The manufacturer Technaxx Deutschland GmbH & Co.KG hereby declares
that this device, to which this user manual belongs, complies with the
essential requirements of the standards referred to the Directive RED
2014/53/EU. The Declaration of Conformity you find here: www.technaxx.de/
(in bar at the bottom "Konformitätserklärung"). Before using the device the
Service phone No. for technical support: 01805 012643 (14 cent/minute from
German fixed-line and 42 cent/minute from mobile networks).
If you drill a hole in the wall, please make sure that power cables, electrical
cords and/or pipelines are not damaged. When using the supplied mounting
material, we do not take the liability for a professional installation. You are
entirely responsible to ensure that the mounting material is suitable for the
particular masonry, and that the installation is done properly. When working at
higher altitudes, there is danger of falling! Therefore, use suitable safeguards.
Keep this user manual for future reference or product sharing carefully. Do
the same with the original accessories for this product. In case of warranty,
please contact the dealer or the store where you bought this product.
Enjoy your product * Share your experience and opinion on one of the
Features
Babyphone with video live view & VOX function to monitor the activities of
your child
2.4G wireless technology with up to 200m transmission distance
(open areas)
audio communication
In- visible infrared lights embedded for 2m night vision range
power off automatically & VOX function (= voice activation) for power saving
Time alert to remind feeding times
privacy protection
out-of-range warning
Technaxx
Video Babyphone TX-118
first time, read the user manual carefully.
Free Email: support@technaxx.de
well-known internet portals.
Built-in microphone and speaker in both units for two-way
Camera can be turned 360° left/right & 45° front/back
Indicators for noise level in baby room
®
* User Manual
Encrypted digital wireless signal for
Warranty 2 years
Screen
Sound alert for
Advertisement
Summary of Contents for Technaxx TX-118
- Page 1 Technaxx * User Manual Video Babyphone TX-118 The manufacturer Technaxx Deutschland GmbH & Co.KG hereby declares that this device, to which this user manual belongs, complies with the essential requirements of the standards referred to the Directive RED 2014/53/EU. The Declaration of Conformity you find here: www.technaxx.de/ (in bar at the bottom “Konformitätserklärung”).
- Page 2 Product Overview (V1.0) Camera front Camera rear Light sensor Indicator LED Lens Speaker Infrared LED Pair Key Microphone Power Adapter Socket Power Key / Volume adjustment Monitor front Monitor rear Indicator for external power Key for Zoom / Answer / Paring adapter / Exit key Up / Increase volume...
-
Page 3: Operation And Use
Operation and use Turn on / Turn off Camera: Press power to turn on the device. Press and hold at least 3 seconds to shutdown the device. Monitor: Press power to turn on the device. Press and hold at least 3 seconds to shutdown the device. Pairing It is required to pair the units before using. - Page 4 Answering (on the monitor) Press and hold the talkback button of monitor and talk. You can hear the sound at the camera side. The user will not hear the sound from the camera side during talkback operation until the button is released. Note: After pressing and holding the talkback button wait until the microphone on the top of the monitor is shown before you start speaking.
- Page 5 Screen backlight mode Click the OK/Menu button under real-time monitoring status (menu main interface). Select Screen Display. Select LCD Backlight Time (there are 5 different levels): Keep On, 10 Seconds, 30 Seconds, 1 Minute, 3 Minutes. Select “Keep On” the monitor does not switch off. If one of the time levels is selected, the monitor will switch off after the selected time.
- Page 6 The sound activates the monitor. As long as the voice sensor detects a sound the Voice sensor Backlight monitor is active. If sound does not exceed low, middle or keep on the sensitivity setting limit, the monitor is high active for another 10 seconds before turning off.
-
Page 7: Technical Specifications
Do not disposal old devices or batteries into the domestic waste. Cleaning: Protect the device from contamination and pollution (use a clean drapery). Avoid using rough, coarse-grained materials or solvents/aggressive cleaner. Wipe the cleaned device accurately. Distributor: Technaxx Deutschland GmbH & Co.KG, Kruppstr. 105, 60388 Frankfurt a.M., Germany...
