COUNTERFOG® PILAR 2.0
USER MANUAL MARCH 2022
COUNTERFOG® IS A REGISTERED TRADEMARK
IT IS STRICTLY PROHIBITED TO MODIFY THIS DOCUMENT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PILAR 2.0 and is the answer not in the manual?

Questions and answers

Related Manuals for COUNTERFOG PILAR 2.0

Summary of Contents for COUNTERFOG PILAR 2.0

  • Page 1 COUNTERFOG® PILAR 2.0 USER MANUAL MARCH 2022 COUNTERFOG® IS A REGISTERED TRADEMARK IT IS STRICTLY PROHIBITED TO MODIFY THIS DOCUMENT...

  • Page 2: Table Of Contents

    COUNTERFOG® PILAR 2.0 DATE: 24/03/2022 CLASSIFICATION: PUBLIC VERSION: 1 CONTENTS INTRODUCTION ........................3 SYMBOLS USED IN THIS MANUAL ..................3 DESCRIPTION ........................3 USE ............................4 2.1 INTENTED USE ........................4 2.2 LIQUIDS SUITABLE TO BE FOGGED ..................5 2.3 SAFETY AND CAUTION WARNINGS ..................6 2.4 AUTHORIZED PERSONS ......................

  • Page 3: Introduction

    Disregarding can damage the device or produce underperformance. 1.2 DESCRIPTION COUNTERFOG® PILAR 2.0 is a fog-generating device for the rapid disinfection of buildings, indoor facilities, offices, vehicles, goods or objects. It provides a dynamic fog cone composed of sub-micrometric droplets of liquid which, when projected into the air, catch air-borne matter (dust, aerosols, spores, etc.).

  • Page 4: Use

    DATE: 24/03/2022 CLASSIFICATION: PUBLIC VERSION: 1 Counterfog is not responsible for the use of other disinfectants not compatible with AISI 316L steel, Teflon and NBR-. 2. USE Carefully instruct all users of the device on how to operate it, its application purposes and the risks incurred.

  • Page 5: Liquids Suitable To Be Fogged

    Follow the safety instructions of the manufacturer of the liquid to be fogged. • Users should familiarize themselves with Counterfog® PILAR 2.0 operation by reading the User Manual prior to first use. It is essential that Counterfog® PILAR 2.0 users follow all safety warnings as detailed in this operating manual.

  • Page 6: Safety And Caution Warnings

    Avoid splashing or overfilling which could harm the user and the device.  COUNTERFOG EBT de la UAH S.L is not responsible for any injury or damage caused by using this device other than using the specific parameters detailed in this manual.

  • Page 7: Authorized Persons

    COUNTERFOG® PILAR 2.0 DATE: 24/03/2022 CLASSIFICATION: PUBLIC VERSION: 1 2.4 AUTHORIZED PERSONS The device shall only be used by adults who have been carefully instructed on how to operate it and are well informed on possible dangers and risks incurred when using the device.

  • Page 8: Components

    COUNTERFOG® PILAR 2.0 DATE: 24/03/2022 CLASSIFICATION: PUBLIC VERSION: 1 2.5 COMPONENTS Part Name Pressure tank Compressor Drain valve Filling valve Liquid valve Filter Check valve P a g e...
  • Page 9 COUNTERFOG® PILAR 2.0 DATE: 24/03/2022 CLASSIFICATION: PUBLIC VERSION: 1 Check valve Air valve Coaxial hose Vent valve Pressure gauge Safety valve Check valve Pressure switch Filling funnel Counterfog® MPM Nozzle for massive nanometric fog generation P a g e...
  • Page 10 COUNTERFOG® PILAR 2.0 DATE: 24/03/2022 CLASSIFICATION: PUBLIC VERSION: 1 10 | P a g e...

  • Page 11: Package Contents

    Earplugs or other ear protectors. 4. ROOM PREPARATION Counterfog® PILAR 2.0 can disinfect air, clothes and surfaces with a scarce amount of disinfectant liquid. Surfaces must be exposed to air. For a full disinfection remove bed covers. Clothes and objects that should be disinfected separately.
  • Page 12 Provide PPE to any person staying in the room or space while disinfection operation is in progress. Fire smoke detectors will usually detect the mist generated by your Counterfog® PILAR 2.0. Before disinfection, turn off your fire alarm device. Do not forget to turn it on again after the whole disinfection operation is over.

