- Page 1 ROLLING600-800-1000 ROLLING600-800-1000 USER/INSTALLER MANUAL V1.0 REV.062022...
-
Page 2: Table Of Contents
00. CONTENT 01. SAFETY INSTRUCTIONS íNDICE ATTENTION: 01. SAFETY INSTRUCTIONS This product is certified in accordance with European STANDARDS TO FOLLOW Community (EC) safety standards. 02. INFORMATION This product complies with Directive 2011/65/EU of the SECURITY INFORMATION European Parliament and of the Council, of 8 June 2011, on TECHNICAL CHARACTERISTICS the restriction of the use of certain hazardous substances 03. -
Page 3: 01. Safety Instructions
01. SAFETY INSTRUCTIONS GENERAL WARNINGS WARNINGS FOR TECHNICIANS • This manual contains very important safety and usage information. • Before beginning the installation procedures, make sure that you have very important. Read all instructions carefully before beginning the all the devices and materials necessary to complete the installation of installation/usage procedures and keep this manual in a safe place the product. -
Page 4: Information
01. SAFETY INSTRUCTIONS RESPONSABILITY panel, must be provided on the product’s fixed power supply leads in accordance with the installation rules. • Supplier disclaims any liability if: • If the product to be installed requires power supply of 230Vac or 110Vac, •... -
Page 5: Security Information 4A
Output torque Height Bearing Chain External switch: Input weight speed Limit switch Motor Screw • Ground (Yellow/Green) AC-6001P 220 V 410 Nm 600 kg 6.5 rpm 127 mm • Brown AC-8001P 220 V 640 Nm 800 kg 3.7 rpm 152.4 mm •... -
Page 6: Installation And Adjustments
Roll Big gear Bracket Model Distance to centers Length Width Join Circular Plates II to the Roll AC-6001P/6003P 304 mm 515 mm 300 mm AC-8001P/8003P 345.5 mm 580 mm 320 mm Join the two Circular Plates I and shaft to the Roll... -
Page 7: Installation Of The Gear 6A
04. INSTALLATION AND ADJUSTMENTS 04. INSTALLATION AND ADJUSTMENTS INSTALLATION OF THE GEAR CHAIN Fix the door motor to the gear. Make sure the nuts are tight and the chain is vertical position. The Motor is supplied with a chain for manual lifting of the grille. In case of using the chain, make slow movements to move the grille. -
Page 8: Connection Scheme
05. CONNECTION SCHEME CONNECTION TO SWITCH OR CONTROL BOARD SWITCH MC4 EVO (OPTIONAL) MC75 (OPTIONAL) • Included as standard • Control board to work • Control board to work with remote control, only with remote control pushbutton and allows placement of Photocells/Security Systems TIME.P PHOTO... -
Page 9: Maintenance
06. MAINTENANCE Check the door once a month. The door must be working without any defect. Regularly check the limit switches. For assistance, contact a qualified technician. Our company reserves the right to change the design and specifications without prior notice. TROUBLESHOOTING Behavior Procedure...
