Daintree Albeo ARC Series Ordering Manual

Albeo ARC Series
®
LED IP65 Round High Bay
CONSTRUCTION
Housing: Die-cast Aluminum
Lens: Polycarbonate
Powder coat painted housing.
Paint:
No glass in housing or lenses
Weight: 6.5 – 9.5lb (2.95 – 4.30kg)
Optical 85° clear optic, Optional polycarbonate refractor,
Assembly: drop lens, or aluminum reflector
OPTICAL SYSTEM
Lumens: 13,000 – 33,600
Wattage: 95 – 240W
Efficacy: Up to 140 LPW
CCT: 4000K, 5000K
CRI: 80
Glare Rating: UGR<28
ELECTRICAL
Input Voltage: 120 – 277V and 277– 480V
Input Frequency: 50/60Hz
Power Factor (PF)*: >0.9*
Total Harmonic Distortion
(THD)*:
EMI: FCC CFR Title 47 Part 15, Class A
Surge Protection:
<20%*
4kV/2kA driver surge
protection couple
* PF and THD may vary with options
CUSTOMER NAME
Project Name
Date
Catalog Number
The Albeo ARC LED Series Round High Bay is an NSF
®
IP65 Wet Rated luminaire is an exceptional mixture of
value and performance. Ideal for high bay applications in
industrial and commercial buildings. Designed to replace
175W– 650W HID and four-to eight-lamp T5/T8 fixtures
with unmatched reliability and quality.
CONTROLS
Dimming: Standard 0 – 10VDC,10%
Field-installable 12 – 24V, >50mA tri-level
occupancy and/or ambient light sensor. Max 40ft
Sensors:
mounting height. All units come sensor-ready,
equipped for easy field-install of sensor
LUMEN AMBIENT TEMPERATURE
TYPE
OPERATING TEMPERATURE
STORAGE TEMPERATURE
LUMEN MAINTENANCE
LXX (10K) @ HOURS 50,000 HR
MOUNTING
• Typical Mounting: 1/2" NPT hook included. Wall Mount
bracket and safety tether may be ordered separately
• Cord & Plugs: 6ft cord included (pre-installed)
DESIGN LIFE & WARRANTY
• Current's Limited 5-year Warranty:
Please refer to IND599 in Product Downloads section at:
https://products.gecurrent.com
ADDITIONAL NOTES
• UL 1598 Suitable for Wet Locations (IP65)
• Emergency battery back-up kit accessory available
w(120-277V only)
Type
TEMPERATURE RATE
−40°C to +40°C (−40°F to 104°F)
−40°C to +70°C
L70
