- Page 1 VER. 1.00 USER’S MANUAL - TE TYPE -...
- Page 2 (ex. Isolation tools, isolation cable) 12. A/S Request A/S Department TEL (031) 831 – 8310~8312 FAX (031) 831 – 8314 Mail : paratec@paratec.co.kr Homepage : www.paratec.co.kr...
- Page 3 Power Rating : 25A @ 220V, 50/60Hz Input : 4~20mA Made In Korea H.page : www.paratec.co.kr , A/S 031)831-8312 ※ Product label includes basic specification of product and A/S information. ※ Product label is attached on the outer side of each unit.
- Page 4 2. SPECIFICATION OF PRODUCT Contents Specification Model Digital Power Regulator TE-TYPE NO of Phase Three Phase Rated Voltage (V) 110/220/380/440 VAC (Cooling FAN Power Auxiliary 220VAC) Allowance of Input ±10% of Rated Voltage Voltage Rate Current (A) 25, 40 / 55, 70 (With Cooling Fan ) 50/60Hz ±2Hz Rated Frequency Dimension...
- Page 5 3. NAME OF EACH PART ① Connecting terminal of main R-S-T and cover ② Input signal & alarm terminal ③ Dip switch (Selecting operating mode) ④ Display LED ⑤ Re-set switch ⑥ Output adjusting volume ⑦ Connecting terminal of U-V-W and cover ⑧...
- Page 6 5. WIRING 5.1. ORDER OF WIRING 1) Detach the covers (Top and bottom). 2) Connect R-S-T.(Caution : Be careful the cable should not be touched onto the case) 3) Connect loads to U-V-W. 4) Connect FG (Field ground). 5) Attach the covers (Tope and bottom). 6) Connect fan power of 220VAC, if it is with cooling fan.
- Page 7 7. CONTROL(INPUT) SIGNAL 7.1. AUTO INPUT 4~20mA Auto input : Refer to detail A. terminal : ‘+’ Cable terminal : ‘-‘ Cable Consult us for any other input signal such as 0~5/1~5/0~10VDC and so on. Pay attention to polarity of ( +, - ). Otherwise, the unit can operate improperly or output can be shut down.
- Page 8 8.2. ZERO-CROSSING CONTROL Turn on the gate on zero point according to input signal. Control method can be changed by selecting 4 dip switch. If you want zero-crossing control, please turn the 4 dip switch on. And mode can not be changed when the unit is operating. If you change new mode, please push the re-set button or re-start the unit.
