Penetrative Tilt Legs Code-Compliant Planning and Installation Guide V 5.1 Complying with AS/NZS1170.2-2011 AMDT 2-2016 Last Updated - Apr. 2022...
Installation Guide / SolarRoof Tilt Legs Introduction The installer is solely responsible for: The Clenergy PV-ezRack® SolarRoof Tilt Legs has been developed as a universal PV-mounting system for roof-mounting on pitched and flat roofs. The use of • Complying with all applicable local or national...
Installation Guide / SolarRoof Tilt Legs Planning Determine the wind region of your installation site Region Definition Wind regions are pre-defined for the whole of Australia by the Australian Standard 1170.2. The Wind Region is an independent factor of surrounding topography or buildings. •...
Page 4
Determine Roof slope and Tilt Leg Angle The PV-ezRack® SolarRoof Tilt Legs system is suitable for roof slope up to 22° for rails running perpendicular to the roof slope (including standard and reverse tilt), and up to 10° for rails running parallel to the roof slope. See the diagrams of 3 different scenarios below.
Page 5
Installation Guide / SolarRoof Tilt Legs Standard Tilt – Rails perpendicular to Roof Slope Reverse Tilt – Rails perpendicular to Roof Slope Standard Tilt – Rails parallel to Roof Slope - Planning - Code-Compliant Planning and Installation Guide V 5.1 - Complying with AS/NZS1170.2-2011 AMDT 2-2016...
Page 6
Installation Guide / SolarRoof Tilt Legs Determine the Installation Area of Roof There are 4 different roof zones for tilt leg installation: Internal Zone, Intermediate Zone, Edge Zone and Corner Zone. Please see diagrams and steps below to define area of each zone. Step 1.
Page 7
Installation Guide / SolarRoof Tilt Legs Determine Two Screws or One Screw Installations of Tilt Legs There are options of using two screws or one screw for installations of adjustable and fixed tilt legs, depending on the project details, like required support spacing, purlin spacing, rib spacing of roof sheet and so on. Please find both two screws and one screw engineering certificates at the end of installation guides for max support spacing.
Page 8
Installation Guide / SolarRoof Tilt Legs - Planning - Code-Compliant Planning and Installation Guide V 5.1 - Complying with AS/NZS1170.2-2011 AMDT 2-2016...
Page 9
Installation Guide / SolarRoof Tilt Legs - Planning - Code-Compliant Planning and Installation Guide V 5.1 - Complying with AS/NZS1170.2-2011 AMDT 2-2016...
Page 10
Installation Guide / SolarRoof Tilt Legs - Planning - Code-Compliant Planning and Installation Guide V 5.1 - Complying with AS/NZS1170.2-2011 AMDT 2-2016...
Page 11
Installation Guide / SolarRoof Tilt Legs (10) - Planning - Code-Compliant Planning and Installation Guide V 5.1 - Complying with AS/NZS1170.2-2011 AMDT 2-2016...
Page 12
Installation Guide / SolarRoof Tilt Legs (11) (12) - Planning - Code-Compliant Planning and Installation Guide V 5.1 - Complying with AS/NZS1170.2-2011 AMDT 2-2016...
Page 13
Installation Guide / SolarRoof Tilt Legs (13) (14) - Planning - Code-Compliant Planning and Installation Guide V 5.1 - Complying with AS/NZS1170.2-2011 AMDT 2-2016...
Page 14
Installation Guide / SolarRoof Tilt Legs (15) - Planning - Code-Compliant Planning and Installation Guide V 5.1 - Complying with AS/NZS1170.2-2011 AMDT 2-2016...
Installation Guide / SolarRoof Tilt Legs System Overview Overview of PV-ezRack® SolarRoof Adjustable Tilt Legs Adjustable Tilt Legs ② ① ⑤ ③ ④ ⑥ 1. End Clamp 2. Inter Clamp 3. Grounding Clip 4. ECO-Rail 5. Grounding Lug 6. Adjustable Tilt Legs Adjustable Tilt Legs with L-feet ②...
Page 17
Installation Guide / SolarRoof Tilt Legs Fixed Tilt Legs ② ① ⑤ ③ ⑥ ④ 1. End Clamp 2. Inter Clamp 3. Grounding Clip 4. ECO-Rail 5. Grounding Lug 6. Fixed Tilt Legs Precautions during Stainless Steel Fastener Installation Improper operation may lead to deadlock of Nuts and Bolts. The steps below should be applied to stainless steel nut and bolt assembly to reduce this risk.
Page 18
Installation Guide / SolarRoof Tilt Legs Safe Torques Please refer to safe torques defined in this guide as shown in the figure below. If power tools are required, Clenergy recommends the use of low speed only. High speed and impact drivers increase the risk of bolt galling (deadlock). If deadlock occurs and you need to cut fasteners, please make sure that there is no load on the fastener before you cut it.
