Summary of Contents for Sharp Aquos LC-13B2UB
- Page 1 LC-13B2UB LC-15B2UB LC-20B2UB LIQUID CRYSTAL TELEVISION TÉLÉVISEUR ACL TELEVISOR CON PANTALLA DE CRISTAL LIQUIDO TELEVISOR DE CRISTAL LÍQUIDO OPERATION MANUAL MODE D’EMPLOI MANUAL DE MANEJO MANUAL DE OPERAÇÃO PO WE R SL EE P...
-
Page 2: Operation Manual
DO NOT OPEN. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. LC-13B2UB LC-15B2UB LC-20B2UB ENGLISH OPERATION MANUAL The lightning flash with arrow- head symbol, within an equilat-... - Page 3 IMPORTANT INFORMATION WARNING: FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly approved by the manufacturer could void the user’s authority to operate this equipment. CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT. “Note to CATV system installer: This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the National Electrical Code that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.”...
-
Page 4: Dear Sharp Customer
DEAR SHARP CUSTOMER Thank you for your purchase of the Sharp LCD Color TV product. To ensure safety and many years of trouble-free operation of your product, please read the Safety Precau- tions carefully before using this product. IMPORTANT SAFETY PRECAUTIONS Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage if improperly handled. - Page 5 IMPORTANT SAFETY PRECAUTIONS (Continued) I Cleaning—Unplug the power cord from the AC outlet before cleaning the product. Use a damp cloth to clean the product. Do not use liquid cleaners or aerosol cleaners. I Water and moisture—Do not use the product near water, such as bathtub, washbasin, kitchen sink and laundry tub, swimming pool and in a wet basement.
-
Page 6: Important Safety Precautions
IMPORTANT SAFETY PRECAUTIONS (Continued) I If an outside antenna is connected to the television equipment, be sure the antenna system is grounded so as to provide some protection against voltage surges and built-up static charges. Section 810 of the National Electrical Code provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, Iocation of antenna-discharge unit, connection to grounding elec- trodes, and requirements for the grounding electrode. -
Page 7: Table Of Contents
Adjusting the V-CHIP Settings ... 31-36 CONNECTING WITH EXTERNAL DEVICES ... 37-39 TROUBLESHOOTING ... 40, 41 SPECIFICATIONS (LC-13B2UB) ... 42 DIMENSIONAL DRAWINGS (LC-13B2UB) ... 43 SPECIFICATIONS (LC-15B2UB) ... 44 DIMENSIONAL DRAWINGS (LC-15B2UB) ... 45 SPECIFICATIONS (LC-20B2UB) ... 46 DIMENSIONAL DRAWINGS (LC-20B2UB) ... 47... -
Page 8: Supplied Accessories
SUPPLIED ACCESSORIES Make sure the following accessories are provided with the product. Remote Control RRMCG1664CESB Antenna Cable (2m) QCNWG0003CEPA AC Adapter UADP-0242CEPZ (LC-13B2UB/LC-15B2UB) UADP-0243CEPZ (LC-20B2UB) “AAA” Size (UM/SUM-4) Dry Battery (×2) UBATU0038CEZZ AC Cord QACCD3097CEPA Operation Manual Cable Clamp (×2) -
Page 9: Preparation
PREPARATION Using the Remote Control I Use the remote control by pointing it towards the remote sensor window. Objects between the remote control and sensor window may prevent proper operation. Cautions regarding use of remote control I Do not expose the remote control to shock. In addition, do not expose the remote control to liquids, and do not place in an area with high humidity. -
Page 10: Power Connection
“B” position on the RF switch (not supplied) : You can view the scrambled channels via the converter/ RF switch (not supplied) Cable TV converter/ Note Consult your SHARP Dealer or Service Center for the type of splitter, RF switch or combiner that might be required. PREPARATION (Continued) To DC input terminal... - Page 11 PREPARATION (Continued) Antenna Connection (Continued) ANTENNAS • The antenna requirements for good color television reception are more important than those for black & white television reception. For this reason, a good quality outdoor antenna is strongly recommended. The following is a brief explanation of the type of connections that are provided with the various antenna systems.
-
Page 12: Front And Rear Control Options
Fundamentally, this operation manual provides a description based on operation with the remote control. The LC-13B2UB, LC-15B2UB and LC-20B2UB have different external dimensions and the positions where the names of the buttons are displayed also differ but the same operating procedures are followed for all three models. - Page 13 VIDEO AUDIO (L) AV-IN1 AUDIO (R) S-VIDEO HEADPHONE Antenna terminal POWER INPUT (DC 12V: LC-13B2UB/ LC-15B2UB) (DC13V: LC-20B2UB) V ID E O A V -I N A U D IO S -V ID H E A D P H O N A N T .
