Summary of Contents for Orbic SmartWrist

Page 1 User Guide...
Page 2: Table Of Contents
SpO2 Activity Using Fall Detection App Sleep Tracking App Connectivity Installing the Orbic Wear App Orbic Care App Orbic Care Registration App in Orbic Smart Wrist Registration through Smart Watch User Web Portal User Login Home Page Friends and Family...
Page 3 ORBIC CARE FAMILY APP Orbic care settings Proﬁle Software updates Troubleshooting To the Owner Using Your Device Limited Warranty Support And More Additional Information...
Page 4: Overview
Congratulations on your purchase of the Orbic Smart Wrist. Orbic is a brand of products designed to help consumers connect to the things that are important to them. Orbic products offer consumers quality and value combined with up-to-date technology. This user guide will show you how to set up and use your Smart Wrist.
Page 5: Touch Screen And Key Instructions
Power on To turn on the Smart Wrist, make sure that the watch is charged once it is un-boxed and then long-press the button for 3 seconds. You will now see the Orbic logo screen. Power off or Reset Long press the button for 3 seconds, select power off or restart.
Page 6: Control Center
To access the control center of the phone, swipe down the home screen. The new screen with the multiple setting icons is the Control center screen. On top of the screen, the green link shows the paired status with the Orbic Wear App, Network strength, Wi-Fi connectivity and the battery status.
Page 7 Lights up the face of the Smart Wrist for extra light. Do Not Disturb feature mutes all calls, (Do Not Disturb) alerts and notiﬁcations on your Orbic Smart Wrist. Lock Screen Screen lock is used to prevent touch by mistake, And does not respond to...
Page 8: Notifications
To change or edit the watch face, long press on the home screen. User can edit or change the watch face. To customize or add new watch face install the Orbic wear app from iOS App store or Google Play store.
Page 9: Charging The Battery
Charging the Battery Please charge your device fully before turning it on. Follow the steps below to charge the device. 1. Watch 2.Charging Dock 4.Loaded the watch 3. Loading the Watch WARNING: Only use the approved charger docks with your device, incompatible chargers or tampering with the charger port could damage and void the warranty.
Page 10: Esim Activation
If you press the button 3 times continuously, it initiates SOS call auto- matically and send SMS automatic to the emergency contact. Applications Used on Device The SmartWrist is an Android 8. 1 go OS watch, all the applications are similar to an Android smart phone. Phone Orbic Smart Wrist gives users the feature to call from the watch, check the call log.
Page 11: Find Phone 1
Find Phone The Smart Wrist helps you to ﬁnd connected smart phone via Orbic Wear app by ringing the phone. This is a very handy feature. Heart Rate You can record your heart rate any moment using the Heart Rate app. Open the app, wait for Smart Wrist to measure your heart rate.
Page 12: Temperature
Temperature User can check the body temperature anytime using the Smart Wrist. Open the temperature app and wait for the watch to record your temperature. SpO2 The SpO2 app can allow you to measure the oxygen level of your blood on-demand directly from your wrist, providing you with insights into your overall wellness.
Page 13: Activity
Activity User can set different activity modes on the Smart Wrist as per the activity they perform. This tracks your activity and tracks your progress. The watch hosts different modes such as – • Outdoor Running • Brisk Walking • Outdoor Cycling •...
Page 14: Sleep Tracking App
Fall detection SOS Screen This screen is launched upon fall detection if the Fall detection feature is ON. This screen shows the microphone icon if the Voice Assistance feature is ON. User has 3 options to respond to a fall detection event. •Up to 30 seconds, if the user does not respond via voice command or swiping up the screen and if the auto messaging is ON, SOS call and message will be initiated.
Page 15 •By default, Sleep Monitoring is set to OFF Enabling this function will start monitoring your sleep within the set sleep duration. •Time to fall asleep The user can set the start time for the sleep duration. By default, this is set to 22:00hrs for the current date.
Page 16: Connectivity Installing The Orbic Wear App
Connectivity Installing the Orbic Wear App Use the phone to scan the below QR Code to download the Orbic Wear App. Also, QR code will appear the ﬁrst time the device is powered on. Then, follow the setup wizard, you can also ﬁnd the QR code within the QR app on the main menu.
Page 17: Registration Through Smart Watch
Click on the “Register” button to register with Orbic Care Web. Once the email id is registered with the Orbic Care web, user will receive a successful message and a temporary code to their email id to login to Orbic Care web portal.