Page 19
Installation Guide / SolarRoof Tilt Legs 2) Adjustable Tilt Legs with L-feet Note: Grounding Z Module, External Teeth Lock Washers, Spring washer and corrugated shim (with pins) on the diagram above are to create the electrical continuity between rail and rear leg tubes. 3) Fixed Tilt Legs Note: Grounding Z Module,External Teeth Lock Washer and Spring washer on the diagram above are to create the...
Installation Guide / SolarRoof Tilt Legs Installation Instructions Front & Rear Leg Installation Front Leg Installation According to the installation plan, determine the mounting position and direction of the front legs. Either two screws or single screw (Buildex 14-11 x 70 Hex Head Zips screw) is required depending on the installation spacing requirement. See two screws and single screw options in Figures 1 and 2.
Page 21
Installation Guide / SolarRoof Tilt Legs Rear Leg Installation According to the installation plan, after confirming the length L of the Rear Leg, fasten two M8*12 bolts as shown in Figure 4. Recommended torque for M8*12 bolts is 18~20 N·m Figure 4 According to the installation plan, either two screws or single screw (Buildex 14-11 x 70 Hex Head Zips screw) is used to install rear leg.
Page 22
Installation Guide / SolarRoof Tilt Legs Install the remaining Front and Rear Legs in Figure 10. NOTE: WHEN USING TIN INTERFACES FOR INSTALLATION WORKS, SCREWS NOT EXPOSED TO FREQUENT RAIN SHOULD BE WASHED DOWN WITH FRESH WATER AT LEAST EVERY 6 MONTHS TO MEET THE WARRANTY CONDITIONS OF BUILDEX SCREWS.
Page 23
Figure 15 PV Module Installation 1) Please refer PV-ezRack® Grounding System for PV modules clamps and grounding lugs installations. 2) The installers must ensure panel clamps are installed flush mounted to the panel frame and apply correct torque value of clamp fastener as shown in section "Safe Torques (P17)".
Installation Guide / SolarRoof Tilt Legs Certification 05 October 2021 Clenergy Australia 1/10 Duerdin Street Clayton, VIC 3168 CERTIFICATION LETTER Clenergy PV ez‐Rack penetrative tilt Certification – TC2, 2.5, 3 – Wind Region A, B, C, D. Project No.: CL‐530‐S‐REV1. Internal REF: 00400. MW Engineering Melbourne, being Structural Engineers within the meaning of Australian regulations, have calculated the maximum spacings for the PV ez‐Rack rail system for the following conditions: ‐ Wind Loads to AS 1170.2‐2011 AMDT 4‐2016 o Wind Terrain Category 2, 2.5 and 3 o Wind average recurrence of 200 years ...
Page 25
Installation Guide / SolarRoof Tilt Legs STRUCTURAL DESIGN CERTIFICATION PV-ezRack® SolarRoof penetrative tilt interface spacing tables according to AS/NZS 1170.2:2011 Amdt 4-2016 Within Australia Terrain Category 2, 2.5 & 3 Client: Clenergy Australia REF: 00400 Date: OCT 2021 Copyright: The concepts and information contained in this document are the property of MW Engineering Melbourne.
Page 28
Installation Guide / SolarRoof Tilt Legs PV ez-Rack SolarRoof Interface spacing table for penetrative tilt legs Type of Rail ER-R-ECO (see Note 12 for other compatible rails) Solar Panel Dimension 2 m x 1 m (see Note 25 for other panel sizes) Terrain Category Angle against horizontal <...
Page 29
Installation Guide / SolarRoof Tilt Legs PV ez-Rack SolarRoof Interface spacing table for penetrative tilt legs (Cont.) Type of Rail ER-R-ECO (see Note 12 for other compatible rails) Solar Panel Dimension 2 m x 1 m (see Note 25 for other panel sizes) Terrain Category Angle against horizontal - 20°...
Page 30
Installation Guide / SolarRoof Tilt Legs PV ez-Rack SolarRoof Interface spacing table for penetrative tilt legs (Cont.) Type of Rail ER-R-ECO (see Note 12 for other compatible rails) Solar Panel Dimension 2 m x 1 m (see Note 25 for other panel sizes) Terrain Category Angle against horizontal - 30°...
Page 31
Installation Guide / SolarRoof Tilt Legs PV ez-Rack SolarRoof Interface spacing table for penetrative tilt legs Type of Rail ER-R-ECO (see Note 12 for other compatible rails) Solar Panel Dimension 2 m x 1 m (see Note 25 for other panel sizes) Terrain Category Angle against horizontal <...