  • Page 13: Operating Instructions

    5.1 POSITION Place Counterfog® PILAR 2.0. on a stable, flat, dust-free, not slippery, horizontal surface. Please, do not drop Counterfog® PILAR 2.0. and always keep it in a vertical position during the operation of the device 5.2 FILLING Counterfog® PILAR 2.0 must be used only with appropriated disinfectants.
  • Page 14 3.9 liters [1.03 gallons (US)].  Liquid disinfectants usually need to be diluted in water (following the instructions of the disinfectant manufacturer). Please, fill your Counterfog® PILAR 2.0 with the recommended solution. Always wear gloves and safety glasses when filling the tank! 14 |...

  • Page 15: Power Connection

    Please, complete the whole process with this liquid (next steps), and when you empty the excess liquid (See 8. END OF OPERATION), fill your COUNTERFOG® PILAR 2.0 with the new disinfectant. o When finish pouring the liquid, close the filling valve...
  • Page 16 CLASSIFICATION: PUBLIC VERSION: 1 o Wait until the pressure gauge (check pressure gauge 12) indicates Counterfog® PILAR 2.0 has been pressurized to 10 bar. Counterfog® PILAR 2.0 is programmed to automatically provide a pressure of when pressurized. 16 | P a g e...

  • Page 17: Decontamination Operation

    This device jets fogged chemical substances. Do not inhale these substances. 6. ROOM DISINFECTION Counterfog® PILAR 2.0 disinfects both air and surfaces. For an effective operation, the user must gently aim corners from one side to the other, from the upper to the lower parts.

  • Page 18: Pause

    8. END OF OPERATION When wanted to finish disinfection, follow the next steps. o Close the liquid valve (Close o Close the air valve (Close o Switch the COUNTERFOG® PILAR 2.0 (position 0). See next image. 18 | P a g e...
  • Page 19 The tank will remain pressurized. Unplug the equipment from the supply line. To end the operation, unplug the Counterfog® PILAR 2.0 device, move it to a safe place and proceed to depressurization: o Carefully open the vent valve (Open 11).
  • Page 20 1 liter of drinkable water (0.26 gallons). When you Counterfog® PILAR 2.0 has been filled, tilt slightly the device to both sides so as to drinkable water is being mixed with the remaining disinfectant in the walls of the device.

  • Page 21: Other Cautions

    Position the Counterfog® PILAR 2.0 on a secure surface to prevent rolling or moving while in use.  Protect this device from severe impact or shock.  Do not tip the Counterfog® PILAR 2.0 on its side at any time unless completely empty and dry. TROUBLESHOOTING Anomaly Possible Cause...
  • Page 22 COUNTERFOG® PILAR 2.0 DATE: 24/03/2022 CLASSIFICATION: PUBLIC VERSION: 1 Possible internal Switch off and unplug device, call the Device emits damages Presence of technical service loud noises foreign bodies in the compressor Possible internal Switch off, unplug device and remove...

  • Page 23: Warranty

    (i) Call COUNTERFOG EBT de la UAH S.L (ii) Prepare the shipment of the device back to COUNTERFOG EBT de la UAH S.L and the original invoice .Please note that the device should be packed in the original shipping box. Should this not be the case the device will not qualify for the above explained warranty service and will be repaired or replaced at customers’...
  • Page 24 Buyer's premises), assembly/disassembly, decontamination, and installation/re- installation. - COUNTERFOG EBT de la UAH S.L and its authorized Dealers assume no liability for any damage, accident, injury, death, loss or other claim related to or resulting from the use of the device. In no event shall they be held liable for incidental or consequential damages relating to or resulting from the use of the device, any of its parts or accessories.

  • Page 25: Disclaimer

    State authority or Buyer or Buyer's contractors or suppliers. -COUNTERFOG's total liability for all claims of any class arising out of or relating to the conclusion, performance or breach of the Contract, or for any Product or Service shall not exceed the Contract Price.

