www.MIPonline.com
8-32 Setscrew (x2)
#00-209
Drive Hub,
13mm (x2)
#18111
P/N: 18170
MIP X-Duty™ Instruction Guide
Cross Pin (x2)
#18100
X-Duty Male Drive,
may cause eye/skin
Apply MIP
Thread Lock
For more information
www.miponline.com/store/sds.html
Coupling (x2)
#18100
102mm (x1)
#18107
WARNING!!!
Chemicals in tubes
irriation and can be
harmful if
swallowed. If it
comes in contact
with skin, wash with
plenty of soap and
water. If in eyes;
Rinse with water for
fifteen miniutes. If
irritation persists get
medical advice.
& SDS please visit:
M4 x 12mm Pin
2mm Spacer (x2)
Screw (x2)
#99120
X-Duty Female Drive,
40mm (x1)
#18101
Moore's Ideal Products, LLC
830 W. Golden Grove Way
#2010-0015
© 2021
Covina, CA 91722
Advertisement
Table of Contents
Related Manuals for MIP X-Duty
Summary of Contents for MIP X-Duty
- Page 1 MIP X-Duty™ Instruction Guide www.MIPonline.com 8-32 Setscrew (x2) Cross Pin (x2) Coupling (x2) M4 x 12mm Pin 2mm Spacer (x2) #00-209 #18100 #18100 Screw (x2) #2010-0015 #99120 Drive Hub, X-Duty Male Drive, X-Duty Female Drive, 13mm (x2) 102mm (x1) 40mm (x1)
- Page 2 MIP X-Duty™ Instruction Guide www.MIPonline.com #18107 #18100 #18111 Apply MIP Lube #18100 Align Flat with #2010-0015 Set Screw Face Drive Assembly #00-209 Apply MIP Thread Lock #18100 #18111 Apply MIP Lube #18101 #18100 Align Flat with Set Screw Face #2010-0015 ©...
- Page 3 MIP X-Duty™ Instruction Guide www.MIPonline.com 3.32" [84mm] (40°) 5.53" 6.48" [140mm] [165mm] Drive Limits !!IMPORTANT!! Align Pin Holes! © 2021 Moore's Ideal Products, LLC 830 W. Golden Grove Way P/N: 18170 Covina, CA 91722...
