32 "HD READY LED TV
DVB-T / T2 HD ANALOG AND DIGITAL TERRESTRIAL TUNER
DVB-S / S2 HD SATELLITE TUNER
REPRODUCTION OF MULTIMEDIA CONTENTS VIA USB
COMPATIBLE WITH CI + HD CAM MODULE
MODEL NO.: TVD232/S2 LED
USER MANUAL
New Majestic S.p.A. Via Rossi Martini, 41, 26013 Crema (CR) – Italy
www.newmajestic.com
ASSEMBLED IN EU
Please read this manual carefully before using,
and keep it for future reference.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Majestic TVD232/S2 LED
Summary of Contents for Majestic TVD232/S2 LED
- Page 1 REPRODUCTION OF MULTIMEDIA CONTENTS VIA USB COMPATIBLE WITH CI + HD CAM MODULE MODEL NO.: TVD232/S2 LED USER MANUAL New Majestic S.p.A. Via Rossi Martini, 41, 26013 Crema (CR) – Italy www.newmajestic.com ASSEMBLED IN EU Please read this manual carefully before using,...
-
Page 2: Important Instructions
ASSEMBLED IN EU IMPORTANT INSTRUCTIONS SAFETY INSTRUCTIONS WARNING – TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR SERIOUS PERSONAL INJURY: ● This product shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus. ●... -
Page 3: Accessories
● Connect this product to the power outlet which has protective earth connection. CAUTION- TO REDUCE THE RISK OR PERSONAL INJURY OR PRODUCT/PROPERTY DAMAGE: ● This product is intended solely for non-commercial, non-industrial, personal use as a television. Do not use this product for any other purpose. ●... -
Page 4: Table Of Contents
TABLE OF CONTENTS GETTING STARTED IMPORTANT INSTRUCTIONS...................1-2 ACCESSORIES……….......................2 FEATURES........................4 GENERAL PARTS......................5-6 REMOTE CONTROL.....................7-8 REMOTE CONTROL PREPARATION.................9 BASIC CONNECTION....................10-13 OPERATIONS BASIC OPERATIONS.....................14-18 MAIN MENU......................19-30 FIRST TIME INSTALLATION……..………………….………………………………..………19 DTV MODE.........................20-28 ATV AND OTHER MODES....................28 SATELLITE MODE……………………………………………………………………………..29 PC/VGA MODE........................30 FOR REFERENCE MAINTENANCE........................31 WALL MOUNTING…………………………………………………………………………..31 STAND INSTALLATION…………………………………………………………………………..32 SPECIFICATIONS......................33-34... -
Page 5: Features
FEATURES 32" LED Display With Hotel Lock Support Auto TV Scanning Analogue tuner and DVB-T DVB-S tuner Support EPG (Electric Program Guide) Function Support TELETEXT (Europe) Function Support USB Multimedia Playback Support Multi-languages On Screen Display Support Full Function Remote Control Support HDMI x2, YPBPR, AV, VGA, PC AUDIO Input CI+ (high definition contents playback supported) Support EARPHONE and COAXIAL Output... -
Page 6: General Parts
GENERAL PARTS MAIN UNIT Front View Back View 1. LED display screen 2. Remote control sensor / Power indicator- In standby mode the indicator light will display red color; when switching on the unit the indicator light will display blue color. 3. - Page 7 GENERAL PARTS Back View 1. Power input 2. EARPHONE output terminal 3. HDMI 1/2 input terminal (Note: “ARC” function is enable on HDMI 1 port only!) 4. VGA input terminal 5. PC AUDIO input terminal 6. CI input terminal (CI Plus compatible) 7.
-
Page 8: Remote Control
REMOTE CONTROL 1 STANDBY Set the unit in standby mode; press it again to switch it on. 2 TV/RADIO (DTV) Switch the unit between TV and Radio. 3 RED button 4 GREEN button 5 BLUE button 6 YELLOW button 7 FAV Display the favorite channels list. - Page 9 REMOTE CONTROL Play the next file. INDEX (DTV) Display the Teletext index. Play the previous file. 23 MENU Call out the main menu or return to previous menu. 24 AUDIO Switch the available sound-track. 25 OK Confirm selection. 26 ▲/▼/◄/► Navigation buttons 27 SLEEP Set desired sleep time.