Page 32
Installation Guide / SolarRoof Tilt Legs PV ez-Rack SolarRoof Interface spacing table for penetrative tilt legs (Cont.) Type of Rail ER-R-ECO (see Note 12 for other compatible rails) Solar Panel Dimension 2 m x 1 m (see Note 25 for other panel sizes) Terrain Category Angle against horizontal - 20°...
Page 33
Installation Guide / SolarRoof Tilt Legs PV ez-Rack SolarRoof Interface spacing table for penetrative tilt legs (Cont.) Type of Rail ER-R-ECO (see Note 12 for other compatible rails) Solar Panel Dimension 2 m x 1 m (see Note 25 for other panel sizes) Terrain Category Angle against horizontal - 30°...
Page 34
Installation Guide / SolarRoof Tilt Legs PV ez-Rack SolarRoof Interface spacing table for penetrative tilt legs Type of Rail ER-R-ECO (see Note 12 for other compatible rails) Solar Panel Dimension 2 m x 1 m (see Note 25 for other panel sizes) Terrain Category Angle against horizontal <...
Page 35
Installation Guide / SolarRoof Tilt Legs PV ez-Rack SolarRoof Interface spacing table for penetrative tilt legs (Cont.) Type of Rail ER-R-ECO (see Note 12 for other compatible rails) Solar Panel Dimension 2 m x 1 m (see Note 25 for other panel sizes) Terrain Category Angle against horizontal - 20°...
Page 36
Installation Guide / SolarRoof Tilt Legs PV ez-Rack SolarRoof Interface spacing table for penetrative tilt legs (Cont.) Type of Rail ER-R-ECO (see Note 12 for other compatible rails) Solar Panel Dimension 2 m x 1 m (see Note 25 for other panel sizes) Terrain Category Angle against horizontal - 30°...
Page 37
Installation Guide / SolarRoof Tilt Legs General Notes Note 1. This engineering document was designed to cater for most common installation scenarios however, it does not cater for all of them. Contact Clenergy if you are unable to comply with any of the installation specifications listed on this document.
Page 38
Installation Guide / SolarRoof Tilt Legs Note 6. Reduction factors using one screw per tilt leg and depending on the type of tophat, purlin or batten as per the below table Purlin Min. Spacing +/- Spacing +/- Spacing +/- Spacing +/- Purlin Material thickness embedment...
Page 39
1:1999 and AS/NZS 1170.2:2011 Amdt 4-2016. Components Part No. Description ECO-Rail ER-R-ECO/XXXX ECO Rail Splice ER-SP-ECO PV-ezRack Splice for ECO rail PV-ezRack Australian Made Mill Australian Made Mill R-ECO/XXXX/AUMF Finish ECO Rail Black ECO-Rail ER-R-ECO/XXXX/BA Black ECO Rail Black Splice ECO Rail...
Page 40
Installation Guide / SolarRoof Tilt Legs Components Part No. Description Tilt Legs ER-TL-15/30 15°/30° Adjustable Tilt Legs Tilt Legs ER-TL-30/60 30°/60° Adjustable Tilt Legs 10°/15° Adjustable Tilt Legs, Tilt Legs ER-TL-10/15/PS Preassembly 15°/30° Adjustable Tilt Legs, Tilt Legs ER-TL-15/30/PS Preassembly 10°/15°...
Page 41
Installation Guide / SolarRoof Tilt Legs Components Part No. Description Mid Clamp XX Black ER-IC-STXXB Inter Clamp XX Black End Clamp XX Black ER-EC-STXXB End Clamp XX Black Adapter for tilt leg on corrugated Adapter for tilt leg EZ-AD-C110 roofs Black Universal C-U/30/46/BA Black Universal Clamp...
Page 42
Installation Guide / SolarRoof Tilt Legs Note 22. Only hip and gable roofs installations are covered on this certificate. Contact Clenergy if you are planning to install on a different roof type such as curved, multi-span (pitched and saw-tooth), mansard, circular bin, silo, tank, pitched free, troughed free, hypar free, canopy, awning and cantilivered roof.
Page 43
Installation Guide / SolarRoof Tilt Legs Reverse tilt Back leg angle between 30° and 90° ECO – Rail parallel to ribs Back leg angle between 30° and 90° Note 29. Roof Zone definition to be calculated as per below: Step 1. Determine building height (h), width (b) and length (d). Step 2.
Page 44
Installation Guide / SolarRoof Tilt Legs Roof Pitch > 10° Roof Pitch < 10° Flat/Mono – Slope Roof > 10° Flat/Mono – Slope Roof < 10° Example for penetrative tilted systems Wind Region: B Terrain Category: 3 Building height: 5m Roof pitch: 2°...
