Kit
CABLE
ADT5AIO, ADT7AIO, ADT2X16AIO, ADTHYBWL
L5210, L7000, L5210-CN, L7000-CN, L5000-ADT
L3000, QC3ADT
VISTA-15P/20P128FBP/250FBP, VISTA-15PCN/20PCN/128BPCN,
Safewatch Pro 3000
VISTA-15P/20P128FBP/250FBP, VISTA-15PCN/20PCN/128BPCN
Installation Guide
Panel Compatibility
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for resideo CELLANT3DBPK
- Page 1 For Documentation and Online Support: https://www.resideo.com/us/en/pro/resources General Information CELLANT3DBPK supports 30 global cellular frequency bands for 4G LTE, 3G WCDMA and CDMA. It should be used on installations where the antenna must be mounted at some distance from the communicator. The antenna is rated for outdoor installations but can also be mounted in attics, plenums and other indoor spaces.
- Page 2 WASHER LOCK WASHER SILICON TAPE WRAP SIGNAL LED (Green) ON - Satisfactory Signal OFF - Unsatisfactory Signal cellant3dB-023-V1- Figure 1 – CELLANT3DBPK Remote, Weatherproof Antenna (LTE-X Series shown; see applicable section for connecting to other communication modules) - 2 -...
- Page 3 ADT5AIO/ADT7AIO/ADT2X16AIO Installation Install the antenna 1. Power down the Control Panel. Refer to the NOTE: ROUTE CELL-EXTCX CABLE EXTERNAL ADTLTE Wireless Communication Module THROUGH CASE BACK ANTENNA WA7626-CA Installation Guide for Replacing the Module (P/N ADAPTER CABLE 800-24146). 2. Remove the screw retaining the module (if installed). 3.
- Page 4 L5000ADT, L5210, L7000 Controls Remove the RF Cable from the PC Board Unplug the power supply from the wall outlet, and open the control panel cover. Release the front case from the back case by depressing the two locking tabs at the top of the unit with the blade of a medium size screwdriver.
- Page 5 L3000/QC3ADT Controls Remove the RF Cable from the PC Board Unplug the power supply from the wall outlet, and open RF CABLE the control panel cover. Release the front case from the back case by depressing LTEL3-ADT/ ANT. LTEL3V-ADT the two locking tabs at the top of the unit with the blade of MODULE a medium size screwdriver.
- Page 6 LTEXV-ADT/LTE-X Series Communication Module Remove the RF Cable from the PC Board Power down the system, then loosen the captive cover screw and lift the communicator cover. Locate the RF RF CABLE cable on the module PC Board. ANT. Slip the Antenna Cable Removal Tool (p/n 700-03513) ANTENNA CABLE under RF Cable connector as shown.
- Page 7 LTE-IA/LTE-IV/LTE-IC Communication Module Remove the RF Cable from the PC Board LTE-I SERIES COMMUNICATOR CABLE Power down the system, open the communicator case by pushing in the two bottom tabs with a screwdriver while separating the case front. Locate the RF cable on the LTE-IA/LTE-IV PC Board. cell-ant3db-014-V0 Slip the Antenna Cable Removal Tool (p/n 700-03513) ANTENNA...
- Page 8 REFER TO THE INSTALLATION AND SETUP GUIDE FOR THE CONTROL WITH WHICH THIS DEVICE IS USED FOR WARRANTY INFORMATION AND LIMITATIONS OF THE ENTIRE SYSTEM. This product is manufactured by Resideo Technologies and its affiliates. 2 Corporate Center Drive, Suite 100 P.O.
