Summary of Contents for SImx LHT0142
- Page 1 PIR MOTION DETECTOR INSTALLATION MANUAL LHT0142 V1.0 - 02/12...
-
Page 2: Side View
SIDE VIEW 2.5m Less Sensitive Lens Mask TOP VIEW 360º Restrict short detection Restrict long detection Restrict detection directly under sensor... - Page 3 During this period if the product has a defect of this nature it will be repaired or replaced free of charge by SIMX with the same Supplier means the authorised distributor or retailer that sold you the Goods in New Zealand or Australia;...
- Page 4 Factory fitted bridge wire REMOVED Lux- Time On Dusk / Dawn setting setting Sw itched Mains Levering area Factory fitted Load Supply bridge wire In the above illustration: - The L1 L2 terminals are used to control a DC load or if the load uses a different phase or voltage supply from the AC mains in.
-
Page 5: General Information
SECTION ONE GENERAL INFORMATION The unit utilises passive infrared technology to detect heat radiation of moving human bodies. Upon detection, the attached lighting load will illuminate for a user-determined time period. An integral daylight sensor ensures day or night-only operation. PARTS INCLUDED - PIR Sensor unit. -
Page 6: Installation
SECTION THREE INSTALLATION After choosing a suitable location (see previous section) install the unit as follows: The unit is suitable for connection to a 230 V AC 50Hz electricity supply. An internal switch should be installed to switch the power to the unit ON & OFF. This allows the sensor to be easily switched off when not required or for maintenance purposes and allows it to be conveniently brought into manual override. -
Page 7: Operation And Testing
When wiring is complete, set the two adjustment controls on the side of the unit (diagram D) to the following position: TIME - Fully anti-clockwise DUSK - Fully clockwise Push back the locating spring (diagram E) and feed the unit into the ceiling void via the 75mm hole. -
Page 8: Manual Override Mode
SETTING UP FOR AUTOMATIC OPERATION. When walk tests are complete, the unit can be switched to automatic operation : To access the controls use a knife or thin flat blade screwdriver to gently level (see diagram E) the unit clear of the ceiling. Hold in position against the spring pressure while making adjustment. The TIME setting controls how long the unit remains illuminated following activation &... -
Page 9: Technical Specifications
Qualified Customer Support Co-ordinators will be on-line to assist in resolving your query. Product Complies with: EN 60669-2-1:2004, EN 60669-1:1999+A1:2002 Distributed by: Simx Limited Ph: +64 9 259 1660 | Technical Support Ph: +64 9 259 1662 Email: sales@simx.co.nz | www.simx.co.nz Simx reserves the right to alter technical specifications without prior warning... -
Page 10: Troubleshooting Guide
SECTION SIX IQ-SA-360-FM 251012:IQ-SA-360-CS-W.qxd 10/26/12 5:40 PM Page 10 TROUBLESHOOTING GUIDE PROBLEM SOLUTION ❏ Lamp stays ON all the time at Cover PIR lens with a thick cloth. If the light turns out, check night. detection area for heat or reflective source. If the light stays on, check wiring.
