Summary of Contents for Skullcandy MacGyver

  • Page 2: Table Of Contents

    TABLE OF CONTENT I GENERAL DESCRIPTIONS----------------------------------- Basic Functions---------------------------------------------------- Accessories--------------------------------------------------------- II OPERATION----------------------------------------------------- Button function overview----------------------------------------- Function light overview------------------------------------------- Power on/off-------------------------------------------------------- Mode switch-------------------------------------------------------- Playing MP3 music------------------------------------------------ Equalizer modes-------------------------------------------------- Playing voice recording------------------------------------------ Voice recording---------------------------------------------------- Shortcut keys to recording funtion Volume & music/recording control------------------------------ Deleting music/voice recording--------------------------------- PC connection------------------------------------------------------ Battery power indicator-------------------------------------------...
  • Page 3 III INSTALLATION OF MP3 PLAYER----------------------------- System requirements------------------------------------------------- USB connection------------------------------------------------------- Installation guide------------------------------------------------------ Firmware download--------------------------------------------------- CAUTIONS---------------------------------------------------------- Ⅳ Ⅴ C HANGING THE USB Ⅵ HELPFUL TIPS----------------------------------------------------- Ⅶ PRODUCT SPECIFICATIONS---------------------------------- NOTE-------------------------------------------------------------------- CABLE-----------------------------------...
  • Page 4: I General Descriptions

    GENERAL DESCRIPTIONS Ⅰ Basic Functions 1.Playable music format:MP3 / WMA / ADPCM 2.USB1.1 interface 3.Portable storage disk(USB1.1) 4.Playing order: Sequence, Random, Pause, Resuming 5. Choose between 6.Delete (current track / voice recording) 7.Built in Microphone: ADPCM voice recording 8.Stereo earphone jack:standard φ2.5mm 9.Automatic detecting of battery voltage and power indicator 10.Power saving:...
  • Page 5 13.11 LED lights: MP3 (MP3): lights up/MP3 mode;flashing per second /playing MP3 PLAY REC (voice recording / playing): lights up/playing mode of voice recording;flashing per second/playing voice recording RECORDING (voice recording): lights up/voice record- ing mode;flashing per second/recording POWER (power supply indicator): lights up/power on; off/power off or no power (also as battery power indicator):lights up/full power;...
  • Page 6 JAZZ : lights up / equalizer set as JAZZ mode CLASSIC : lights up / equalizer set as CLASSIC mode RANDOM: lights up / random playing 14.5 buttons: ----working mode (MODE) / power on (ON) / pow- er off (OFF) ----forward (FORWARD) / increase volume (VOLUME+) ----reverse (REVERSE) / decrease volume...
  • Page 7: Accessories

    Accessories MP3 Watch Installation CD USB extension cable Instruction Manual Earphone Plug Converter (2.5mm to 3.5mm) (optional) Charging adapter(optional) Earphone...
  • Page 8: Operation

    Ⅱ OPERATION function light Forward / working mode /power on / increase volume power off play / pause Crown Delete Reverse / decrease volume earphone jack Voice recording microphone Button function overview...
  • Page 9: Function Light Overview

    ROCK JAZZ CLASSIC Function light overview Power indicator / POWER Voice recording / RECORDING Recharging / CHARGE Random playing / RANDOM Play voice recording / PLAY REC...
  • Page 10: Power On/Off

    Power on/off Press button ---- POWER light lights up, power on Press and hold button 3 seconds ----POWER light off, power off ※ Note: default mode when power on : 1) MP3 playing mode, MP3 light lights up. 2) equalizer mode, same as when power off last time 3) play the last track of voice recording once motivated starts from the track stopped at last time.
  • Page 11: Playing Mp3 Music

    MP3 mode (MP3 light lights up) recording mode (RECORDING light lights up) Playing MP3 music (under MP3 mode) Press momentarily ----play, MP3 light flashing Press again light lights up (Random playing starts when RANDOM light lights up.) playing record- RECORDING ing mode (PLAY REC light lights up)
  • Page 12: Equalizer Modes

    Equalizer modes (under music playing mode) Press button momentarily --- switch among the following equalizer modes: ROCK ROCK JAZZ CLASSIC NORMAL ROCK (POP light lights up) (ROCK light lights up) JAZZ CLASSIC JAZZ CLASSIC (CLASSIC light lights up) (JAZZ light lights up) ※...
  • Page 13: Playing Voice Recording