Page 18: User Login
(check email for the temporary password) that will be used as login information on the Orbic Care platform. If the user is logging in for the ﬁrst time in the website, then it is mandatory to ﬁll their ﬁrst...
Page 19 After submitting the details, user can reset their password. To reset their password user must provide a new password and click ‘Submit’ button for the new password to be saved. Once User has provided the necessary details, he/she will be guided to the login page.
Page 20 Login After successfully registering in the website, User must login by providing their registered email id and password. If the user does not remember the password, they can click “Forgot password?” option. Upon clicking, the user will be navigated to a page where they can type their registered email id and click the “Send code”...
Page 21: Home Page
When the user logs in successfully, they will be navigated to the Home page that displays: Menu on the left-hand side: Home Friends and Family Proﬁle About Orbic Care Contact Us Log out Vitals (Home screen) contains: User details Cards representing each vitals with their values, date, time and icons respectively.
Page 22: Friends And Family
Friends and Family allows user to add a member to their Friends and family list and enable the vitals that can be visible to their members. Hence, we have: Member Settings Orbic care Settings Member settings: Member settings allows users to: Add a new or an existing member.
Page 23: Orbic Care Family App
Once provided, User can click on the “Submit” button to add the member in their Friends and Family list. ORBIC CARE FAMILY APP OrbicCare Family app provides the ability for the family member to access user’s vital information anytime, anywhere. The user of the smart wrist needs to provide access to the family member before information can be shared.
Page 24 Home Screen Home Screen displays: User’s name User’s proﬁle picture Menu option Vitals - Cards displaying all the vitals with icon, values, date and time respectively Vitals Vitals card shows the following : Heart rate SpO2 Body Temperature Sleep Score Fall Detection Watch worn Battery indicator...
Page 25 Heart Rate Heart rate displays the following: SpO2 Spo2 displays the following: Toggle between day, week,month and year to view respective data. Graph that renders data. Max and Min saturation levels with date and time.
Page 26 Body Temperature Body Temperature view is similar to that of SpO2. You can see: Toggle buttons: day, week,month and year to view respecitve data. Graph that renders the data based on user selection. Max and Min Temperature % with date and time. Sleep tracking displays: Date Navigation –...
Page 27 Fall Detection Fall Detection displays: Date Navigation – one week data. Records for heart rate, Spo2 and body temperature Graph My Connections My Connections widget displays all the user’s name with their proﬁle image in individual cards.
Page 28 Change Password Member can update their password by tapping on the ‘Change Password’ menu item availabe on the Settings screen. Terms and Conditions Terms and Conditions Screen provides all the information the member needs to know while using the app. User can view this screen by tapping on the “Terms and Conditions”...
Page 29 Log Out You can Log out of the application by selecting ‘Log Out’ option from the menu items provided. On tapping the option, a pop-up appears asking you to choose either yes or no to logout. If the you tap “Yes”, you will be redirected to the login screen.
Page 30: Orbic Care Settings
Orbic care settings This setting allows the user to enable/disable the vitals that can be observed by their members. Users can enable/disable the following: Heart rate Blood Oxygen Body Temperature Sports Outdoor Running Walking Fitness Exercise Hiking Exercise Cycling Device Worn...
Page 31 Jason Walsh...
Page 32: Profile
Profile Proﬁle displays User’s details: Proﬁle Image - User can upload a proﬁle picture by clicking ‘choose ﬁle’ button. User Detail - It displays the details provided by the user during registration. First name Last name Middle name Email User time-zone Device Information IMEI number User Group...
Page 33: Software Updates
ON, you will have to manually perform the following steps. Open the SETTINGS app and select Apps & Notiﬁcations. Scroll down (You might have to select All Apps) and select Orbic Wear. Click on PERMISSION-> LOCATION and select “Allow all the time”...
Page 34 Software Update Issues • The watch will give a Low Battery message if it is less than 30%. • Download interruptions, you can check the network go to System Updates page to retry. • Install failed, you can go to System Updates page to retry.
Page 35: To The Owner
To the Owner •Some electronic devices, such as the electronic system of vehicles, are susceptible to electromagnetic interference sent by your device if invades- partly shielded. Please consult the manufacturer of your device before using if necessary. •Operating your device may interfere with medical devices like hearing aids and pacemakers.
Page 36: Limited Warranty
Limited Warranty This warranty does not apply to defects or errors in the Product caused by: •Reasonable abrasion. •End User’s failure to follow device provider installation, operation or main- tenance instructions or procedures. •End User’s mishandling, misuse, negligence, or improper installation, disassembly, storage, servicing or operation of the Product.