-
Page 10: Remote Control Preparation
REMOTE CONTROL PREPARATION BATTERY INSTALLATION Install the batteries as the following pictures. Be sure + and – terminals are positioned as indicated in the battery compartment (Fig1). SERVICE LIFE OF BATTERIES - The batteries normally last for one year although this depends on how often the remote control is used. -
Page 11: Basic Connection
BASIC CONNECTION ● Ensure all the cables are disconnected from the main unit before connecting to AC power source. ● Read through the instructions before connecting other equipments. CONNECTING TO AC POWER SOURCE To power outlet CONNECT EXTERNAL ANTENNA TO UNIT Install external antenna into antenna jack for best picture. - Page 12 HDMI CONNECTION Use HDMI cable to connect the unit with HDMI cable (Not included) other devices to receive high-definition multimedia signal. Back of DVD/VCR PC/VGA CONNECTION Audio cable (Not included) VGA cable (Not included) Back of PC Use VGA cable and Audio cable to connect the unit with TV or PC, and use this product as a monitor.
- Page 13 AV (COMPOSITE VIDEO) CONNECTION AV cable (Not included) For basic connection, use the composite Audio L/R (white/red) and CVBS (yellow) cable to connect the unit with other devices. Back of DVD/VCR YPBPR CONNECTION AUDIO cable YPbPr cable (Not included) (Not included) Back of DVD/VCR...
- Page 14 COAXIAL CONNECTION Use coaxial cable (not included) to connect the unit with amplifier or other audio decoding devices for coaxial audio signal output. USB CONNECTION USB Memory Device (Not included) INSERT A CI CARD (CI+ or standard) Insert your CI card (Conditional (Not included) Access Module) to watch special digital channels in your area.
-
Page 15: Basic Operations
MAKE SURE ALL THE EQUIPMENTS AND POWER CORD ARE CONNECTED PROPERLY AND THE UNIT IS SET IN CORRECT MODE BEFORE KINDS OF OPERATIONS. BASIC OPERATIONS - Press STANDBY button on the unit or remote control to power ON the unit (indicator will glow blue);... - Page 16 EPG TV GUIDE (FOR DTV MODE ONLY) - Press EPG button on remote control to display program guide. - Press UP/DOWN navigation button to select preferred program - Press LEFT/RIGHT navigation button to switch between left column and right column. When a program is highlighted (cursor moved to Right column): - Press GREEN button repeatedly to set a reminder.
- Page 17 QUICK SELECT When viewing an available channel, press OK button on remote control to enter Channel List menu page. - Press UP or DOWN navigation button to select preferred channel. - Press LEFT/RIGHT navigation button to select a channel group. - Press OK button to confirm selection.
- Page 18 1. PHOTO - Press LEFT/RIGHT navigation button to select Photo in the main menu and press OK button to enter it. - Use navigation buttons to select desired folder or file. - When selecting files, press RED button to enter submenu and you can delete a file accordingly.
- Page 19 - Use navigation buttons to select desired option and press OK to confirm it. - Press EXIT button to return. 3. MOVIE - Press LEFT/RIGHT navigation button to select Movie in the main menu and press OK button to enter it. - Use navigation buttons to select desired folder or file.
-
Page 20: Main Menu
MAIN MENU ● The unit contains different setting menus. Once the initial programming is entered, it will be remained in the memory until change, and the unit can always be operated under the same conditions. ● The settings will be remained in the memory until the settings are changed, even after setting the player to standby mode. -
Page 21: Dtv Mode
DTV MODE - Press the SOURCE button on the unit or remote control to select DTV input source. 1. CHANNEL 1.1 TV menu - Press OK or RIGHT navigation button to enter it. - Use navigation buttons to select DVB-T or DVB-C. 1.2 Auto Tuning - Press OK or RIGHT navigation button to enter it. - Page 22 When “Antenna” is DVB-T: 1.4 DTV Manual Tuning - Press OK or RIGHT navigation button to enter it. - Use LEFT/RIGHT navigation button to select the channel. Then press OK button to start searching. When “Antenna” is DVB-C: 1.4 CADTV Manual Tuning - Press OK or RIGHT navigation button to enter it.
- Page 23 2. PICTURE 2.1 Picture Mode - Press UP/DOWN/LEFT/RIGHT navigation buttons to select an option. Picture Mode: available options: Standard, Mild, Personal, Dynamic. Contrast / Brightness / Colour / Tint / Sharpness: adjustable value: 0-100. NOTE: Contrast, Brightness, Colour and Sharpness are adjustable only when Picture Mode is “User”.
- Page 24 3. SOUND 3.1 Sound Mode - Press UP/DOWN/LEFT/RIGHT navigation buttons to select an option. Sound Mode: available options: Standard, Music, Movie, Sports, Personal. Treble / Bass: adjustable value: 0-100. NOTE: Treble and Bass are adjustable only when Sound Mode is “User”. 3.2 Balance This item is used to adjust the audio output between left and right speaker from -50 to 50.
- Page 25 4. TIME 4.1 Clock It displays current system time when an available channel was saved. 4.2 Time Zone This item is used to select desired time zone. 4.3 Off Time Off Time: available options: Off / Once / Every Day / Mon~Fri / Mon~Sat / Sat~Sun / Sun. Hour / Minute: use navigation buttons to adjust the Hour / Minute when Off Time is not “Off”.