  • Page 26: Disposal And Decommissioning

    COUNTERFOG® PILAR 2.0 DATE: 24/03/2022 CLASSIFICATION: PUBLIC VERSION: 1 DISPOSAL AND DECOMMISSIONING Disposal should be done respecting the environment and local recycling rules. The dismantling of the device must be done by specialized companies. The device is built with recyclable materials.
  • Page 27 COUNTERFOG® PILAR 2.0 DATE: 24/03/2022 CLASSIFICATION: PUBLIC VERSION: 1 ANNEX I: DISINFECTANTS AUTHORIZED IN SPAIN As a result of the health emergency, the Government of Spain declared a state of alarm in accordance with Royal Decree 463/2020, published on March 12, 2020, due to the spread of the pandemic generated by the SARS-CoV-2 coronavirus.
  • Page 28 COUNTERFOG® PILAR 2.0 DATE: 24/03/2022 CLASSIFICATION: PUBLIC VERSION: 1 Air conditioning Commercial name Surfaces Equipment Fabrics equipment and conducts LIMOSEPTIC SF TOTAL SHOCK SF TERMINAL FORTE SR BIOQUELL HPV-AQ Vaprox ® Hydrogen Peroxide Sterilant Vaprox ® 59 Hydrogen Peroxide Sterilant...
  • Page 29 COUNTERFOG® PILAR 2.0 DATE: 24/03/2022 CLASSIFICATION: PUBLIC VERSION: 1 Air conditioning Commercial name Surfaces Equipment Fabrics equipment and conducts SANYTOL KITCHEN DISINFECTANT NDP AIR TOTAL + GREEN VIRIBIOL PLUS National Registry of products for the disinfection of surfaces and air (environmental use)
  • Page 30 COUNTERFOG® PILAR 2.0 DATE: 24/03/2022 CLASSIFICATION: PUBLIC VERSION: 1 Manufacturer's Registration Manufacturer's recommended application Commercial name Active Substance User recommended Number procedure concentration a contact time of 15 s. Recommended safety period: 24 hours. • Air disinfection: Spraying or fogging with the product diluted in water with a contact time of 15 s.
  • Page 31 COUNTERFOG® PILAR 2.0 DATE: 24/03/2022 CLASSIFICATION: PUBLIC VERSION: 1 Manufacturer's Registration Manufacturer's recommended application Commercial name Active Substance User recommended Number procedure concentration SANOSIL S010 18-20/40/90- Hydrogen peroxide: 5%, -Professional • Contact disinfection for use: Surfaces and 09514 Silver: 0.00415%...
  • Page 32 COUNTERFOG® PILAR 2.0 DATE: 24/03/2022 CLASSIFICATION: PUBLIC VERSION: 1 Manufacturer's Registration Manufacturer's recommended application Commercial name Active Substance User recommended Number procedure concentration size of the area to • Disinfection in air conditioning equipment be treated) and ducts: spraying or fogging of the pure product respecting contact times.
  • Page 33 COUNTERFOG® PILAR 2.0 DATE: 24/03/2022 CLASSIFICATION: PUBLIC VERSION: 1 Manufacturer's Registration Manufacturer's recommended application Commercial name Active Substance User recommended Number procedure concentration LIMOSEPTIC SF 12-20/40/90- Didecyldimethyl - Specialized 1% :4 pulses / • Contact disinfection: surfaces and 01927 ammonium chloride: professional envelopes (25 ml.)
  • Page 34 COUNTERFOG® PILAR 2.0 DATE: 24/03/2022 CLASSIFICATION: PUBLIC VERSION: 1 Manufacturer's Registration Manufacturer's recommended application Commercial name Active Substance User recommended Number procedure concentration not be used continuously by mechanical application with a dispenser. TERMINAL FORTE 17-20/40/90- Hydrogen peroxide: 9%, - Specialized Undiluted at the •...
  • Page 35 COUNTERFOG® PILAR 2.0 DATE: 24/03/2022 CLASSIFICATION: PUBLIC VERSION: 1 Vaprox ® ES/MRF(NA)- Hydrogen peroxide: 35% - Specialized Undiluted • Disinfection of non-porous surfaces, Hydrogen 2019-02-00622-1- professional materials, equipment and furniture not used Peroxide Sterilant staff for direct contact with food or animal feed,...
