Alfa Laval Temperature Transmitter
Safety instructions
This instrument is built and tested ac cord ing to the current EU-direc-
tives and packed in technically safe con di tion. In order to main tain this
condition and to ensure safe op er a tion, the user must follow the hints
and warnings given in this instruction.
During the installation the valid national rules have to be observed.
Ignoring the warnings may lead to severe per son al injury or substantial
damage to property.
The product must be op er at ed by trained staff. Correct and safe
operation of this equipment is de pend ent on proper transport, storage,
installation and op er a tion.
All electrical wiring must conform to local stand ards. In order to prevent
stray elec tri cal radiation, we rec om mend twisted and shielded input
cables, as also to keep power sup ply cables separated from the input
cables. The con nec tion must be made ac cord ing to the connecting
di a grams.
Before switching on the power supply take care that other equip ment
is not af fect ed. Ensure that the supply voltage and the conditions in the
environment comply with the spec i fi ca tion of the de vice.
Before switching off the supply voltage check the possible effects on
other equipment and the processing system.
Electrical Installation
Alfa Laval Temperatur Transmitter with Alfa Laval Transmitter
RTD
2
1
Mounting example of a Alfa Laval Temperature Transmitter
Please refer to the relevant Alfa Laval Temperature Transmitter manual
(page 3 in this document).
4...20 mA (+)
1
2
4...20 mA (-)
M12 plug
TE67Gxxxxxxxxx
R
74 - 03
Installation Manual 5850-026
TE91K020-EN2
Advertisement
Related Manuals for Alfa Laval TE67G Series
Summary of Contents for Alfa Laval TE67G Series
- Page 1 Electrical Installation Alfa Laval Temperatur Transmitter with Alfa Laval Transmitter Mounting example of a Alfa Laval Temperature Transmitter Please refer to the relevant Alfa Laval Temperature Transmitter manual (page 3 in this document). 4...20 mA (+) 4...20 mA (-)
- Page 2 EPDM gaskets supplied with 3-A marked products are conform to 5) Weldings should be grinded to Ra= 0.4 / Ra= 0.8 Sanitary Standard Class I (8% milk fat max.) Alfa Laval Universal Transmitter Safety instructions Application This instrument is built and tested ac cord ing to the current 230 V EU-directives and packed in technically safe con di tion.
- Page 3 (electronic, mechanical, photocopying, recording, or otherwise), or for any purpose, without the expressed permission of Alfa Laval Corporate AB. Alfa Laval Corporate AB will enforce its rights related to this document to the fullest extent of the law, including the seeking of criminal prosecution.
- Page 4 Item Number Overview Temperature transmitter, clamp DN38 (ISO2852)/ClampDN40 (DIN32676) with M12 electrical connection, 4-20 mA output Item no. Description TE67G111051630 Span: 0 to 150°C, sensor length: 50 mm, sensor tip ø6 mm TE67G111101630 Span: 0 to 150°C, sensor length: 100 mm, sensor tip ø6 mm TE67G111151630 Span: 0 to 150°C, sensor length: 150 mm, sensor tip ø6 mm TE67G111201630...
- Page 5 Temperature transmitter, clamp DN38 (ISO2852)/Clamp DN40 (DIN32676) with M12 electrical connection, 4-20 mA output Item no. Description TE67G511051630 Span: -20 to 150°C, sensor length: 50 mm, sensor tip ø4 mm TE67G511101630 Span: -20 to 150°C, sensor length: 100 mm, sensor tip ø4 mm TE67G511151630 Span: -20 to 150°C, sensor length: 150 mm, sensor tip ø4 mm TE67G511201630...
- Page 6 Temperature transmitter, clamp DN38 (ISO2852)/Clamp DN40 (DIN32676) with M12 electrical connection, 4-20 mA output Item no. Description TE67GC11051630 Span: -10 to 100°C, sensor length: 50 mm, sensor tip ø3 mm TE67GC11101630 Span: -10 to 100°C, sensor length: 100 mm, sensor tip ø3 mm TE67GC11151630 Span: -10 to 100°C, sensor length: 150 mm, sensor tip ø3 mm TE67GC11201630...
