- Page 1 MEDIUM DUTY MINI TOWER Mobile Aluminium Access Tower Instruction Manual EN 1298-IM-EN The Mini Tower is compliant with BS EN 1004:2004 3T - Through The Trapdoor Method 01432 346800 sales@leachs.com www.leachs.com...
- Page 2 The Mini Tower is a mobile access tower compliant with EN 1004 Class 3. This tower is not suitable for applications outside of EN1004 or other than as described in these instructions. This tower is manufactured in our ISO 9001 accredited facility. This manual complies with EN 1298-IM-EN. Maximum Safe Working Loads The safe working load of the tower is 350 kg including its own weight.
- Page 3 • In case of any doubt as to the integrity of any items of the equipment, the part should be withdrawn from use, quarantined and subject to detailed examination to determine whether repair or replacement is required. If returned to the factory, LEACH'S will provide a free of charge evaluation of any damaged components.
- Page 4 • The tower is not designed to be used with hoisting arrangements. • Contact LEACH'S for advice on loadings Tel: +44 (0)1432 346 800 or Email: sales@leachs.com • Fit guard rails at every level and ensure all wind latches are engaged at both ends of the platform.
- Page 5 · after completing the movement check that the tower is correct and complete. Products | LEACH'S Page 5...
- Page 6 Standard scaffold tubes and fittings can be used with the products. Ties should be spaced at no more than 4m intervals. Ties must be rigid and be secured to both frame uprights. For further details regarding tying in, please contact your supplier: LEACH'S. Page 6...
- Page 7 During the assembly phase these plates can be rotated outwards to enable the platform to be hooked onto the tower structure - either on the rungs of the end frames or onto the brace panels on the side of the tower. Products | LEACH'S Page 7...
- Page 8 Component Schedule WORKING PLATFORM HEIGHT CODE PART DESCRIPTION 2239 125mm Dia. Castor Wheel 3520 Mini Tower Adj. Alum Leg (black collar) 3201 Mini Tower Base Frame 12.4 3202 Mini Tower Main Frame 3203 Mini Tower Brace Panel 3204 Mini Tower Platform 11.1 3205 Mini Tower Toeboard...
- Page 9 3520 - Adj. Leg 3203 - Mini Tower Brace Panel 3204 - Mini Tower Platform 3205 - Mini Tower Toeboard 3510 - 1.2m Horiz. Brace (Red) 3207 - Mini Tower Stabiliser 3206 - Component Hanger Frame Products | LEACH'S Page 9...
- Page 10 ASSEMBLY INSTRUCTIONS - All Platform Working Heights Step 1 Insert the leg & castor assembly into each leg of the base frame assembly When fully inserted, ensure the spring-loaded pin is engaged into the hole in the side of the frames. Ensure all 4 wheels have the brakes applied.
- Page 11 2nd pair of frames. Put a pair of assembled frames on each end of the base unit with the head fitting pointing inwards. Ensure that the locking bolts at the bottom engage once added to the base frame. Products | LEACH'S Page 11...
- Page 12 Build Method for 2m Working Platform Height Step 6 Add a brace panel between rungs 6 and 8 on the same side of the tower as the folding gate on the base frame. Make sure that the hooks are facing outwards.
- Page 13 Hang one brace panel then two 2m end frames on one hanger frame. Hang two brace panels then the toeboard on the second hanger frame. Hook a platform onto the end frame. Products | LEACH'S Page 13...
- Page 14 Step 9 From the platform, fit the two end frames. Ensure that the head fitting are pointing inwards and the locking bolts at the bottom of the installed frames are in the locked position. Step 10 Remove the brace panel and fit it on the same side as the hanger frame it comes off between rungs 6 and 8 above the current platform.
- Page 15 Using the 3T method install 2 brace panels. Remove these from the hanger on the side of the tower. Relocate the platform hanging from the end of the tower round onto the empty brace panel on the side of the tower. Products | LEACH'S Page 15...
- Page 16 Step 9 Remove the 2 assembled end frames and install on the tower, ensuring the head fittings pointing inwards and the locking bolts at the bottom are fully engaged. Remove the brace panel from the end hanger and fit it on the tower - ensuring the hooks are located between the 6th and 8th rung up from the platform.
- Page 17 3rd rung down. Ensure that the hooks face outwards. Now fit the toeboard Products | LEACH'S Page 17...
-
Page 18: Packing & Transportation
Dismantling Disassembly is the reverse of the relevant assembly process until you reach an assembled base unit as described in step 3. Ensure that the 3T method is used at all times. The toeboard should be secured in the closed position using the Velcro strap provided after removal from the platform before proceeding further with the dismantling. - Page 19 Notes Products | LEACH'S Page 19...
- Page 20 For further information regarding our range of access products and services, please get in touch with us: LEACH'S Beacon Park, 228 Holme Lacy Road, Hereford HR2 6BQ t: +44 (0)1432 346 800 e: sales@leachs.com w: www.leachs.com Manufacturing Member 01432 346800 sales@leachs.com...
