Targus Control Plus
EN - Introduction
Thank you for your purchase of the Targus Control Plus Presenter Remote. It offers true plug-and-
play capability with no need for software drivers and the 2.4 GHz technology allows for effective
presentations at up to 66'/20m.
Contents
• Control Plus Presenter Remote
• USB-A Stowable Dongle
• 1 x AAA battery
• User Guide
System Requirements
Hardware
• USB-A interface
Operating System
• Windows® 10
• macOS®
• iOS®
• Android™
"App/Programme functionality may vary, please check with your software provider"
Installing the Battery
Insert the supplied battery, making sure the positive (+) and negative (-) ends of the battery match
the polarity indicators inside the battery compartment.
The White LED will light for 3 seconds after correct battery installation.
CAUTION : risk of explosion if the battery is replaced by an incorrect type.
Establishing connection by 2.4G mode
1. Plug the USB-A receiver into any USB-A port on your laptop.
2. The presenter will connect laptop automatically, please follow connect with the laptop if
2.4G mode is not working.
3. Depress "Laser Button and Forward Button" for 3 seconds. The White LED will flash during
pairing.
2
Targus Control Plus
Establishing connection by Bluetooth
1. Enable the Bluetooth setting on your laptop/computer device.
2. Depress "Laser Button + Backward Button" for 3 seconds. The White LED will flash for 3 mins
during pairing.
3. While the White LED is flashing, go to your laptop/computer Bluetooth setting and select "Targus
P067" Bluetooth device name.
4. The Bluetooth presenter is now connected to your laptop/computer and the White LED turns off..
5. If the pairing process takes longer than 3 minutes and the White LED turns off, reinstall battery
and follow step 2.
Power Saving Mode
In order to conserve power and increase battery life time, the presenter will enter power saving
mode automatically after 5 minutes while presenter is motionless. Click on any button to resume to
normal operation, the presenter may take a few seconds to reconnect with your laptop/computer.
Reconnecting the laptop/computer device
The presenter will automatically attempt to reconnect to the most recent device whenever 2.4G
mode or Bluetooth mode when power on or awaken.
Troubleshooting (Bluetooth connection)
• Make sure your presenter power is on.
• Make sure your laptop/computer device Bluetooth is working properly.
• Power indicator light flashing red indicates low battery.
• If your laptop/computer is connected to other Bluetooth devices, you may need to disconnect
some devices before you can connect the presenter.
• If the presenter is still not connecting to your laptop/computer device and you see several "Targus
P067" on Bluetooth device list, you may need to remove all "Targus P067", then hold the combo
button "Laser Button + Backward Button" for 3 seconds to make a new device Bluetooth pairing
connection.
• If the presenter is still not recognized, make sure the correct version of software is installed. Verify
the Windows and Mac OS version for compatibility.
Keys and Functions
Back Button
Laser Indicator LED
Red Laser Button
Forward Button
Single Button /
Operation
Combo Button
Long press button
1
Laser Button
1. Short press
2
2. Long press 1 second
3
Forward Button
3. Long press 1 second again
4
1. Short press
5
2. Long press 1 second
6
Back Button
3. Long press 1 second again
7
Long press Laser Button +
Laser Button +
8
Forward Button 3 seconds
Forward Button
Long press Laser Button +
Laser Button +
9
Backward
Backward Button 3 seconds
USB-A Receiver
Function Description
Show red laser point
Forward page
Play PTT
End PTT
Backward page
Black screen
Resume screen
2.4G wireless mode pairing
or re-pairing
Bluetooth wireless mode
paring or re-pairing
3
