- Page 1 QUICK USER GUIDE HUOX 50 AND HUOX SPACE...
- Page 2 HUMANOX is a registered trademark of HUMANOX SOCCER S.A. HUMANOX informs that the HUOX 50 is not a diagnostic medical device. For any medical problem it is important that you have seen or visited your physician and initiated or completed treatment.
- Page 3 HUMANOX You are about to enter HUOX Space, the platform that integrates the HUOX 50 In these pages, we will guide you step by step through the HUOX 50 and we will teach you how to use HUOX Space...
-
Page 4: Table Of Contents
GENERAL DESCRIPTION OF THE HUOX 50 TECHNICAL CHARACTERISTICS HOME QUICK USER GUIDE HUOX 50 CONTENT OF YOUR HUOX 50 KNOW YOUR HUOX 50 HUOX 50 INTERNAL PART 10, 11 TURNING ON YOUR SHIN GUARDS IDENTIFIER/IMEI/MAC NUMBER TURNING OFF YOUR SHIN GUARDS... -
Page 5: General Description Of The Huox
ENERAL DESCRIPTION OF THE HUOX 50 The HUOX 50 are the world's first smart and connected carbon shin guards, capable of collecting more than 50,000 pieces of raw data, and translating them in real time in the form of metrics on the HUOX Space platform. Manufactured with aerospace... -
Page 6: Technical Characteristics
TECHNICAL CHARACTERISTICS Communications networks Frecuency band GSM Quad Band (850/900/1800/1900MHz) Data Transmission Protocol TCP / IPv4 Global Navigation Systems GPS / GLONASS / Galileo / BeiDou / QZSS Connection between Shin guards Bluetooth SENSORS Sensitivity : ±2/±4/±8/±16 g Accelerometer & Gyroscope Angular velocity: ±125/±245/±500/±1000/±2000 dps Extended frequency response of 60 Hz to 20 kHz Microphone... - Page 7 This warning is possible thanks to the body temperature sensor built into the HUOX Before going into the guide of the HUOX 50 smart device and the HUOX Space platform, we must inform you that it is important to have an active subscription to the platform (to check plans and prices visit our website https://humanox.com/) once the...
- Page 8 HUOX 50...
-
Page 9: Content Of Your Huox
ONTENT OF YOUR HUOX 50 Your HUOX 50 set includes a bag to store your shin guards, a charging base, and a USB cable for charging. Carrying bag Charging base HUOX 50 USB Cable for charging NOW YOUR HUOX 50 The HUOX 50 smart shin guards are a sensorized device with real-time connection, equipped with high technology made available to the user. -
Page 10: Huox 50 Internal Part
RIGHT SHIN GUARD It gives us information regarding connectivity with the mobile network and TURN ON LED/ STATUS GPS connectivity Your HUOX 50 will automatically shut down after five minutes of inactivity. The complete shutdown process is described on page 11. -
Page 11: Turning On Your Shin Guards
URNING ON YOUR SHIN GUARDS They must first be charged (page 13 of this guide). Turning on the HUOX 50 is very simple, you just have to hold the shin guard with one hand and, with two fingers of the other hand, tap twice on the inner central part to turn it on. -
Page 12: Turning Off Your Shin Guards
If you add your shin guards through the HUOX Space website, the the name IMEI. If you are adding the HUOX 50 from the APP, this number appears as MIC. The ID identification number appears under the name IMEI. If you are adding the HUOX 50 from the number can be found on both the left and right shin guards. -
Page 13: Charging Base For Your Huox
HARGING BASE FOR YOUR HUOX 50 Your HUOX 50 comes with a charging base and USB cable. For a full charge, the approximate Your HUOX 50 comes with a charging base and USB cable. For a full charge, the charging time is 4 hours. The first time you charge them you will need to leave them for 6 hours. - Page 14 HARGING YOUR HUOX 50 To charge the HUOX 50, you need to note that a USB cable is provided with the delivery of the shin guards. A USB adapter or another source such as a computer can be used as a power source which is not included in your pack.
- Page 15 Then, plug the cable into the power source and charge the HUOX 50 for 4 hours (6 hours for the first time). The charging base adapts to any power source from a USB adapter to a computer, for example. Please note that for the charging process to last four hours you need to use a 3.5 mA charger plug.
- Page 17 HUOX Space is the HUMANOX platform where you can see your metrics for each match or training session. Here you can create a profile and link your HUOX 50 shin guards, as well as follow other users, have them follow you and share your metrics.
