Summary of Contents for Hortitek UFO LED
- Page 1 UFO LED INSTRUCTION MANUAL...
- Page 2 100W 200W 300W 450W PRODUCT SPECIFICATIONS Product Code M4450 M4455 M4460 M4465 Power 100W 200W 300W 450W Voltage Range/Frequency 100-277V ~ 50/60Hz 120V 0.83A 1.67A 2.50A 3.75A 208V 0.49A 0.98A 1.46A 2.20A 220V 0.46A 0.93A 1.39A 2.09A Current 230V 0.44A 0.89A 1.33A 2.00A...
- Page 3 DIMENSIONS (mm/inch) 100W 200W ∅25 (0.98”) ∅25 (0.98”) 189mm (7.44”) 182mm (7.16”) 63mm (2.48”) 55mm (2.17”) 271 (10.67”) 239 (9.41”) 300W 450W ∅23 (0.91”) ∅30 (1.18”) 240mm (9.45”) 251mm (9.88”) 73mm (2.87”) 80mm (3.15”) 426 (16.8”) 383 (15.1”) CONNECTING MULTIPLE LED FIXTURES Connect the 3.5mm Male Jumper Cable between the Controller and the first UFO Control Box.
- Page 4 hortitek.com...