-
Page 14: Removing The Back Cover
FRONT AND REAR CONTROL OPTIONS (Continued) Removing the Back Cover I Before connecting a connection cord into the rear terminal, remove the back cover. Push in the tab and pull out the back cover carefully. I To mount the cover, insert the 2 hooks on the bottom of the cover into the cabinet and press on the upper part of the back cover until the tab locks in place with a click. -
Page 15: Remote Control
REMOTE CONTROL POWER DISPLAY* SLEEP MUTE VOL(+)/(–) CH ( )/( ) MTS* POWER DISPLAY SLEEP BRIGHT MENU MUTE TV/VIDEO FLASHBACK BRIGHT MENU/ ]/[/</> (Cursor control) TV/VIDEO FLASHBACK* Channel Select Displays the receiving channel for 10 seconds. Returns to the previous channel. -
Page 16: Basic Operation
This product is factory set to comply with the TV broadcasting system in the United States. For Brazil, Argentina and Uruguay, set the color system according to the country before using this product by following the table below. I LC-13B2UB, LC-15B2UB The VIDEO INPUT mode is compatible with color systems worldwide and is automatically set. -
Page 17: Turning On Power
BASIC OPERATION (Continued) Turning on POWER MAIN POWER POW ER SLE EP POWER indicator Switching TV/VIDEO [AV1/AV2/COMPONENT/TV] Modes POWER POWER DISPLAY SLEEP BRIGHT MENU MUTE TV/VIDEO FLASHBACK TV/VIDEO Press MAIN POWER, located on the upper side of the main unit, to The POWER indicator instantane- ously changes from red to green and the main unit is turned on. -
Page 18: Sound Volume
Sound Volume POWER DISPLAY SLEEP BRIGHT MENU MUTE TV/VIDEO FLASHBACK MUTE To mute the sound (+)/(–) To select MTS (Multi ch TV Sound) Note ON/OFF Standby To turn off the LCD TV POWER DISPLAY SLEEP BRIGHT MENU To turn the LCD TV back on MUTE TV/VIDEO FLASHBACK... -
Page 19: Changing The Channels
BASIC OPERATION (Continued) Changing the Channels Changing channels by using Channel Select on the remote control • This LCD TV set allows you to select up to 125 channels (1 to 125). To select a channel, enter a 2- or 3-digit number. POWER DISPLAY SLEEP... -
Page 20: Selecting Menu Items
The TINT display only appears when the color system is set to N358 or N443 in the NTSC mode. LC-13B2UB/LC-15B2UB The TINT display only appears when the color system is set to N358 or N443 or AUTO in the NTSC mode. -
Page 21: Adjustment
ADJUSTMENT Adjusting the SLEEP TIMER Settings You can set the SLEEP TIMER to automatically turn off the TV. POWER DISPLAY SLEEP BRIGHT MENU MUTE TV/VIDEO SLEEP FLASHBACK MENU POWER DISPLAY SLEEP BRIGHT MENU MUTE TV/VIDEO MENU/ FLASHBACK ]/[/ </ > Note When you set the SLEEP TIMER, the SLEEP indicator lights. -
Page 22: Adjusting The Brightness Settings
Adjusting the BRIGHTNESS Settings You can set the brightness of the screen. POWER DISPLAY SLEEP BRIGHT MENU MUTE TV/VIDEO BRIGHT FLASHBACK MENU POWER DISPLAY SLEEP BRIGHT MENU MUTE TV/VIDEO MENU/ FLASHBACK ]/[/ </ > ADJUSTMENT (Continued) Directly setting the BRIGHTNESS Press BRIGHT to display the BRIGHTNESS screen. -
Page 23: Adjusting The Language Settings
ADJUSTMENT (Continued) Adjusting the LANGUAGE Settings The language for the On-Screen Display can be ENGLISH, SPANISH or FRENCH. POWER DISPLAY SLEEP BRIGHT MENU MUTE TV/VIDEO MENU/ FLASHBACK ]/[/ </ > Press MENU to display the MENU screen. Press ]/[ to move the cursor to SET UP. -
Page 24: Adjusting The Video Adjust Settings
Adjusting the VIDEO ADJUST Settings POWER DISPLAY SLEEP BRIGHT MENU MUTE TV/VIDEO MENU/ FLASHBACK ]/[/ </ > ADJUSTMENT (Continued) Press MENU to display the MENU screen. Press ]/[ to move the cursor to VIDEO ADJUST. Press </ > to enter. Press ]/[ to move the cursor to the desired item. - Page 25 PICTURE TINT COLOR BLACK LEVEL SHARPNESS RED-BLUE GREEN I LC-13B2UB/LC-15B2UB COLOR SYSTEM I LC-20B2UB COLOR SYSTEM Note TINT is displayed only when N358 or N443 is selected. In BLUE SCREEN, PICTURE setting displayed in magenta cannot be selected. Selecting RESET will return all settings to the factory settings.
