- Page 1 LIFTKAR PTR POWERED TRACKED STAIRCLIMBER INSTRUCTION MANUAL English...
-
Page 2: Table Of Contents
1 GENERAL SAFETY GUIDELINES ............................2 PRODUCT DESCRIPTION ..............................2.1 Controls - Handle Unit ..............................2.2 Controls - Base Unit ..............................2.3 LIFTKAR PTR – INDIVIDUAL COMPONENTS ........................2.4 TECHNICAL DATA ................................ 2.5 Indicators and Controls ............................. 2.6 Main Dimensions ............................... -
Page 3: Introduction
The LIFTKAR PTR can quickly be dismantled into two handy parts by shifting two levers: the base unit including rechargeable battery weighs approx. 28 kg, the handle unit approx. 11 kg. The LIFTKAR PTR ensures safe handling on the stairs. -
Page 4: General Safety Guidelines
If not avoided, physical injury or damage to property will result. W ARNING - IMMINENT DANGER POSSIBLE If not avoided, death or severe physical injury can result. D ANGER - IMMINENT DANGER If not avoided, death and severe physical injury will result. Liftkar PTR I 4... - Page 5 The LIFTKAR PTR is not designed for travelling extended distances over horizontal surfaces. Do not use the LIFTKAR with a passenger until you have practiced operating it perfectly without a payload. Next, try operating it again with somebody as lightweight as possible who is not disabled.
- Page 6 CAUTION Do not use the LIFTKAR with a passenger until you have practiced operating it perfectly without a payload. Next, try operating it again with somebody as lightweight as possible who is not disabled. The test passenger should hold onto a handrail or a second person during the climb.
- Page 7 Instead, their arms should rest on the armrests or their thighs. DANGER Never operate the LIFTKAR PTR on surfaces that are wet, slippery, polished or waxed, smooth, icy or generally do not give the operator sufficient stability, and impair the adhesion of the stairclimber tracks.
-
Page 8: Product Description
Changes to red if the stairs are too steep (36° - 40°). The speed of the LIFTKAR PTR is reduced automatically. A red light and an acoustic warning go on when the unit is overloaded, or the stairs are too steep. PTR stops. -
Page 9: Controls - Base Unit
2.2 CONTROLS - BASE UNIT The key protects the LIFTKAR PTR against unauthorised use. ON/OFF WARNING Same function as on handle unit. Use only for loading purposes (e.g. stowing in car). DRIVE SPEED Starts the drive chain in the chosen climbing mode. -
Page 10: Indicators And Controls
HANDLE UNIT Key switch ON/OFF - UP/DOWN switch ON/OFF - UP/DOWN switch Multi-function LED – battery status and inclination angle Speed selector switch I / II / III EMERGENCY STOP DC charging socket Activation button Main fuse Liftkar PTR I 10... -
Page 11: Main Dimensions
2.6 MAIN DIMENSIONS SIDE VIEW FRONT VIEW Liftkar PTR I 11... -
Page 12: Start-Up
6 hours depending on the residual charge. The charging socket is located on the back of the base unit (figure 1a). Liftkar PTR is equipped with an inbuilt battery charger. During charging process a LED (figure 1b) which you can find in the left side wall of the... -
Page 13: Detaching The Handle Unit
(figure 4b). 3.5 REMOVING THE HANDLE UNIT Pivot the handle unit forward and pull slightly up- wards. Once the snap- in position is reached the handle releases itself automatically. Liftkar PTR I 13... -
Page 14: Operation
Adjust the headrest and pivot the handle unit back into the operating position. Keep both your hands on the handle unit while you do this. The spring- loaded retention lever automatically moves into its front limit position. Liftkar PTR I 14... -
Page 15: Operation On The Stairs
“UP” (figure 2b). The LED illuminates permanently green. Stand behind the handle unit of the tracked stair- climber as instructed during training by authorised personnel. Press the activation button on the right handle (figure 2c). Liftkar PTR I 15... -
Page 16: Removing The Wheel Chair
Before operating the tracked stairclimber it must be at an angle of 90° to the stairs. 4.2.5 SAFETY CHECK Although the tracked stairclimber is equipped with an angle warning LED, we recommend checking the precise inclination of the stairs before climbing them for the first time. 4.3 REMOVING THE WHEEL CHAIR Liftkar PTR I 16... -
Page 17: Using The Tracked Stairclimber On Level Surfaces
Move UP mode. Pressing the ON/OFF button again switches the unit to the Move DOWN mode. Pressing the ON/OFF button for a longer period switches the unit off. Use the speed selector switch to choose between one of three speed settings. Liftkar PTR I 17... -
Page 18: Tilting Angle Sensor
In the event of an extreme stair angle, the unit stops climbing upstairs. (A warning tone as well as the red illuminated LED signalizes this condition.) It is still possible to move downstairs in creep speed in order to bring the PTR out of the danger zone onto the next landing. -
Page 19: Safety Release System
If the total weight (tracked stairclimber and passenger) is low, the operator will need to support travel down the stairs by pushing in the direction of travel. After usage of the safety release system your LIFTKAR PTR must undergo a complete safety check by an authorised SANO partner. -
Page 20: Disposal
5.2 DISPOSAL The LIFTKAR PTR tracked stairclimber is a durable product. At the end of their useful life, the tracked stairclimber components and charger should be disposed of properly. The tracked stairclimber does not contain any hazardous materials and is fully recycling-compatible. The printed circuit boards and the rechargeable battery must be disposed of using a suitable recycling process. -
Page 21: Recalls And Corrective Actions
If your LIFTKAR PTR is affected by a product recall, you will be informed on what happens next. We recommend that you register your device on our website www.sano-stairclimbers.com/product-registration. -
Page 22: Warranty And Costumer Service
In order to ensure an extended service life of the tracked stairclimber, we recommend having the tracked stairclimber serviced at regular intervals by an authorised SANO dealer. Please contact your SANO dealer for more information. COSTUMER SERVICE Costumer Service: +43 7239 / 510 10 Liftkar PTR I 22... -
Page 23: Warranty And Liability
7.1 WARRANTY The warranty period for the climbing unit and handle unit on all models of the LIFTKAR PTR tracked stairclimber is 24 months. Battery packs have a warranty period of 6 months. In both cases the warranty period starts on the day the product is handed over to the costumer. -
Page 24: Declaration Of Conformity
8 DECLARATION OF CONFORMITY SANO Transportgeraete GmbH takes sole responsibility in declaring that LIFTKAR stairclimbers comply with the following principle requirements the EC Directive for Medical Devices Class I EU2017/745 (MDR) compliance. The Conformity Assessment Procedure according to Annex IX (MDR). -
Page 25: Notes
NOTES Liftkar PTR I 25... - Page 26 Model: Serial No.: Manufacturing date: Date of purchase: Dealer: Liftkar PTR I 26...
-
Page 27: Contact
Bristol Court, Betts Avenue Martlesham Heath Ipswich, Suffolk / IP5 3RY, England Tel. +44 1473 / 333 889 Fax +44 1473 / 333 742 info@sano-uk.com www.sano-uk.com Subject to changes without notice / LIFTKAR PTR 2022-04, REV 04 WWW.SANO-STAIRCLIMBERS.COM Liftkar PTR I 27...
