- Page 1 Manual ME EX...
-
Page 2: Table Of Contents
3.4 Design 10.2.1 MET/MEV 3.5 Function 10.2.2 MEB 10.3 Exploded-view drawing 4 Preparation for use 10.3.1 ME EX 75 10.3.2 ME EX 100 4.1 Transport and storage 4.2 Assembly and installation 11 Accessories & Spare Parts 4.2.1 Unpacking 4.2.2 Installation 11.1 Brackets... -
Page 3: Introduction
MOVEX ME EX 1.2 Warranty Foreword To preserve the validity of the warranty, it is forbid- FUMEX operates in the environmental technology sector den to modify or re-engineer the product during the and specializes in extraction arms, fans, and filters for warranty period without first obtaining prior approval all work environments. -
Page 4: Safety
MOVEX ME EX 2 Safety 2.1 General This product is safe to use and designed to minimize any potential risks. Even so, if the product is not used correctly or as intended, it may be hazardous to the user or cause damage to the product. The user should 2.5 General warnings and... -
Page 5: Product Description
MOVEX ME EX 3 Product Description 3.1 Serial number & product name Refer to the product nameplate. 3.2 Labels and safety signs Safety signs that are missing or illegible must be replaced before the product is used. According to Fig. 1. -
Page 6: Area Of Use
MOVEX ME EX 3.3 Area of use 3.5 Function The ME EX extraction arm is an extractor arm for Since the product does not have an internal capturing and extracting gases and dust-filled air in ignition source, it cannot be classified under explosive atmospheres. -
Page 7: Preparation For Use
MOVEX ME EX 4 Preparation for use 4.1 Transport and storage 4.2.1 Unpacking 1. Unpack the product. Protect the product and its parts from rain, 2. Check for any damage and missing parts. snow, aggressive atmospheres and other Contact a local Fumex representative directly if harmful effects. - Page 8 MOVEX ME EX ME 100 EX ME 75 EX Fig. 7 METS 1500-75 EX METS 2000-75 EX MET 1650-100 EX MET 1900-100 EX MET 2100-100 EX MET 2650-100 EX 13 mm “Click” MEB 1650-100 MEB 1900-100 Fig. 8 Manual...
- Page 9 MOVEX ME EX Fig. 9 Fig. 11 Fig. 10 Manual...
-
Page 10: Commissioning
MOVEX ME EX 5 Commissioning 6 Operation 5.1 Start-up Ensure that any objects or people that may be electrostatically charged cannot come into 1. Check that all joints are adjusted to the correct contact with the equipment. friction. When extracting different dust combinations, 2. -
Page 11: Troubleshooting
MOVEX ME EX 7 Troubleshooting 7.1 Troubleshooting guide The troubleshooting guide contains information for identifying faults which are simple to rectify. Always perform the troubleshooting procedures before contacting FUMEX. TROUBLESHOOTING GUIDE Symptom Possible cause Recommended action Friction joints incorrectly adjusted. -
Page 12: Adjusting Friction Joints
MOVEX ME EX 10 Technical information 8.3 Adjusting friction joints Adjust the friction joints as shown in Fig. 11. 10.1 Technical data General 9 Decommissioning Dimensions: ..See Section 10.2 Dimensional drawing Weight: ....See Section 10.2 Dimensional drawing 9.1 Final decommissioning/ Size: .... -
Page 13: Dimensional Drawing
MOVEX ME EX 10.2 Dimensional drawing 10.2.1 MET Dimensions (in) Weight (lb) Lenght MET 1000-75EX Ø3 Ø3 Ø9 Ø2 Ø39 MET 1300-75EX Ø3 Ø3 Ø9 Ø2 Ø51 MET 1500-75EX Ø3 Ø3 Ø9 Ø2 Ø59 METS 1500-75EX* Ø3 Ø3 Ø9 Ø2 Ø59... -
Page 14: Exploded-View Drawing
MOVEX ME EX 10.3 Exploded-view drawing 10.3.1 ME EX 75 Manual... -
Page 15: Me Ex 100
MOVEX ME EX 10.3.2 ME EX 100 Manual... -
Page 16: Accessories & Spare Parts
MOVEX ME EX 11 Accessories & Spare Parts Ø (x4) Ø11 (x4) 11.1 Brackets CEILING BRACKET MTI EX Ceiling bracket with internal exhaust duct. Can be supplied in lengths excee- ding 79” upon request. ME 75EX Dimensions (in) ME 100EX... -
Page 17: Hoods And Suction Nozzles
MOVEX ME EX 11.2 Hoods and suction nozzles DOME HOOD MEK EX Suitable for gases with high lift, completely or partially covering the contaminant source. Temp. range: 5 °F to +176 °F. Material: PE (dissipative) Colour: Black Dimensions (in) Weight... -
Page 18: Other Accessories
MOVEX ME EX 11.3 Other accessories PROTECTIVE GRILLE MESG Stainless steel protective grille to prevent objects from being sucked into the system. Fitted to joints. Temp. range: 5 °F to +176 °F. Dimensions (in) MESG-75 MESG-100 Ø4 7/16 Ø6 7/16 Ø75... -
Page 19: Notes
MOVEX ME EX 12 Notes Manual... - Page 20 EXTRACTION ARMS · VEHICLE EXHAUST EXTRACTION · FANS · FILTERS · CURTAINS · CONTROLS Verkstadsvägen 2, 93161 Skellefteå, Sweden • Tel.: +46 910-361 80 • Fax: +46 910-130 22 • E-mail: info@fumex.se www.fumex.com...