    Playing voice recording Press momentarily ----play, PLAY REC light flashing Press again momentarily---- pause, PLAY REC light lights up Voice recording (under recording mode) Press momentarily----start voice recording (RECORDING light flashing per second) Press again momentarily----stop voice recording (RECORDING light lights up) Shortcut keys to recording funtion playing pause mode or recording pause mode) Press...
  • Page 14: Deleting Music/Voice Recording

    (RECORDING light flashing per 0.5 second within 10 seconds and keeps lighted up after 10 seconds when all tracks deleted.) PC connection 1.Connect the watch to PC through USB cable. 2.Recharging light(CHARGE)lights up, which means the pro- for 2 seconds----delete the...
  • Page 15: Battery Power Indicator

    Battery recharging Recharging is needed when power indicator (POWER light) is flashing per 0.5 second or off. 1)Connect the watch to PC through USB cable or through optional adaptor to AC power for recharging (ref. to Figure Battery recharging') Crown...
  • Page 16 2)Recharging light(CHARGE)lights up ----under recharge 3)Recharging light(CHARGE)lights weakly----slow recharge 4)Recharging light(CHARGE)off----recharge over ※ Note: a)The battery will be recharged slowly when close to full power and the product can work by then. b)No slow recharge is indicated by CHARGE light when re- charged through PC.
  • Page 17: Iii Installation Of Mp3 Pla Yer

    III INSTALLATION OF MP3 PLA YER System requirements IBM compatible personal computer Pentium 166 MHz MMX or faster Windows98SE/ME/2000/XP USB port (Universal Serial Bus) Mac Os X/Mac Os 9.0 64MB RAM or more 20MB free hard-disk space or more 4 x CD-ROM drive or more Accessible to Internet (Recommended) ※...
  • Page 18: Installation Guide

    Installation guide Install the driver MP3 Player: Put the installation CD into CD-ROM Drive and then it will be in- stalled automatically. The following window will pop up: Click Next button and the window below will pop up...
  • Page 19 Click Yes button to continue...
  • Page 20 Select the installation folder and then click Next...
  • Page 21 Click Next to start installation...
  • Page 22 Installation completed...
  • Page 23 Click Finish and restart your PC according to the PC requirement...
  • Page 24: Firmware Download

    Firmware download: 1.Make sure the MP3 player utilities is successfully installed 2.Connect the product to PC 3.Click (start) (program) (MP3 Player Utilities) (Firmware Download) the following window will pop up Click Start and the window below will pop up...
  • Page 25 Click Close to complete the download...
  • Page 26: Ⅳ Cautions

    .Remove the product from any device holding the USB plug itself but not the cable or watch body.Do not overbend the cable in case its broken (ref.to the Figure below) 8.When recharging through the accessorial adapter,make sure to pull out the MP3 watch before pulling out the adapter.
  • Page 27: Ⅴ Changing The Usb Cable

    Ⅴ     Changing the USB Cable: 1. Preparation: Prepare the new USB plug assembly and spare springs for replacement: Spare Springs USB Plug Screwdriver and tweezers(optional)
  • Page 28 2. Unscrew the case: 1) Unscrew the two screws that fix the USB plug assembly. 2) No need to unscrew the case back as picture shows. 3. Lift of the defect USB plug: !) Lift of the defect USB plug in vertical direction as arrow shows.
  • Page 29 4.Place the new USB plug: 1) Place the springs from the plastic package into the four spr- ing holes. 2) Make sure there are springs in all four spring holes. Press the new USB plug onto the case in vertical direction as arrow shows. Make sure it fits well on the case.
  • Page 30 5. Fixing the case: Put back the two screws up on the case to fix new USB plug. The replacement is now finished.
  • Page 31: Ⅵ Helpful Tips

    Ⅵ HELPFUL TIPS Problem Battery low Unable to play MP3 Not standard MP3/WMA files Battery low Unable to download USB cable broken or not music connected properly. Unable to No space for more recording do voice files recording The USB plug not connected No Drive or loose.
  • Page 32: Ⅶ Product Specifications

    Ⅶ PRODUCT SPECIFICATIONS Built in memory: 32MB/64MB/128MB/ 256MB/512MB flash Port: standard USB port Battery: 170mAh/3.7V macromolecule polymer Li-ion recharg- eable battery Recharging time: 2 hours for fully charged Battery playtime: 7 continuous hours with fully charged battery Voice recording time: 2hours/32MB, 4.5hours/64MB, 9hours/128MB, 18hours/256MB,36hours/512MB ...
  • Page 33: Note

    Such modifications could void the Users authority to operate the equipment. 2.If the MP3 watch shuts down and the buttons are not workable, please press to reset. at the same time...
