Summary of Contents for PulseAudio PA-EARCX
- Page 1 HDMI AUDIO EXTRACTOR with eARC and ARC PART NUMBER PA-EARCX Extracts audio signals from an HDMI source signal vanco1.com | 800.626.6445...
-
Page 2: Dear Customer
DEAR CUSTOMER Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. THIS PRODUCT IS 100% INSPECTED AND TESTED IN THE UNITED STATES TO VERIFY PERFORMANCE PARAMETERS. -
Page 3: Package Contents
18 Gbps, 4K@60Hz with HDR content, while the second HDMI output is dedicated for extracting ARC/eARC audio. For extracting audio from the latest 4K and eARC components, the PA-EARCX is the perfect solution. HDMI Audio Extractor with eARC Part # PA-EARCX •... -
Page 4: Specifications
SPECIFICATIONS HDMI Compliance ............HDMI 2.0b HDCP Compliance ............HDCP 2.3/1.x Video Bandwidth ............18 Gbps Video Resolution ............Up to 4k2k@60Hz 4:4:4 Color Depth ..............8-bit, 10-bit, 12-bit (1080p@60Hz); 8-bit (4K2K@60Hz YUV4:4:4); 8-bit,10-bit,12-bit (4K2K@60Hz YCbCr 4:2:2/4:2:0 Color Space ..............RGB 4:4:4, YCbCr 4:4:4/4:2:2/4:2:0 HDMI Audio Formats ..........PCM 2.0, LPCM 5.1 / 7.1, Dolby Digital, Dolby Digital plus, Dolby TrueHD, Dolby Atmos, DTS 5.1, DTS ES 6.1, DTS HRA, DTS HD Master, DTS:X ESD Protection.............Human body model —... -
Page 5: Panel Descriptions
Connect to an HDMI display with eARC and/or ARC Note that some displays have a specific HDMI port for ARC/eARC, ensure you plug the HDMI cable from the PA-EARCX to that designated HDMI port. Additionally, some ARC/eARC equipped displays must have the feature activated... -
Page 6: Connect And Operate
However, like all electronic equipment, the PA-EARCX should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit. -
Page 7: Technical Support
TECHNICAL SUPPORT In case of problems, please contact Vanco Technical Support by dialing 1-800-626- 6445. You can also email technical support issues to techsupport@vanco1.com. When calling, please have the Model Number, Serial Number (affixed to the bottom of the unit) and Invoice available for reference during the call. - Page 8 ® Vanco International 506 Kingsland Drive Batavia, Illinois 60510 call: 800.626.6445 | fax: 630.879.9189 visit: www.vanco1.com A brand from Learn more at vanco1.com...
