Page 1: Table Of Contents
Table of contents Product introduction Points requiring attention during use Introduction of main parts 1 Packing list 2 Introduction of host functional interface 3 Remote control 4 Connection to other equipment 5 Use of battery Basic operation 1 Turn it on 2 Play video/audio files Advanced operation 1 Display brightness adjustment... -
Page 2: Product Introduction
Product introduction Video-55 is a video/audio player used along with iPod ® 5G 30G/60G. It is equipped with a 7" high-definition LCD unit, a high-performance audio speaker system, a fully functional IR remote control, USB interface, and video/audio input/output interfaces. This system can be used to view movies, pictures, or other video files played by iPod ®... - Page 3 the body of the device. When using a cleaning cloth containing a chemical, please carefully read the use instructions for the cleaning cloth. Please unplug the power cord when cleaning the device. When cleaning the liquid crystal display unit, please use a piece of soft, dry cloth (such as lens cleaning cloth).
-
Page 4: Introduction Of Main Parts
H T U U T H THIS CLASS B DIGITAL APPARATUS COMPLIES WITH CANADIAN ICES-003. Sonic Impact Technologies LLC ©Sonic Impact Technologies LLC 2555 State Street Video-55 is a trademark of Sonic San Diego, California 92101 Impact Technologies LLC iPod®... -
Page 5: Introduction Of Host Functional Interface
2 Introduction to host functional interface 1 Speaker, The device is equipped with two 1.25" full-frequency titanium alloy cone speakers, one at each end, to provide high-quality audio performance. 2 Functional interface gate, with video output, video input, audio input, external power interface and "USB"... - Page 6 1 Rubber anti-wear pad: Protect the device from wear 2 Liquid crystal display screen: 7-inch, 16:9 3 Speaker port holes 4 + Key: 1. Total volume-up control key: the volume of the device will gradually increase when "+" is pressed; 2. After entering the "MENU" parameter-adjusting menu, the analog parameter on the screen will gradually increase when the "+"...
-
Page 7: Remote Control
1 Bottom rubber pads: Protect the device from wear 2 Rechargeable battery compartment gate 3 Main unit label sticker 4 Main unit label 3 Remote control ATTENTION: To avoid damage, please do not throw, step on, or hit the remote control. - Page 8 Please remove the plastic film between the remote control battery and the metal spring contacts before using the remote control. ATTENTION: In order to prevent the remote control lithium-ion battery from leaking, please remove the battery from the remote control if the remote control will not be used for a long period (for example, one month or longer).
-
Page 9: Connection To Other Equipment
key: Same as that on the main unit key: Video-55 pause key/play key: Press " pause key: Same as that on the main unit key: Fast-forward key for iPod ® 5G player: When playing songs, press " to the next song. Hold down the " "... - Page 10 Diagram illustrating connection to external speaker Diagram illustrating connection to PC Data communication between "PC" and iPod ® 5G can be realized through the "USB" interface.
- Page 11 Diagram illustrating connection to video input equipment Diagram illustrating connection between power adapter and external power supply ATTENTION: Please place the device in a stable location when making the electrical connection. Avoid short-circuits at the charging terminals of the device and the adapter.
-
Page 12: Use Of Battery
5 Use of battery A rechargeable lithium-ion battery is used in this device. Please operate as described below. Charge the battery a. Connect adapter to the "DC IN" socket of this device. b. Plug the power adapter into an AC power outlet. ·... - Page 13 e. The battery should be stored at a temperature of 15-25°C. Please do not expose the battery to excessively low or high temperatures. Please do not store the battery in a dusty environment. f. If the battery is to be stored for a long time, it is recommended to charge/discharge the battery once every year.
-
Page 14: Basic Operation
Special reminders: Because of the intrinsic properties of lithium-ion batteries, please note the following: a. When disposing of a defective or old battery, please apply adhesive tape to the terminals and dispose of the battery according to local regulations. b. In order to prolong the service life of the battery, please do not charge the battery frequently in an intermittent way. -
Page 15: Play Video/Audio Files
c. If the "HOLD" key on the keypad is in the locked position, please release the "HOLD" key and press the "POWER" key. If the "HOLD" key is in the released state, press the "POWER" key directly to turn on the device. - Page 16 ATTENTION: When the "30pin" interface of the Video-55 is corrected to an iPod ® that is on, the Video-55 cannot play signals output from the video/audio player connected to the "AV IN" interface. It is necessary to select and confirm "VIDEO"...
-
Page 17: Advanced Operation
on the iPod ® control panel cannot control the volume of this device. b. Other video/audio players When this device is playing, the volume is adjusted using "+," "–" keys. The volume keys on the video/audio equipment connected to this device have the same functions. 3 Turning it off Standby status If the "POWER"... -
Page 18: Display Brightness Adjustment
1 Display brightness adjustment a. Press the "MENU" key on the control panel or the remote control to display the VIDEO MENU." b. Select "BRIGHTNESS" using the " , " keys on the control panel or the remote control. The selected item will have a different color from the unselected items. -
Page 19: Display Sharpness Adjustment
3 Display sharpness adjustment a. Press the "MENU" key on the Video-55 control panel or remote control to display the VIDEO MENU." b. Select "SHARPNESS" using the " , " keys on the Video-55 control panel or remote control. The selected item will have a different color from the unselected items. -
Page 20: Display Language
5 Display language a. Press the "MENU" key on the Video-55 control panel or the remote control to display the VIDEO MENU." b. Select "LANGUAGE" using the " , " keys on the Video-55 control panel or remote control. The selected item will have a different color from the unselected items. -
Page 21: System Parameters
System parameters 1 Interface DC IN: 9V 2A DC power input terminal AV IN: AV input AV OUT: AV output Earphone output Data terminal: Mini USB socket 2 Specifications Audio system mode 2-channel Power (PMPO) 20 W x 2 Frequency response 200-18 kHz Display screen 7-inch 16:9... - Page 22 Symptom Possible problem The battery of the remote control is discharged There is radio wave Too close to the radio interference transmission tower The display A black screen The power is not turned on screen has is displayed when using an external power problems when the supply.
- Page 23 Symptom Possible problem A blue screen The video/audio file has no is displayed video signal output. The when a device enters blue screen video/audio status within the next two file is played minutes. The device then enters the screensaver mode. The video/audio signal input interface comes loose There is noise...
- Page 24 Symptom Possible problem The audio source has problems. Speaker makes Bad connection crackling noises Speaker makes The volume of the operating crackling system is too high sounds (when connected to a Sound The volume of the Video-55 distortion system is too high Solution Symptom Check whether the iPod ®...