-
Page 26: Adjusting The Preset Settings
Adjusting the PRESET Settings POWER DISPLAY SLEEP BRIGHT MENU MUTE TV/VIDEO MENU/ FLASHBACK ]/[/ </ > Selected item Factory setting BRIGHTNESS [BRIGHT] Maximum brightness AUTO POWER OFF [OFF] (only TV mode) UPSIDE [NORMAL] Normal vertical image orientation RIGHT/LEFT [NORMAL] Normal horizontal image orientation AV2 IN/OUT [IN]... -
Page 27: Set Up
ADJUSTMENT (Continued) SET UP I CHANNEL SETTING It is necessary to set the receiving mode to AIR or CABLE channels to receive locally broadcast TV programs. POWER DISPLAY SLEEP BRIGHT MENU MUTE TV/VIDEO MENU/ FLASHBACK ]/[/ </ > Note Receivable channels of your TV set are: AIR channels: VHF: 2 through 13. - Page 28 SET UP (Continued) I Saving broadcast TV channels in the memory POWER DISPLAY SLEEP BRIGHT MENU MUTE TV/VIDEO MENU/ FLASHBACK ]/[/ </ > ADJUSTMENT (Continued) Press MENU to display the MENU screen, press ]/[ to move the cursor to SET UP, and press </ > to enter.
- Page 29 ADJUSTMENT (Continued) SET UP (Continued) I Adding weak or additional channels or erasing unwanted channels from TV memory POWER DISPLAY SLEEP BRIGHT MENU MUTE TV/VIDEO MENU/ FLASHBACK ]/[/ </ > Channel Select Note If CH SEARCH is performed again, the previously memorized channels will be lost. Press MENU to display the MENU screen, press ]/[ to move the cursor to SET UP, and press </ >...
-
Page 30: Adjusting The Blue Screen Settings
Adjusting the BLUE SCREEN Settings I BLUE SCREEN Automatically turns the screen blue if a broadcast signal is not received. POWER DISPLAY SLEEP BRIGHT MENU MUTE TV/VIDEO MENU/ FLASHBACK ]/[/ </ > Note When received signals are weak or interfered with by some other signals, the BLUE SCREEN function may be activated. -
Page 31: Adjusting The Closed Caption Settings
ADJUSTMENT (Continued) Adjusting the CLOSED CAPTION Settings I SETTING CLOSED CAPTION • This TV set is equipped with an internal Closed Caption decoder. “Closed Caption” is a system which allows conversations, narration, and sound effects in TV programs and home videos to be viewed as captions on the TV screen (see the illustration). •... -
Page 32: Adjusting The V-Chip Settings
Adjusting the V-CHIP Settings I V-CHIP • This function allows TV programs to be restricted and TV usage to be controlled based on FCC data. It prevents children from watching violent or sexual scenes that may be harmful. • Restriction of TV programs includes two ratings that contain information about the program: the MPAA rating and the TV Parental Guidelines. - Page 33 ADJUSTMENT (Continued) Adjusting the V-CHIP Settings (Continued) [2] TV PARENTAL GUIDELINES RATING TV-Y (All children) TV-Y7 (Direct to Older Children) ⇑ TV-G (General Audience) base TV-PG (Parental Guidance Suggested) ⇓ TV-14 (Parents Strongly Cautioned) TV-MA (Mature Audience Only) : The content rating can be set, but this rating is not normally broadcast by TV stations. ✕...
-
Page 34: I Setting V-Chip
Adjusting the V-CHIP Settings (Continued) I SETTING V-CHIP [1] MPAA RATING POWER DISPLAY SLEEP BRIGHT MENU MUTE TV/VIDEO MENU/ FLASHBACK ]/[/ </ > Channel Select Note If you set G to BLOCK, all ratings are automatically blocked. If you set X to BLOCK, G, PG, PG-13, R and NC-17 are not blocked. ADJUSTMENT (Continued) Press MENU to display the MENU screen. - Page 35 ADJUSTMENT (Continued) Parent Control (V-CHIP Operation Continued) Adjusting the V-CHIP Settings (Continued) [2] TV GUIDELINES I Setting MPAA POWER DISPLAY SLEEP BRIGHT MENU MUTE TV/VIDEO MENU/ FLASHBACK ]/[/ </ > I Setting BLOCK CONTENT POWER DISPLAY SLEEP BRIGHT MENU MUTE TV/VIDEO MENU/ FLASHBACK...
- Page 36 Adjusting the V-CHIP Settings (Continued) [3] ACTIVATE ON TO TURN ON V-CHIP BLOCK POWER DISPLAY SLEEP BRIGHT MENU MUTE TV/VIDEO MENU/ FLASHBACK ]/[/ </ > Channel Select [4] CANCELING THE V-CHIP BLOCK SCREEN WHILE V-CHIP BLOCK IS ACTIVATED POWER DISPLAY SLEEP BRIGHT MENU...