- Page 26 4.7 OSD Timer This item is used to select desired OSD menu duration. Available options: Off, 5/10/15/20/25/30/35 seconds. 5. LOCK - Press RIGHT navigation button and input the factory default password “0000” using number buttons on remote control. - Press UP/DOWN navigation button to select preferred item. NOTE: If you forget the password, please use the universal password “8899”.
- Page 27 5.6 Hotel Model - Press RIGHT navigation button to enter it. - Press UP/DOWN navigation button to move the cursor. - Press LEFT/RIGHT navigation button to select an option. Hotel Mode: turn on/off Hotel Mode. Source Lock: turn on/off the lock of available sources. Default Source: set the default source.
- Page 28 6. SETUP 6.1 Language This item is used to select desired on-screen display language. 6.2 TT Language This item is used to select desired teletext language. 6.3 Audio Language - Press RIGHT navigation button to enter it. - Then you can select desired primary audio language and secondary audio Language. 6.4 Subtitle Language - Press RIGHT navigation button to enter it.
-
Page 29: Atv And Other Modes
6.7 Blue Screen This item is used to turn on/off Blue Screen. The screen background will turn blue at very weak or no signal condition, if Blue Screen is ON. 6.8 First Time Installation This item is used to recall the First Time installation menu. 6.9 Energy Mode This item is used to select Home or Store mode. -
Page 30: Satellite Mode
SATELLITE MODE Tips: ● Connect your Satellite antenna to the LBN terminal first to receive satellite signals. ● Press SOURCE button on remote control to select “Satellite”. 1. Auto Tuning - Press MENU button to call out the main menu. - Highlight “TV”... -
Page 31: Pc/Vga Mode
PC MODE - Connect a personal computer to this unit. - Power on your computer and this unit. - Press SOURCE button on the unit or remote control to select PC-RGB (VGA) input source. - Press MENU button to display the main menu and select “PICTURE” using LEFT/RIGHT navigation button. -
Page 32: Maintenance
MAINTENANCE ● Be sure to press STANDBY button to set the player to the standby mode and disconnect the power plug before maintaining the player. ● Wipe the player with a dry, soft cloth. ● If the surface is extremely dirty, wipe clean with a cloth which has been dipped in a weak soap-water solution and wrung out thoroughly, and then wipe again with a dry cloth. -
Page 33: Stand Installation
STAND INSTALLATION Your TV is packaged with the Stand and the Cabinet separated. Before enjoying this TV, please carry out the Stand Installation according to the instructions below. Step 1 Place the TV faced down on a soft cloth or cushion to prevent the panel from being damaged. -
Page 34: Specifications
SPECIFICATIONS Display Device 32 inch LED HD Ready TV Resolution 1366×768 Pixel Pitch 0.51075(H)×0.17025(V) mm Luminance 180 cd/m (+/-10%) Contrast Ratio 3000:1 Aspect Ratio 16:9 Response Time 8 ms Viewing Angle 178(H)/178(V) Visible Range 697.685(H)×392.256(V) mm Tuner: Analogue tuner PAL (BG/DK/I); SECAM (BG/DK/L) DVBT/T2 and DVB-C HD tuner DVB-S/S2 HD tuner Automatic channel search... - Page 35 Video Input PC-RGB (VGA) Up to 1360×768@60Hz Color System: PAL/NTSC/SECAM CVBS Video Level: 1Vp-p@75ohm YPbPr 480i,480p,576i,576p,720p,1080i,1080p HDMI 480i,480p,576i,576p,720p,1080i,1080p AC 100/240V~ 50/60Hz Operation temperature -5° to 35° Unit dimensions: 73.2 (H) x 43.4 (L) x 6.9 (D) cm Dimensions with stand: 73.2 (H) x 47.4 (L) x 19.6 (D) cm Weight with stand: Approx.
-
Page 36: Troubleshooting
GENERAL TROUBLESHOOTING Check the following points before assuming malfunctions of this unit: Symptom Remedy No power. Insert the power plug securely into the power outlet. No picture. Ensure that the equipment is connected properly. ● Ensure that the equipment is connected properly. ●... - Page 37 INFORMATION TO USERS OF DOMESTIC EQUIPMENT Pursuant to Art. 25, Paragraph 1 of the Legislative Act N. 49 14th March 2014, "Implement of the Directives 2011/65 / EU and 2012/19 / EU concerning the reduction of the use of hazardous substances in electrical and electronic equipment, as well as waste disposal".
- Page 38 Class II, double insulation WEEE Logo (Waste of electrical and electronic equipments) Indoor use = Battery disposal...
