OZ Trampolines OVAL Assembly Instructions Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
OVAL
TRAMPOLINE
ASSEMBLY INSTRUCTIONS

Advertisement

loading
Need help?

Need help?

Do you have a question about the OVAL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for OZ Trampolines OVAL

Summary of Contents for OZ Trampolines OVAL

  • Page 1 OVAL TRAMPOLINE ASSEMBLY INSTRUCTIONS...
  • Page 2 SAFETY TIPS At Oz Trampolines, we are passionate about your family’s safety when using our trampolines and accessories. We have put together a list of safety tips and advice which will help ensure your Oz Trampolines experience is safe, secure and fun.

  • Page 3: Table Of Contents

    WELCOME Thank you for purchasing with Oz Trampolines. We have designed our trampolines to be safe and ensure that the parts last many years in the harsh Australian climate. Our high quality trampolines are designed to give you peace of mind and provide your children with many years of enjoyment.

  • Page 4: Product Inventory

    PRODUCT INVENTORY Trampoline Frame Trampoline Frame Net Top Poles (Curved) (Straight) T-Pieces Net T-Pieces Trampoline Mat Net Bottom Poles U-Shaped Legs Fibreglass Poles Safety Pads Pole Padding Safety Pad Ties Leg Extensions Spring Tool Net Clamps Leg Screws T-Piece Screws Anchor Kit Safety Nets Net Pocket...

  • Page 5: Trampoline Parts

    TRAMPOLINE PARTS Trampoline Size 7x10 8x12 10x15 Trampoline Frame (Curved) Trampoline Frame (Straight) Fibreglass Net Rods Net Top Poles Net Bottom Poles T-Pieces Net T-Pieces Trampoline Mat U-Shaped Legs Safety Pads Pole Padding Leg Extensions Safety Pad Ties Spring Tool Net Clamps Leg Screws T-Piece Screws...

  • Page 6: Frame Assembly

    FRAME ASSEMBLY Step 1 To begin. Arrange the frame parts and frame T pieces as pictured, to ensure all curved parts are in their correct location. Step 2 To connect, place a T-Piece over the larger part of the square tubing. Tip: If hard to place on, stretch the T-Pieces slightly outwards.
  • Page 7 FRAME ASSEMBLY Finished Stage Proceed to screw further tightening each nut and place the screw cap supplied on the thread end. Handy Hint Leave screws a little loose until all frame is together. Then tighten. The last piece of the frame can be tight to get into place. Have a second person or use a wall to apply some resistance against the frame to help it shift into place.
  • Page 8 FRAME ASSEMBLY Legs: Step 2 Connect the U-Shaped piece to the leg extensions. The correct end has one screw hole and should simply slot into place. Secure the legs together with the leg screws provided, and continue this step for each U-Shaped leg. Legs: Step 3 Slot each U-Shaped leg into the T-Pieces and secure with the T-Piece screws, washers, nuts and screw caps.

  • Page 9: Mat Assembly

    MAT ASSEMBLY Step 1 Ensure that you have counted your springs and have the correct amount of springs for your trampoline. Also take note that the end of the spring which looks like the letter C, is the end that hooks into your trampoline frame.

  • Page 10: Safety Pads

    SAFETY PADS Step 1 Lay your safety trampoline pads around the edges of your trampoline, ensuring the black loops are facing down. Step 2 Place the pad tie through the black loop on the pads. Step 3 Loop the tie around the frame and loop the white head through the other end of the tie to secure it to the frame.

  • Page 11: Safety Net

    SAFETY NET Step 1 Lay the trampoline net onto the trampoline and spread out so the trampoline entrance is in the middle of the long side of the trampoline. Tip: Line the net up with leg of the trampoline you wish to have the safety net opening positioned.
  • Page 12 SAFETY NET Step 5a Once all poles are inserted and net T pieces and straps are on, stand each pole up and attach with 2 clamps to the U shape leg as per the picture, noting that the rounder edge of the clamp should be facing outwards. –...
  • Page 13 SAFETY NET Step 7 For the entrance thread the two black straps between the safety padding and the bounce mat. Tie straps to trampoline leg. Do not tie the straps too tight as entrance needs some tolerance. Step 8 Take the entrance elastic tie and loop it through one of the two loops on the bottom side of the entrance flap.

  • Page 14: Net Pocket, Ladder & Anchor Kit

    NET POCKET, LADDER & ANCHOR KIT Net Pocket Connect the net pocket between the two poles of your choice, using the attachments provided. Tip: Place the net pocket close to the entry for storage of children’s shoes etc. Ladder Hook your ladder over the trampoline frame, positioning it at the entrance of the trampoline.
  • Page 15 ACCESSORIES Our Trampoline Basketball Kits are a great addition to your Oz Trampoline. Slam dunk your way to the top and become a basketball champion. Protect bouncers from the harsh Australian sun with our extendable shade roof. (Extends up to 50cm above the top of the net).
  • Page 16 • Free delivery Australia wide* • Round, Oval and Inground trampolines • Easy returns* • Long warranties • Largest range of parts in Oz • High quality - Built to last • Easy claim warranty service • Friendly advice 7 days a week •...