-
Page 37: Adjusting The V-Chip Settings
ADJUSTMENT (Continued) Adjusting the V-CHIP Settings (Continued) [5] CHANGING THE V-CHIP BLOCK SETTINGS POWER DISPLAY SLEEP BRIGHT MENU MUTE TV/VIDEO FLASHBACK Channel Select [6] CHANGING OR CLEARING THE SECRET NUMBER If you forget the secret number, clear the secret number as follows. Upper control panel of the main unit MENU... -
Page 38: Connecting With External Devices
CONNECTING WITH EXTERNAL DEVICES You can enjoy picture and sound by connecting a VCR or a home video game system to the terminals located on the rear of the TV set. When connecting an external device, turn off the power of the main unit first to prevent any possible damage. - Page 39 CONNECTING WITH EXTERNAL DEVICES (Continued) Connecting a VCR, DVD player or a video camera (AV-IN1/2/COMPONENT) V ID E O /O U T A V -I N 2 A U D IO O N E N T C O M P A U D IO V ID E O A V -I N...
- Page 40 CONNECTING WITH EXTERNAL DEVICES (Continued) Outputting video and audio (video output) You can output video and audio data from the TV set through the AV output terminals (AV-OUT). V ID E O Connect a VCR, /O U T A V -I N 2 Audio amplifier, A U D IO etc.
-
Page 41: Troubleshooting
TROUBLESHOOTING I Before calling for repair service, check the following items for possible remedies to the encountered symptoms. TV set Problem Picture Sound There is no picture or sound. There is no Picture picture. There is no picture from AV-IN 1. There is no sound. - Page 42 Antenna Problem The picture is not sharp. The picture moves. The picture is doubled or tripled. The picture is spotted. There are stripes on the screen or colors fade. I Use in hot and cold rooms (locations) • When the unit is used in a low temperature rooms (location), the picture may leave trails or appear slightly delayed.
-
Page 43: Specifications (Lc-13B2Ub)
Weight Accessories As a part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be some deviations from these values in individual units. -
Page 44: Dimensional Drawings (Lc-13B2Ub)
DIMENSIONAL DRAWINGS (LC-13B2UB) 3.7/95.1 2.4/60.5 1.1/27 5.4/137.3 7.0/177.8 VIDEO AV-IN 2/OUT AUDIO COMPONENT AUDIO 1.6/40.5 Unit: inch/mm MENU TV/VIDEO MAIN POWER 16.9/429 10.4/265 10.7/271.2 39.4/100 VIDEO AV-IN1 AUDIO S-VIDEO HEAD PHONE ANT. POWER INPUT DC12V... -
Page 45: Specifications (Lc-15B2Ub)
Weight Accessories As a part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be some deviations from these values in individual units. -
Page 46: Dimensional Drawings (Lc-15B2Ub)
DIMENSIONAL DRAWINGS (LC-15B2UB) 3.9/98.8 2.4/61.1 1.1/27 5.9/149.5 1.9/48.5 7.8/198 MENU TV/VIDEO MAIN POWER 19.1/484 12.0/305.3 11.9/301.6 39.4/100 VIDEO AV-IN 2/OUT AUDIO COMPONENT AUDIO Unit: inch/mm VIDEO AV-IN1 AUDIO S-VIDEO HEAD PHONE ANT. POWER INPUT DC12V... -
Page 47: Specifications (Lc-20B2Ub)
Weight Accessories As a part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be some deviations from these values in individual units. -
Page 48: Dimensional Drawings (Lc-20B2Ub)
DIMENSIONAL DRAWINGS (LC-20B2UB) 4.2/107.3 2.9/72.6 1.2/30.5 6.5/163.9 2.6/65.5 9.0/229.4 MENU TV/VIDEO MAIN POWER 12.6/319 24.8/630 15.8/401.3 14.9/379 VIDEO AV-IN1 AUDIO VIDEO S-VIDEO AV-IN 2/OUT AUDIO HEAD PHONE COMPONENT ANT. 3.94/100 AUDIO POWER INPUT DC12V Unit: inch/mm... -
Page 49: Calling For Service
Product, and shall constitute full satisfaction of all claims, whether based on contract, negligence, strict liability or otherwise. In no event shall Sharp be liable, or in any way responsible, for any damages or defects in the Product which were caused by repairs or attempted repairs performed by anyone other than an authorized servicer. - Page 50 (b) Any Sharp product tampered with, modified, adjusted or repaired by any party other than Sharp, Sharp’s Authorized Service Centres or Sharp’s Authorized Servicing Dealers. (c) Damage caused or repairs required as a result of the use with items not specified or approved by Sharp, including but not limited to head cleaning tapes and chemical cleaning agents.