  • Page 36 COUNTERFOG® PILAR 2.0 DATE: 24/03/2022 CLASSIFICATION: PUBLIC VERSION: 1 Manufacturer's Registration Manufacturer's recommended application Commercial name Active Substance User recommended Number procedure concentration 49.7% (10.49% oxygen in water. Recommended safety period: 12 available) hours. -Specialized 10 gr product/ 1 l of •...
  • Page 37 COUNTERFOG® PILAR 2.0 DATE: 24/03/2022 CLASSIFICATION: PUBLIC VERSION: 1 Manufacturer's Registration Manufacturer's recommended application Commercial name Active Substance User recommended Number procedure concentration • Disinfection of air conditioning equipment and ducts. In air conditioning equipment the mode of use will be only in a timely manner...
  • Page 38 COUNTERFOG® PILAR 2.0 DATE: 24/03/2022 CLASSIFICATION: PUBLIC VERSION: 1 Manufacturer's Registration Manufacturer's recommended application Commercial name Active Substance User recommended Number procedure concentration TERMINAL FORTE 17-20/40/90- Hydrogen peroxide: 9%, - Specialized Undiluted at the rate • Contact disinfection: surfaces and 05739-HA Peracetic acid: 0.25%,...
  • Page 39 COUNTERFOG® PILAR 2.0 DATE: 24/03/2022 CLASSIFICATION: PUBLIC VERSION: 1 Manufacturer's Registration Manufacturer's recommended application Commercial name Active Substance User recommended Number procedure concentration • Air disinfection: nebulization or thermonebulization with the product diluted in water. Safety period: 24 hours. • Disinfection of air conditioning ducts by...
  • Page 40 COUNTERFOG® PILAR 2.0 DATE: 24/03/2022 CLASSIFICATION: PUBLIC VERSION: 1 Manufacturer's Registration Manufacturer's recommended application Commercial name Active Substance User recommended Number procedure concentration BIOQUELL HPV-AQ 17-20/40/90- Hydrogen peroxide: - Specialized Undiluted • Air disinfection: apply the pure product with 08737-HA...
  • Page 41 COUNTERFOG® PILAR 2.0 DATE: 24/03/2022 CLASSIFICATION: PUBLIC VERSION: 1 Manufacturer's Registration Manufacturer's recommended application Commercial name Active Substance User recommended Number procedure concentration Didecyldimethyl characteristics and respecting contact times. Safety period of 3 ammonium chloride: requirements of hours. 6.93% each installation)
  • Page 42 COUNTERFOG® PILAR 2.0 DATE: 24/03/2022 CLASSIFICATION: PUBLIC VERSION: 1 National Register of products for surface disinfection (clinical use) Manufacturer's Registration Manufacturer's recommended application Commercial name Active Substance User recommended Number procedure concentration SANOSIL S010 HC 987-DES Hydrogen peroxide: -Professional Undiluted at the rate •...
  • Page 43 COUNTERFOG® PILAR 2.0 DATE: 24/03/2022 CLASSIFICATION: PUBLIC VERSION: 1 Manufacturer's Registration Manufacturer's recommended application Commercial name Active Substance User recommended Number procedure concentration Total Shock SF 613-DES Glutaraldehyde: 2,5% - Professional Undiluted at the rate • Contact disinfection: surfaces and...
  • Page 44 COUNTERFOG® PILAR 2.0 DATE: 24/03/2022 CLASSIFICATION: PUBLIC VERSION: 1 Registro Nacional de productos para la desinfección de superficies y aérea (uso ambiental) Manufacturer's Registration Manufacturer's recommended Commercial name Active Substance User recommended Number application procedure concentration SANYTOL MULTI- 12-20/40- Didecyldimethyl...
  • Page 45 COUNTERFOG® PILAR 2.0 DATE: 24/03/2022 CLASSIFICATION: PUBLIC VERSION: 1 Manufacturer's Registration Manufacturer's recommended Commercial name Active Substance User recommended Number application procedure concentration Biphenyl-2-ol: 7%, • Air disinfection: Fogging of the product Glutaraldehyde:4.25% previously diluted in water. National Register of products for the disinfection of surfaces in contact with food and feed (food industry)