-
Page 18: Through The Web
Registering on HUOX Space through the website is very easy. Remember that you need to be a subscriber to be able to see your metrics for each training session or match. Enter the website: https://live.humanox.com. Then click the button “Sign up"... - Page 19 You will find three profiles: player, technical Fill in your personal data. team (coach or physical trainer), environment (parents or followers). Choose the one that applies. After the message "Account successfully Accept the terms and conditions. created" pops up, click "ACCEPT." Click "CREATE AN ACCOUNT"...
-
Page 20: Main Screen
AIN SCREEN From the main screen you will be able to access the 3 HUOX SPACE menu selections Left menu selection: Add and remove shin guards, Start and stop matches, Superior Right Menu: Check your metrics Edit profile Interact with other users Log out Inferior Right Menu: Synchronize your shin... - Page 21 First of all, you need to add your shin guards to your previously registered user. To do this you have to turn them on, wait for the HUOX 50 LED to flash every second and follow the steps described below. Once added, through the APP or web, you will be able to record your matches or training sessions, as long as the HUOX 50 are turned on and they have a GSM and GPS mobile network signal.
- Page 22 Check that the identification number is correct TARTING A MATCH ATTENTION: Before starting the game, make sure that the HUOX 50s are turned on and connected to GPS (two flashes per second). Click in “MY GAMES" Click the green "+"...
- Page 23 Optional, "Check the GPS signal" to see the Optional, check the GPS sign clicking GPS connection at the time. on the “CHECK" button. Click in "RECORD THE MATCH" Click the button "Start match”. At the start of the game, a running timer appears, indicating that the game is recording successfully. As the recording of the match is taking place, the data collected from the HUOX 50s will be collected as metrics in HUOX Space in real time.
- Page 24 HECK YOUR METRICS Once you have recorded your match you can check your metrics by following these steps: Click on "MY GAMES" Choose the match of your preference Example of metrics that are shown on in HUOX SPACE...
-
Page 25: Add Your Shin Guards
HANGING THE DEVICE If for some reason you need changing your device, you first need to unlink the one you are using, and then add a new one as indicated in the "Add your shin guards" section (p. 19 of this guide). Click on the green "+"... - Page 26 Registering with HUOX Space is very easy. All you have to do is follow the steps below. The first thing you need to do is download the HUMANOX APP. We remind you that in order to access your metrics to have an active subscription.
- Page 27 Finally, a welcome screen pops up. Click on the button "Start" YNCHRONISING YOUR SHIN GUARDS By synching your shin guards, you can record your matches or training sessions, as long as the HUOX 50s are switched on and have a mobile network signal. Once you are registered, Introduce the IMEI Click the button...
-
Page 28: Start A Match
TARTING A MATCH ATTENTION: Before starting the match, make sure that the HUOX 50 is turned on and connected to the GPS signal (two flashes per second). Make sure you wear your shin guards in such a way that they do not move and in the correct position for the entire match, to obtain accurate metrics. - Page 29 In case you need to change the device, you must first unlink the one you are using, and then add the new one following the steps indicated in the section "Synchronise your shin guards" (page 25). Click on “Humanox Click on the Wheel Next, a confirmation situated in “my...
- Page 30 OW TO LOG OUT Once you are done working with HUOX SPACE, do not forget to log out. In the screen "My profile", click on the right superior menu Once you are inside the configuration menu, click on "Log out"...
- Page 31 • Use only water. Do not use solvents, alcohols, paints or any other type of chemical product. WARNING • The HUOX 50 is an electronic device that requires connection to a 2G network and is not considered a medical device. Therefore, it should not be used for diagnostic purposes or as a substitute for obtaining measurements that require the use of a laboratory or precision medical device.
- Page 32 • The battery is a fixed element in the electronics of the device that cannot be replaced or modified. The only valid charging method is inserting the shin guard into the charging base provided. • The charging base must be powered by a PS2 source according to the 62368-1 standard. USE RECOMMENDATIONS •...
-
Page 34: Fcc Regulatory Notices
FCC Regulatory notices Humanox Soccer, S.A. has not approved any changes or modifications to this device by the user. Any changes or modifications could void the user’s authority to operate the equipment. INTERFERENCE STATEMENT This device complies with Part 15 of the FCC Rules and Industry Canada licence-exempt RSS standard(s). - Page 35 All products bearing this symbol are waste from electrical and electronic equipment (WEEE according to Directive 2012/19/EU) that should not be mixed with unsorted household waste. Instead, you should protect human health and the environment by handing over your waste equipment to a collection point for the recycling of waste electrical and electronic equipment designated by the government or local authorities.
- Page 36 If you have any questions regarding the operation of the HUOX 50 shin guards and the HUOX Space platform, please contact us: Telephones: +34 956263058 WhatsApp: +34 655092190 Email: atencion.cliente@humanox.com...
